RX30L-EHD (1976)
Toyota Cressida
(7612-8008)MX32,RX30,TX30
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52055 - PAD SUB-ASSY, REAR BUMPER | ||||
| 52055-29035 |
RX3#..LHD..(DLX,GL)..GEN W/BUMPER GUARD |
1 | ||
| 52055-29055 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN FOR S.A.B. |
1 | ||
| 52055-29025 |
RX30..5F..DLX..SA;MX3#,RX35..DLX,SDX;RX30..5F..(EUR,GEN);RX30..(3FC,3H,4F)..(DLX,GL) |
1 | ||
| 52107 - STAY SUB-ASSY, REAR BUMPER, RH | ||||
| 52181-22050 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
1 | ||
| 52107 - STAY SUB-ASSY, REAR BUMPER, RH | ||||
| 52181-22050 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
1 | ||
| 52108 - STAY SUB-ASSY, REAR BUMPER, LH | ||||
| 52182-22050 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
1 | ||
| 52108 - STAY SUB-ASSY, REAR BUMPER, LH | ||||
| 52182-22050 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
1 | ||
| 52151 - BUMPER ASSY, REAR | ||||
| 52151-29355 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN FOR S.A.B. |
1 | ||
| 52151-29275 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30..(3FC,3H,4F)..(DLX,GL,SDX) W/BUMPER PAD |
1 | ||
| 52151 - BUMPER ASSY, REAR | ||||
| 52151-29355 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN FOR S.A.B. |
1 | ||
| 52151-29275 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30..(3FC,3H,4F)..(DLX,GL,SDX) W/BUMPER PAD |
1 | ||
| 52154 - GUARD, BUMPER, REAR RH | ||||
| 52405-29015 |
RX3#..LHD..(DLX,GL)..GEN |
1 | ||
| 52155 - GUARD, BUMPER, REAR LH | ||||
| 52406-29015 |
RX3#..LHD..(DLX,GL)..GEN |
1 | ||
| 52191 - PACKING, REAR BUMPER STAY | ||||
| 52191-10030 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
4 | ||
| 52191 - PACKING, REAR BUMPER STAY | ||||
| 52191-10030 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
4 | ||
| 52191 - PACKING, REAR BUMPER STAY | ||||
| 52191-10030 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
4 | ||
| 52191 - PACKING, REAR BUMPER STAY | ||||
| 52191-10030 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30,TX30..3FC,3H,4F |
4 | ||
| Common parts | ||||
| 90112-08010 | ||||
| 90179-06115 | ||||
| 90179-08123 | ||||
| 90950-01210 | ||||
| 91611-40835 | ||||
| 91661-40612 | ||||
(7908-8008)SED..LHD..DLX,GL..GEN ; (8001-8008)GL..SA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52055 - PAD SUB-ASSY, REAR BUMPER | ||||
| 52055-29035 |
RX3#..LHD..(DLX,GL)..GEN W/BUMPER GUARD |
1 | ||
| 52055-29055 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN FOR S.A.B. |
1 | ||
| 52055-29025 |
RX30..5F..DLX..SA;MX3#,RX35..DLX,SDX;RX30..5F..(EUR,GEN);RX30..(3FC,3H,4F)..(DLX,GL) |
1 | ||
| 52151 - BUMPER ASSY, REAR | ||||
| 52151-29355 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN FOR S.A.B. |
1 | ||
| 52151-29275 |
RX30..5F..DLX..SA;RX30..5F..(EUR,GEN);MX32,RX30..(3FC,3H,4F)..(DLX,GL,SDX) W/BUMPER PAD |
1 | ||
| 52167 - REINFORCEMENT, REAR BUMPER | ||||
| 52023-22030 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
1 | ||
| 52415B - PLATE, REAR ABSORBER MOUNTING | ||||
| 52415-20010 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
2 | ||
| 52415B - PLATE, REAR ABSORBER MOUNTING | ||||
| 52415-20010 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
2 | ||
| 52417B - RETAINER, REAR ABSORBER MOUNTING | ||||
| 52417-20010 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
2 | ||
| 52430 - ABSORBER, REAR BUMPER, RH | ||||
| 52605-22010 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
1 | ||
| 52430A - SPACER, REAR BUMPER ABSORBER | ||||
| 90560-08419 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
8 | ||
| 52440 - ABSORBER, REAR BUMPER, LH | ||||
| 52605-22010 |
RX30..5F..GL..SA;RX3#..(SED,WG)..LHD..(DLX,GL)..GEN |
1 | ||
| 52505 - FILLER SUB-ASSY, REAR BUMPER | ||||
| 52550-22010 |
RX30..5F..GL..SA;RX30..SED..LHD..(DLX,GL)..GEN |
1 | ||
| 52506 - EXTENSION SUB-ASSY, REAR BUMPER, RH | ||||
| 52106-29025 |
RX30..5F..GL..SA;RX30..SED..LHD..(DLX,GL)..GEN |
1 | ||
| 52507 - EXTENSION SUB-ASSY, REAR BUMPER, LH | ||||
| 52107-29145 |
RX30..5F..GL..SA;RX30..SED..LHD..(DLX,GL)..GEN |
1 | ||
| Common parts | ||||
| 90112-08010 | ||||
| 90159-50024 | ||||
| 90179-06162 | ||||
| 90179-08123 | ||||
| 90950-01210 | ||||
| 91616-60832 | ||||
| 94180-41000 | ||||
| Linked diagrams | ||||
| 5801 | ||||
