AE86R-ECMQF (1983)
Toyota Corolla Coupe
(8305-8511)4A,4AC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 15100 - PUMP ASSY, OIL | ||||
| 15100-19015 |
4A,4AC..AE86 |
1 | ||
| 15100-15020 |
4A..AE86 |
1 | ||
| 15100-19025 |
4AG#..AE86 |
1 | ||
| 15100A - PIN, RING(FOR OIL PUMP SET) | ||||
| 90253-11021 |
4A,4AC,4AG#..AE86 |
2 | ||
| 15100B - RING, O(FOR OIL PUMP) | ||||
| 96711-19010 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15100C - SEAL(FOR OIL PUMP) | ||||
| 90311-32001 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15104 - STRAINER SUB-ASSY, OIL | ||||
| 15104-15080 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15115 - COVER, OIL PUMP | ||||
| 15115-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15115-15030 |
4A..AE86 TOYODA |
1 | ||
| 15115-15020 |
4A..AE86 AISIN |
1 | ||
| 15120 - BODY SUB-ASSY, OIL PUMP | ||||
| 15101-15020 |
4A..AE86 AISIN |
1 | ||
| 15120-15011 |
4A,4AC..AE86 AISIN |
1 | ||
| 15101-15030 |
4A..AE86 TOYODA |
1 | ||
| 15121 - GEAR, OIL PUMP DRIVE | ||||
| 15121-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15121-15030 |
4A..AE86 TOYODA |
1 | ||
| 15121 - GEAR, OIL PUMP DRIVE | ||||
| 15121-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15121-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122 - GEAR, OIL PUMP DRIVEN | ||||
| 15122-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15122 - GEAR, OIL PUMP DRIVEN | ||||
| 15122-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15131 - VALVE, OIL PUMP RELIEF | ||||
| 15131-15030 |
4A..AE86 TOYODA |
1 | ||
| 15131-24010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15132 - SPRING, OIL PUMP RELIEF VALVE | ||||
| 15132-40010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15132-15030 |
4A..AE86 TOYODA |
1 | ||
| 15135 - RETAINER, OIL PUMP RELIEF VALVE | ||||
| 15135-15030 |
4A..AE86 TOYODA |
1 | ||
| 15135-15010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15149 - GASKET, OIL STRAINER FLANGE | ||||
| 15149-15010 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15193 - GASKET, OIL PUMP | ||||
| 15197-15011 |
4A,4AC,4AG#..AE86 |
1 | ||
| Common parts | ||||
| 90116-06049 | ||||
| 90151-60006 | ||||
| 90179-06070 | ||||
| 91511-60825 | ||||
| 91511-60835 | ||||
| 91611-60610 | ||||
| 93220-16014 | ||||
| 96151-01500 | ||||
(8308- )4AG#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 15100 - PUMP ASSY, OIL | ||||
| 15100-19015 |
4A,4AC..AE86 |
1 | ||
| 15100-15020 |
4A..AE86 |
1 | ||
| 15100-19025 |
4AG#..AE86 |
1 | ||
| 15100A - PIN, RING(FOR OIL PUMP SET) | ||||
| 90253-11021 |
4A,4AC,4AG#..AE86 |
2 | ||
| 15100B - RING, O(FOR OIL PUMP) | ||||
| 96711-19010 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15100C - SEAL(FOR OIL PUMP) | ||||
| 90311-32001 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15104 - STRAINER SUB-ASSY, OIL | ||||
| 15104-15080 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15104E - BOLT, STUD(FOR OIL STRAINER) | ||||
| 90116-06022 |
4AGE..AE86 |
2 | ||
| 15115 - COVER, OIL PUMP | ||||
| 15115-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15115-15030 |
4A..AE86 TOYODA |
1 | ||
| 15115-15020 |
4A..AE86 AISIN |
1 | ||
| 15120 - BODY SUB-ASSY, OIL PUMP | ||||
| 15101-15020 |
4A..AE86 AISIN |
1 | ||
| 15120-15011 |
4A,4AC..AE86 AISIN |
1 | ||
| 15101-15030 |
4A..AE86 TOYODA |
1 | ||
| 15121 - GEAR, OIL PUMP DRIVE | ||||
| 15121-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15121-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122 - GEAR, OIL PUMP DRIVEN | ||||
| 15122-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15131 - VALVE, OIL PUMP RELIEF | ||||
| 15131-15030 |
4A..AE86 TOYODA |
1 | ||
| 15131-24010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15132 - SPRING, OIL PUMP RELIEF VALVE | ||||
| 15132-40010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15132-15030 |
4A..AE86 TOYODA |
1 | ||
| 15135 - RETAINER, OIL PUMP RELIEF VALVE | ||||
| 15135-15030 |
4A..AE86 TOYODA |
1 | ||
| 15135-15010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15149 - GASKET, OIL STRAINER FLANGE | ||||
| 15149-15010 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15193 - GASKET, OIL PUMP | ||||
| 15197-15011 |
4A,4AC,4AG#..AE86 |
1 | ||
| Common parts | ||||
| 90179-06070 | ||||
| 91511-60825 | ||||
| 91511-60835 | ||||
| 91611-60610 | ||||
| 93220-16014 | ||||
| 96151-01500 | ||||
(8511- )4A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 15100 - PUMP ASSY, OIL | ||||
| 15100-19015 |
4A,4AC..AE86 |
1 | ||
| 15100-15020 |
4A..AE86 |
1 | ||
| 15100-19025 |
4AG#..AE86 |
1 | ||
| 15100A - PIN, RING(FOR OIL PUMP SET) | ||||
| 90253-11021 |
4A,4AC,4AG#..AE86 |
2 | ||
| 15100B - RING, O(FOR OIL PUMP) | ||||
| 96711-19010 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15100C - SEAL(FOR OIL PUMP) | ||||
| 90311-32001 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15103 - GEAR SET, OIL PUMP | ||||
| 15103-15020 |
4A..AE86 AISIN |
1 | ||
| 15104 - STRAINER SUB-ASSY, OIL | ||||
| 15104-15080 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15115 - COVER, OIL PUMP | ||||
| 15115-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15115-15030 |
4A..AE86 TOYODA |
1 | ||
| 15115-15020 |
4A..AE86 AISIN |
1 | ||
| 15120 - BODY SUB-ASSY, OIL PUMP | ||||
| 15101-15020 |
4A..AE86 AISIN |
1 | ||
| 15120-15011 |
4A,4AC..AE86 AISIN |
1 | ||
| 15101-15030 |
4A..AE86 TOYODA |
1 | ||
| 15121 - GEAR, OIL PUMP DRIVE | ||||
| 15121-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15121-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122 - GEAR, OIL PUMP DRIVEN | ||||
| 15122-15030 |
4A..AE86 TOYODA |
1 | ||
| 15122-15010 |
4A,4AC..AE86 AISIN |
1 | ||
| 15131 - VALVE, OIL PUMP RELIEF | ||||
| 15131-15030 |
4A..AE86 TOYODA |
1 | ||
| 15131-24010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15132 - SPRING, OIL PUMP RELIEF VALVE | ||||
| 15132-40010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15132-15030 |
4A..AE86 TOYODA |
1 | ||
| 15135 - RETAINER, OIL PUMP RELIEF VALVE | ||||
| 15135-15030 |
4A..AE86 TOYODA |
1 | ||
| 15135-15010 |
4A,4AC,4AG#..AE86 AISIN |
1 | ||
| 15149 - GASKET, OIL STRAINER FLANGE | ||||
| 15149-15010 |
4A,4AC,4AG#..AE86 |
1 | ||
| 15193 - GASKET, OIL PUMP | ||||
| 15197-15011 |
4A,4AC,4AG#..AE86 |
1 | ||
| Common parts | ||||
| 90116-06049 | ||||
| 90151-60006 | ||||
| 90179-06070 | ||||
| 91511-60825 | ||||
| 91511-60835 | ||||
| 91611-60610 | ||||
| 93220-16014 | ||||
| 96151-01500 | ||||
