TE72L-ELMECC (1982)
Toyota Corolla
(7908-8305)3TC..EUR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 28011 - CLUTCH SUB-ASSY, STARTER | ||||
| 28011-26042 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28011-15010 |
3TC..TE72..SE,XE 12V 0.8KW |
1 | ||
| 28011-22020 |
4K,2T#,3T..KE70,TE7# 12V 0.6KW,0.8KW |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-26080 |
2T#,3T..TE7# 12V 0.8KW |
1 | ||
| 28110 - HOUSING ASSY, STARTER DRIVE | ||||
| 28110-25011 |
2T#,3T..TE7# 12V 0.8KW |
1 | ||
| 28120 - YOKE ASSY, STARTER | ||||
| 28120-25011 |
2T#,3T..TE7# 12V 0.8KW |
1 | ||
| 28120-26070 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28130 - FRAME ASSY, STARTER COMMUTATOR END | ||||
| 28130-37010 |
3TC..TE72..SE,XE 12V 0.8KW |
1 | ||
| 28130-21011 |
4K,2T#,3T..KE70,TE7# 12V 0.6KW,0.8KW |
1 | ||
| 28137 - WASHER, FELT, STARTER | ||||
| 90099-02323 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28140 - HOLDER ASSY, STARTER BRUSH | ||||
| 28140-15010 |
3TC..TE72..SE,XE 12V 0.8KW |
1 | ||
| 28140-25011 |
2T#,3T..TE7# 12V 0.8KW |
1 | ||
| 28140-26070 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28143 - SPRING, STARTER BRUSH | ||||
| 28143-40010 |
4K,2T#,3T..KE70,TE7# 12V 0.6KW,0.8KW |
4 | ||
| 90099-17112 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
4 | ||
| 28150 - SWITCH ASSY, MAGNET STARTER | ||||
| 28150-25010 |
2T#,3T..TE7# 12V 0.8KW |
1 | ||
| 28160 - ARMATURE ASSY, STARTER | ||||
| 28160-15010 |
3TC..TE72..SE,XE 12V 0.8KW |
1 | ||
| 28160-26070 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28160-22021 |
2T#,3T..TE7# 12V 0.8KW |
1 | ||
| 28160A - BEARING, STARTER ARMATURE | ||||
| 28253-45020 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW,NO.2 |
1 | ||
| 90099-10113 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW,NO.1 |
1 | ||
| 28160A - BEARING, STARTER ARMATURE | ||||
| 28253-45020 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW,NO.2 |
1 | ||
| 90099-10113 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW,NO.1 |
1 | ||
| 28165 - SPRING, STARTER MAGNET SWITCH RETURN | ||||
| 28165-26040 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28228 - ROLLER, STARTER IDLE GEAR CLUTCH | ||||
| 28228-26040 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28229 - RETAINER, STARTER IDLE GEAR | ||||
| 28229-26040 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| 28252 - GEAR, STARTER IDLE | ||||
| 28254-45020 |
4K#,3TC..KE70,TE72..LHD..EUR 12V 1.0KW |
1 | ||
| Common parts | ||||
| 90091-20604 | ||||
| 90099-00902 | ||||
| 90099-00907 | ||||
| 90099-04562 | ||||
| 90099-05129 | ||||
| 90099-12009 | ||||
| 90179-08146 | ||||
| 91611-41040 | ||||
| 91611-61050 | ||||
| 94110-40800 | ||||
| 94511-00800 | ||||
