EE90L-AEMDS (1987)
Toyota Corolla Sed/Lb/Wg
(8908- )LB,SED
FOR FRONT BUMPER TYPE E
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52015A - ARM SUB-ASSY, REAR BUMPER, RH | ||||
| 52181-12280 |
AE92..GT..SA;AE92,CE90,EE90..SED..(GL,SE,STD,XL) |
1 | ||
| 52016A - ARM SUB-ASSY, REAR BUMPER, LH | ||||
| 52182-12230 |
AE92..GT..SA;AE92,CE90,EE90..SED..(GL,SE,STD,XL) |
1 | ||
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-12150 |
AE9#,CE90,EE90..LB,SED |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-12140 |
AE92,CE90,EE90..LB,SED |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-12830 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE F,W(BUMPER MOULDING) |
1 | ||
| 52159-12710 |
EE90..4F..STD..GCC;AE9#,CE90,EE90..SED..(STD,XL)..(GEN,SA) TYPE F |
1 | ||
| 52159-12830 |
AE9#,CE90,EE90..SED..XL..GEN TYPE F,W(BUMPER MOULDING) |
1 | ||
| 52565A - RETAINER, REAR BUMPER, LOWER | ||||
| 52565-12110 |
AE92,CE90,EE90..SED TYPE C |
1 | ||
| 52565-12040 |
EE90..STD..GCC;AE92..(GL,XL)..SA;EE90..SED..(STD,XL)..(GEN,SA);AE9#,CE90..SED..(STD,XL)..GEN TYPE A |
4 | ||
| 52565-12100 |
AE9#,CE90,EE90..SED..XL..GEN TYPE B |
2 | ||
| 52565-12100 |
AE9#,CE90,EE90..SED TYPE B |
2 | ||
| 52565-12040 |
AE9#,CE90,EE90..SED TYPE A |
2 | ||
| 52565-12160 |
AE9#,CE90,EE90..(LB,SED)..(GL,GTI,STD,XL) TYPE D |
1 | ||
| 52565-12040 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE A |
6 | ||
| 52565-12040 |
AE9#,CE90,EE90..SED..XL..GEN TYPE A |
6 | ||
| 52565-12160 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE D |
1 | ||
| 52565-16020 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE A |
6 | ||
| 52565-16020 |
AE92,CE90,EE90..SED..XL..GEN TYPE A |
6 | ||
| 52565-16020 |
AE92,CE90,EE90..SED..(GL,XL)..GEN TYPE A |
6 | ||
| 52565-12160 |
AE92,CE90,EE90..SED..(GL,XL)..GEN TYPE D |
1 | ||
| 52565-12160 |
AE92,CE90,EE90..SED..XL..GEN TYPE D |
1 | ||
| 52565-12100 |
AE92,CE90,EE90..SED..XL..GEN TYPE B |
2 | ||
| 52565-12100 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE B |
2 | ||
| 52565-12100 |
AE92,CE90,EE90..SED..(GL,XL)..GEN TYPE B |
2 | ||
| 52565-16020 |
EE90..4F..STD..GCC;AE92,CE90,EE90..SED..(STD,XL)..GEN TYPE A |
4 | ||
| 52591 - SEAL, REAR BUMPER SIDE, RH | ||||
| 52591-12050 |
AE9#,CE90,EE90..LB,SED |
1 | ||
| 52751 - MOULDING, REAR BUMPER | ||||
| 52751-12120 |
AE92,CE90,EE90..LHD..SED..XL;AE92,EE90..SED..(GL,SE)..(GCC,GEN) |
1 | ||
| 52751-12120 |
AE92,EE90..SED..GL..GEN;AE92,CE90,EE90..LHD..SED..XL..GEN W(PAINTED BUMPER) |
1 | ||
| 52751-12120 |
AE9#,CE90,EE90..SED..(GL,XL)..(GCC,GEN) |
1 | ||
| Common parts | ||||
| 90119-06340 | ||||
| 90119-06341 | ||||
| 90159-60008 | ||||
| 90159-60304 | ||||
| 90179-08025 | ||||
| 90189-06013 | ||||
| 90189-06089 | ||||
| 90467-06018 | ||||
| 91655-40820 | ||||
| 91656-60618 | ||||
(8705- )LB,SED ; (8908- )
FOR FRONT BUMPER TYPE F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52015A - ARM SUB-ASSY, REAR BUMPER, RH | ||||
| 52181-12280 |
AE92..GT..SA;AE92,CE90,EE90..SED..(GL,SE,STD,XL) |
1 | ||
| 52016A - ARM SUB-ASSY, REAR BUMPER, LH | ||||
| 52182-12230 |
AE92..GT..SA;AE92,CE90,EE90..SED..(GL,SE,STD,XL) |
1 | ||
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-12150 |
AE9#,CE90,EE90..LB,SED |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-12140 |
AE92,CE90,EE90..LB,SED |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-12830 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE F,W(BUMPER MOULDING) |
1 | ||
| 52159-12710 |
EE90..4F..STD..GCC;AE9#,CE90,EE90..SED..(STD,XL)..(GEN,SA) TYPE F |
1 | ||
| 52159-12830 |
AE9#,CE90,EE90..SED..XL..GEN TYPE F,W(BUMPER MOULDING) |
1 | ||
| 52565A - RETAINER, REAR BUMPER, LOWER | ||||
| 52565-12110 |
AE92,CE90,EE90..SED TYPE C |
1 | ||
| 52565-12040 |
EE90..STD..GCC;AE92..(GL,XL)..SA;EE90..SED..(STD,XL)..(GEN,SA);AE9#,CE90..SED..(STD,XL)..GEN TYPE A |
4 | ||
| 52565-12100 |
AE9#,CE90,EE90..SED..XL..GEN TYPE B |
2 | ||
| 52565-12100 |
AE9#,CE90,EE90..SED TYPE B |
2 | ||
| 52565-12040 |
AE9#,CE90,EE90..SED TYPE A |
2 | ||
| 52565-12160 |
AE9#,CE90,EE90..(LB,SED)..(GL,GTI,STD,XL) TYPE D |
1 | ||
| 52565-12040 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE A |
6 | ||
| 52565-12040 |
AE9#,CE90,EE90..SED..XL..GEN TYPE A |
6 | ||
| 52565-12160 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE D |
1 | ||
| 52565-16020 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE A |
6 | ||
| 52565-16020 |
AE92,CE90,EE90..SED..XL..GEN TYPE A |
6 | ||
| 52565-16020 |
AE92,CE90,EE90..SED..(GL,XL)..GEN TYPE A |
6 | ||
| 52565-12160 |
AE92,CE90,EE90..SED..(GL,XL)..GEN TYPE D |
1 | ||
| 52565-12160 |
AE92,CE90,EE90..SED..XL..GEN TYPE D |
1 | ||
| 52565-12100 |
AE92,CE90,EE90..SED..XL..GEN TYPE B |
2 | ||
| 52565-12100 |
EE90..SED..XL..GCC;AE92,EE90..SED..(GL,SE)..(GCC,GEN) TYPE B |
2 | ||
| 52565-12100 |
AE92,CE90,EE90..SED..(GL,XL)..GEN TYPE B |
2 | ||
| 52565-16020 |
EE90..4F..STD..GCC;AE92,CE90,EE90..SED..(STD,XL)..GEN TYPE A |
4 | ||
| 52591 - SEAL, REAR BUMPER SIDE, RH | ||||
| 52591-12050 |
AE9#,CE90,EE90..LB,SED |
1 | ||
| 52751 - MOULDING, REAR BUMPER | ||||
| 52751-12120 |
AE92,CE90,EE90..LHD..SED..XL;AE92,EE90..SED..(GL,SE)..(GCC,GEN) |
1 | ||
| 52751-12120 |
AE92,EE90..SED..GL..GEN;AE92,CE90,EE90..LHD..SED..XL..GEN W(PAINTED BUMPER) |
1 | ||
| 52751-12120 |
AE9#,CE90,EE90..SED..(GL,XL)..(GCC,GEN) |
1 | ||
| Common parts | ||||
| 90119-06340 | ||||
| 90119-06341 | ||||
| 90119-14002 | ||||
| 90159-60304 | ||||
| 90179-08025 | ||||
| 90189-04096 | ||||
| 90189-06013 | ||||
| 90189-06089 | ||||
| 91655-40820 | ||||
