ST191L-BEPNK (1996)

Toyota Corona Sed (Ukp)

Production Jan 1996 - Oct 1997
Engine 3SFE
Transmission ATM
Displacement 2500cc
Power 168 HP (125 kW)

(9601-9710)UKP

Click highlighted areas on diagram

diagram 52029 52115A 52116A 52119A 52535 52536 9010906221 9011906374 9011906374 9016860023 9016860023 9017906127 9017906161 9046709139 9046714048
Part # Description Qty Price
52029 - REINFORCEMENT SUB-ASSY, FRONT BUMPER, UPPER
52029-05010

AT190,CT190,ST191..UKP

 1
52115A - SUPPORT, FRONT BUMPER SIDE, RH
52115-20300

AT190,CT190,ST191..UKP

 1
52116A - SUPPORT, FRONT BUMPER SIDE, LH
52116-20210

AT190,CT190,ST191..UKP

 1
52119A - COVER, FRONT BUMPER
52119-05020

AT190,CT190,ST191..UKP

 1
52535 - RETAINER, FRONT BUMPER SIDE, RH
52535-05010

AT190,CT190,ST191..UKP

 1
52536 - RETAINER, FRONT BUMPER SIDE, LH
52536-05010

AT190,CT190,ST191..UKP

 1
Common parts
90109-06221
90119-06374
90168-60023
90179-06127
90179-06161
90467-09139
90467-14048
