AE92R-AEMNU (1987)

Toyota Corolla Sed/Lb/Wg

Production May 1987 - May 1992
Engine 4AF
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8705- )

Click highlighted areas on diagram

diagram 11278 11284 11288 11291 11292 11293A 11293A 11293A 11294 11296A 11296A 11298 1356410010 17791 17792 23923
Part # Description Qty Price
11278 - PLATE, ENGINE EMISSION IDENTIFICATION
11278-16020

4AF,2E..AE9#,EE97..RHD;2E..EE90..RHD..(LB,SED)..MTM

SINGAPORE SPEC

 1
11278-16020

4AF..AE92..RHD..GL..GEN;2E..EE90..RHD..(LB,SED)..MTM..GEN;4AF,2E..AE92,EE97..RHD..(3FC,4F,4FC)..(STD,XL)..GEN

SINGAPORE SPEC

 1
11291 - PLATE, ENGINE NAME
11291-15120

4AF..AE9#

 1
11292 - PLATE, ENGINE NAME, NO.2
11292-16010

4AF..AE92..RHD..GL..GEN

W(HOT AIR INTAKE)

 1
11296A - LABEL, ENGINE SERVICE INFORMATION
11296-16030

4AF..AE9#

 1
11296A - LABEL, ENGINE SERVICE INFORMATION
11296-16030

4AF..AE9#

 1
Common parts
13564-10010
