ZRE172L-DEXSK (2014)

Toyota Corolla

Production Apr 2014 - Aug 2016
Engine 2ZRFE
Transmission CVT
Displacement 2500cc
Power 168 HP (125 kW)

(1308- )

Click highlighted areas on diagram

diagram 11298B 16793B 69339C 74515A 74541E 74559B 74596A 74598A 82685 88723E
Part # Description Qty Price
16793B - LABEL, COOLING FAN INFORMATION
16793-0T020

2ZRFE..ZRE172..CVT,MTM

 1
69339C - LABEL, CHILD PROTECTOR INFORMATION
69339-06040

ZRE172..CVT,MTM

 2
74559B - LABEL, FUEL INFORMATION
74559-01010

ZRE172..GEN

 1
74596A - LABEL, SIDE AIR BAG CAUTION
74596-02020

ZRE172..(CVT,MTM)..(LE,S);ZRE172..(CVT,MTM)..STD..MXC

 2
74598A - LABEL, PASSENGER AIR BAG CAUTION
74598-20010

ZRE172..GEN

 1
82685 - PLATE, CAUTION
82685-12110

ZRE172..CVT,MTM

 1
88723E - LABEL, COOLER SERVICE CAUTION
88723-02340

ZRE172..CVT,MTM

 1
