ZZE122R-GEPGKT (2001)
Toyota Corolla (Asia/India)
(0105-0208)IDN,MA,PHL,TH,VN ; (0208-0311)IDN,MA,PHL,VN ; (0311-0506)MA,PHL,VN ; (05
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-13020 |
ZZE12#..TH |
1 | ||
| 45025-13020 |
ZZE12#..TH |
1 | ||
| 45025-13020 |
ZZE12#..IDN,TH |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 45274-42010 |
ZZE12#..TH |
1 | ||
| 45274-02020 |
ZZE12#..IDN,TH |
1 | ||
| 45274-42010 |
ZZE12#..TH (J) |
1 | ||
| 45274-02020 |
ZZE12#..TH (L) |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
ZZE12#..IDN,TH T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,TH T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,PHL,TH,VN T=1.20,UPPER |
1 | ||
| 90520-17269 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE12#..IDN,PHL,TH,VN T=1.20,(L),LOWER |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
ZZE12#..IDN,TH T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,TH T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,PHL,TH,VN T=1.20,UPPER |
1 | ||
| 90520-17269 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE12#..IDN,PHL,TH,VN T=1.20,(L),LOWER |
1 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-12150 |
ZZE12#..TH |
1 | ||
| 45209-02030 |
ZZE12#..IDN,TH |
1 | ||
| 45209-02030 |
ZZE12#..TH |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-02090 |
ZZE12#..IDN,TH (L) |
1 | ||
| 45210-42020 |
ZZE12#..TH |
1 | ||
| 45210-42020 |
ZZE12#..IDN,TH (J) |
1 | ||
| 45210-42020 |
ZZE12#..TH (J) |
1 | ||
| 45210-02090 |
ZZE12#..IDN,TH (L) |
1 | ||
| 45221 - SHAFT, STEERING INTERMEDIATE | ||||
| 45221-12291 |
ZZE12#..TH |
1 | ||
| 45221-02040 |
ZZE12#..IDN,TH |
1 | ||
| 45221-02040 |
ZZE12#..IND,TH |
1 | ||
| 45250 - COLUMN ASSY, STEERING | ||||
| 45250-1E200 |
ZZE12#..TH |
1 | ||
| 45250-02400 |
ZZE12#..IDN,TH |
1 | ||
| 45250-02400 |
ZZE12#..TH |
1 | ||
| 45259A - SHEET, COLUMN HOLE COVER SILENCER | ||||
| 45259-02010 |
ZZE12#..IDN,TH |
1 | ||
| 45259-02010 |
ZZE12#..IND,TH |
1 | ||
| 45259-12010 |
ZZE12#..TH |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-12460 |
ZZE12#..TH |
1 | ||
| 45260-02050 |
ZZE12#..TH |
1 | ||
| 45260-02050 |
ZZE121..TH;ZZE121..ATM..MA;ZZE122..IDN,MA,TH |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-16020 |
ZZE12#..IDN,TH |
1 | ||
| 45271-16020 |
ZZE12#..IDN,TH |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-02040 |
ZZE12#..ATM..(IDN,TH) |
1 | ||
| 45280-02040 |
ZZE12#..ATM..(IDN,TH) |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-02150E0 |
ZZE122..(18E,18G)..(IDN,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45286-02150E0 |
ZZE122..(18E,18G)..(IDN,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45286-02230E0 |
ZZE121..ATM..16E..TH;ZZE122..(18E,18G)..(IDN,TH) W(AUTOMATIC LIGHT CONTROL),SANDAL WOOD,TRIM0# |
1 | ||
| 45287 - COVER, STEERING COLUMN, LWR | ||||
| 45287-02160E0 |
ZZE122..(18E,18G)..(IDN,TAIW,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45287-02160E0 |
ZZE122..(18E,18G)..(IDN,TAIW,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45287-02180E0 |
ZZE122..(18E,18G)..(IDN,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
ZZE12#..IDN,TH |
2 | ||
| 45897-12020 |
ZZE12#..IDN,TH |
2 | ||
| Common parts | ||||
| 90105-08418 | ||||
| 90119-08560 | ||||
| 90119-08C42 | ||||
| 90467-06188 | ||||
| 93313-14012 | ||||
| 93568-55014 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(0208-0311)TH ; (0311- )IDN,TH
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-13020 |
ZZE12#..TH |
1 | ||
| 45025-13020 |
ZZE12#..TH |
1 | ||
| 45025-13020 |
ZZE12#..IDN,TH |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 45274-42010 |
ZZE12#..TH |
1 | ||
| 45274-02020 |
ZZE12#..IDN,TH |
1 | ||
| 45274-42010 |
ZZE12#..TH (J) |
1 | ||
| 45274-02020 |
ZZE12#..TH (L) |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
ZZE12#..IDN,TH T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,TH T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,PHL,TH,VN T=1.20,UPPER |
1 | ||
| 90520-17269 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE12#..IDN,PHL,TH,VN T=1.20,(L),LOWER |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
ZZE12#..IDN,TH T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,TH T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,LOWER |
1 | ||
| 90520-17269 |
ZZE12#..IDN,PHL,TH,VN T=1.20,UPPER |
1 | ||
| 90520-17269 |
ZZE121..TH;ZZE121..MTM..PHL;ZZE122..IDN,MA,PHL,TH,VN;ZZE121..ATM..16E..(MA,PHL) T=1.20,UPPER |
1 | ||
| 90520-17042 |
ZZE12#..IDN,PHL,TH,VN T=1.20,(L),LOWER |
1 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-12150 |
ZZE12#..TH |
1 | ||
| 45209-02030 |
ZZE12#..IDN,TH |
1 | ||
| 45209-02030 |
ZZE12#..TH |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-02090 |
ZZE12#..IDN,TH (L) |
1 | ||
| 45210-42020 |
ZZE12#..TH |
1 | ||
| 45210-42020 |
ZZE12#..IDN,TH (J) |
1 | ||
| 45210-42020 |
ZZE12#..TH (J) |
1 | ||
| 45210-02090 |
ZZE12#..IDN,TH (L) |
1 | ||
| 45221 - SHAFT, STEERING INTERMEDIATE | ||||
| 45221-12291 |
ZZE12#..TH |
1 | ||
| 45221-02040 |
ZZE12#..IDN,TH |
1 | ||
| 45221-02040 |
ZZE12#..IND,TH |
1 | ||
| 45250 - COLUMN ASSY, STEERING | ||||
| 45250-1E200 |
ZZE12#..TH |
1 | ||
| 45250-02400 |
ZZE12#..IDN,TH |
1 | ||
| 45250-02400 |
ZZE12#..TH |
1 | ||
| 45259A - SHEET, COLUMN HOLE COVER SILENCER | ||||
| 45259-02010 |
ZZE12#..IDN,TH |
1 | ||
| 45259-02010 |
ZZE12#..IND,TH |
1 | ||
| 45259-12010 |
ZZE12#..TH |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-12460 |
ZZE12#..TH |
1 | ||
| 45260-02050 |
ZZE12#..TH |
1 | ||
| 45260-02050 |
ZZE121..TH;ZZE121..ATM..MA;ZZE122..IDN,MA,TH |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-16020 |
ZZE12#..IDN,TH |
1 | ||
| 45271-16020 |
ZZE12#..IDN,TH |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-02040 |
ZZE12#..ATM..(IDN,TH) |
1 | ||
| 45280-02040 |
ZZE12#..ATM..(IDN,TH) |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-02150E0 |
ZZE122..(18E,18G)..(IDN,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45286-02150E0 |
ZZE122..(18E,18G)..(IDN,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45286-02230E0 |
ZZE121..ATM..16E..TH;ZZE122..(18E,18G)..(IDN,TH) W(AUTOMATIC LIGHT CONTROL),SANDAL WOOD,TRIM0# |
1 | ||
| 45287 - COVER, STEERING COLUMN, LWR | ||||
| 45287-02160E0 |
ZZE122..(18E,18G)..(IDN,TAIW,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45287-02160E0 |
ZZE122..(18E,18G)..(IDN,TAIW,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45287-02180E0 |
ZZE122..(18E,18G)..(IDN,TH) SANDAL WOOD,TRIM0# |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
ZZE12#..IDN,TH |
2 | ||
| 45897-12020 |
ZZE12#..IDN,TH |
2 | ||
| Common parts | ||||
| 90105-08418 | ||||
| 90167-T0013 | ||||
| 90467-06188 | ||||
| 93313-14012 | ||||
| Linked diagrams | ||||
| 8401 | ||||
