AE92R-ALHNU (1987)
Toyota Corolla Sed/Lb/Wg
(8705- )4AF
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17061 - DIAPHRAGM SUB-ASSY | ||||
| 17061-10010 |
4AF..AE9#..GEN W(HOT AIR INTAKE & PRE AIR CLEANER) |
1 | ||
| 17061-15040 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17061-15040 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17061 - DIAPHRAGM SUB-ASSY | ||||
| 17061-10010 |
4AF..AE9#..GEN W(HOT AIR INTAKE & PRE AIR CLEANER) |
1 | ||
| 17061-15040 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17061-15040 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-16430 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17700-16480 |
4AF..AE9#..GCC,GEN W(PRE AIR CLEANER) |
1 | ||
| 17700-16420 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17700-16510 |
4AF..AE9#..GEN W(HOT AIR INTAKE & PRE AIR CLEANER) |
1 | ||
| 17700-16430 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-16430 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17700-16480 |
4AF..AE9#..GCC,GEN W(PRE AIR CLEANER) |
1 | ||
| 17700-16420 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17700-16510 |
4AF..AE9#..GEN W(HOT AIR INTAKE & PRE AIR CLEANER) |
1 | ||
| 17700-16430 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 90175-06010 |
4AF..AE9# |
1 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06018 |
4AF..AE9# |
1 | ||
| 17705 - CAP SUB-ASSY, AIR CLEANER | ||||
| 17705-15150 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17705-16220 |
4AF..AE9#..GCC,GEN W(PRE AIR CLEANER) |
1 | ||
| 17705-15150 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17705-16240 |
4AF..AE9#..GEN W(HOT AIR INTAKE & PRE AIR CLEANER) |
1 | ||
| 17705-16210 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17728 - VALVE, THERMOSTATIC | ||||
| 17728-16010 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17728-16010 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17730A - HOSE, PRECLEANER | ||||
| 17881-16180 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17730B - CLAMP, HOSE(FOR PRECLEANER HOSE) | ||||
| 17786-16010 |
4AF..AE9#..GCC,GEN |
2 | ||
| 17730B - CLAMP, HOSE(FOR PRECLEANER HOSE) | ||||
| 17786-16010 |
4AF..AE9#..GCC,GEN |
2 | ||
| 17730C - CASE, PRECLEANER | ||||
| 17736-16040 |
4AF..AE9#..GEN W(HOT AIR INTAKE) |
1 | ||
| 17736-16030 |
4AF..AE9#..GEN W(PRE AIR CLEANER) |
1 | ||
| 17730E - BRACKET, PRECLEANER, NO.1 | ||||
| 17741-16020 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17744 - CUP, PRECLEANER | ||||
| 17744-16020 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17751 - INLET, AIR CLEANER, NO.1 | ||||
| 17751-15010 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17751-16010 |
4AF..AE9#..GCC,GEN |
1 | ||
| 17751-15010 |
4AF..AE92..RHD..GEN SINGAPORE SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-15060 |
4AF..AE9# |
1 | ||
| 17881 - HOSE, AIR CLEANER, NO.1 | ||||
| 17881-15120 |
4AF..AE92..RHD NEW ZEALAND SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17881-15150 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1) | ||||
| 96111-10460 |
4AF..AE92..RHD..GEN NEW ZEALAND SPEC OR W(HOT AIR INTAKE) |
1 | ||
| 17882 - HOSE, AIR CLEANER, NO.2 | ||||
| 17881-15140 |
4AF..AE9# |
1 | ||
| 17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2) | ||||
| 17786-15010 |
4AF..AE9# |
2 | ||
| 17882A - CLAMP(FOR AIR CLEANER HOSE, NO.2) | ||||
| 17786-15010 |
4AF..AE9# |
2 | ||
| 17883 - HOSE, AIR CLEANER, NO.3 | ||||
| 17883-16030 |
4AF..AE9# |
1 | ||
| 17884 - HOSE, AIR CLEANER, NO.4 | ||||
| 17880-16010 |
4AF..AE9# |
1 | ||
| Common parts | ||||
| 90119-06374 | ||||
| 90175-06010 | ||||
| 90179-06070 | ||||
| 90179-06143 | ||||
| 90339-03005 | ||||
| 91651-40614 | ||||
| 92122-40655 | ||||
