Toyota Corolla coupe AE86 THROTTLE LINK & VALVE LEVER (ATM)

Part #	Description	Period	Qty
35505 - LEVER SUB-ASSY, MANUAL VALVE
35505-22020	AE86..4FC	05/1983 - 08/1983	1
35505-22030	AE86..4FC	08/1983 - 12/1983	1
35505-22040	AE86..4FC	12/1983 - 04/1987	1
35506 - SHAFT SUB-ASSY, MANUAL VALVE LEVER
35561-40010	AE86..4FC	05/1983 - 04/1987	1
35506C - PIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)
90254-04011	AE86..4FC	05/1983 - 04/1987	1
35506F - SEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)
90311-11128	AE86..4FC	05/1983 - 08/1983	2
90311-11001	AE86..4FC	08/1983 - 04/1987	2
35506F - SEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)
90311-11128	AE86..4FC	05/1983 - 08/1983	2
90311-11001	AE86..4FC	08/1983 - 04/1987	2
35506H - SPACER (FOR MANUAL VALVE LEVER SHAFT)
90560-20003	AE86..4FC	05/1983 - 04/1987	1
35556 - SHAFT, PARKING LOCK PAWL
35556-22010	AE86..4FC	05/1983 - 08/1985	1
35556-26010	AE86..4FC	08/1985 - 04/1987	1
35556E - RING, E (FOR PARKING LOCK PAWL SHAFT)
90523-08021	AE86..4FC	05/1983 - 04/1987	1
35557 - PAWL, PARKING LOCK
35557-35010	AE86..4FC	05/1983 - 04/1987	1
35557A - SPRING, TORSION (FOR PARKING LOCK PAWL)
90508-25001	AE86..4FC	05/1983 - 04/1987	1
35585 - ROD, PARKING LOCK
35501-22020	AE86..4FC	05/1983 - 04/1987	1
35595 - BRACKET, PARKING LOCK PAWL
35595-16010	AE86..4FC	05/1983 - 10/1983	1
35595-40010	AE86..4FC	10/1983 - 04/1987	1
Common parts
90101-06416
94110-50800
94512-00800
94542-00600

AE86L-ESPXS (1983)
