KE70R-EDMNSW (1981)
Toyota Corolla
(8108-8204)DV,SED,WG..RHD..EUR,GEN ; (8108-8406)AE71,KE70..2D..ARL ; (8204- )AE7
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55301 - PANEL SUB-ASSY, INSTRUMENT | ||||
| 55311-1215015 |
TE71..RHD..4D;KE70,TE72..(DX,GL)..SA;KE70..(DV,SED,WG)..RHD..(EUR,GEN) BEIGE,BEIGE,TRIM4# |
1 | ||
| 55311-1215001 |
TE71..RHD..4D..GEN;KE70..(DV,SED,WG)..RHD..(2FC,4F);KE70..(SED,WG)..RHD..5F..(EUR,GEN) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55311-1215004 |
CE70,KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 55311-1215006 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) D-BROWN,BROWN,TRIM4# |
1 | ||
| 55311-1215001 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55301G - REINFORCEMENT SUB-ASSY, INSTRUMENT PANEL | ||||
| 55305-12050 |
KE70,TE7#..(DV,SED,WG)..RHD |
1 | ||
| 55308 - TRAY SUB-ASSY, INSTRUMENT PANEL UNDER | ||||
| 55601-1208005 |
KE70,TE7#..(SED,WG)..RHD..(DX,GL,XL) BEIGE,BEIGE,TRIM4# |
1 | ||
| 55601-1208004 |
KE70,TE71..(SED,WG)..RHD..(DX,GL,XL)..(EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 55601-1208001 |
KE70,TE71..(SED,WG)..RHD..(DX,GL,XL)..(EUR,GEN) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55342 - BRACE, INSTRUMENT PANEL, NO.2 | ||||
| 55307-12030 |
AE71,CE70,KE70,TE7#..(DV,SED,WG)..RHD |
1 | ||
| 55343 - BRACE, INSTRUMENT PANEL, NO.3 | ||||
| 55308-12100 |
AE71,CE70,KE70,TE7#..(DV,SED,WG)..RHD |
1 | ||
| 55375 - RETAINER, INSTRUMENT PANEL UNDER TRAY, UPPER | ||||
| 55375-12010 |
AE71,CE70,KE70,TE7#..(DX,GL,GT,SE,SR,XE,XL)..(EUR,GEN,SA,SAA) |
1 | ||
| 55401 - PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH | ||||
| 55410-1261006 |
KE70..RHD..EUG BROWN,BROWN,TRIM4# |
1 | ||
| 55410-1261004 |
KE70..RHD..EUG BLUE,BLUE,TRIM8# |
1 | ||
| 55410-1260006 |
KE70..DX..SA;KE70..SED..RHD..(EUR,GEN) BROWN,BROWN,TRIM4# |
1 | ||
| 55410-1261003 |
KE70..RHD..EUG GRAY,GRAY,TRIM0#,2# |
1 | ||
| 55410-12830 |
KE70..SED..RHD;KE70..WG..RHD..EUG |
1 | ||
| 55404 - SAFETY PAD SUB-ASSY, INSTRUMENT PANEL, UPPER | ||||
| 55401-1209006 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) D-BROWN,BROWN,TRIM4# |
1 | ||
| 55401-1209015 |
TE71..RHD..4D;KE70,TE72..(DX,GL)..SA;KE70..(DV,SED,WG)..RHD..(EUR,GEN) BEIGE,BEIGE,TRIM4# |
1 | ||
| 55401-1209001 |
KE70..STD..SA;KE70,TE71..(DV,SED,WG)..RHD..(ARL,EUR,GEN) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55401-1209004 |
CE70,KE70,TE71..(DV,SED,WG)..RHD..(ARL,EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 55410 - PANEL ASSY, INSTRUMENT CLUSTER FINISH, NO.2 | ||||
| 55413-12250 |
KE70..SED..RHD BLACK |
1 | ||
| 55413-12250 |
KE70..SED..RHD;KE70..WG..RHD..EUG BLACK |
1 | ||
| 55413-12250 |
KE70..SED..RHD..(EUR,GEN) BLACK |
1 | ||
| 55414 - BEZEL, CIGAR LIGHTER HOLE | ||||
| 55477-12050 |
AE71,CE70,KE70,TE7#..DV,SED,WG |
1 | ||
| 55431A - PANEL, INSTRUMENT PANEL FINISH | ||||
| 55431-12050 |
KE70..SED..RHD;KE70..WG..RHD..EUG BLACK |
1 | ||
| 55431-12050 |
KE70..SED..RHD BLACK |
1 | ||
| 55431-12050 |
KE70..SED..RHD..(EUR,GEN) BLACK |
1 | ||
| 55432B - PANEL, INSTRUMENT PANEL FINISH, LOWER | ||||
| 55432-1205015 |
KE70..SED..RHD;KE70..WG..RHD..EUG BEIGE,BEIGE,TRIM4# |
1 | ||
| 55432-1205006 |
KE70..SED..RHD..(EUR,GEN) D-BROWN,BROWN,TRIM4# |
1 | ||
| 55432-1205001 |
KE70..SED..RHD;KE70..(DV,WG)..RHD..(ARL,EUR) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55432-1205004 |
KE70..SED..RHD..(ARL,EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 55449 - COVER, COOLER SWITCH HOLE | ||||
| 55538-12030 |
AE71,CE70,KE70,TE7#..DV,SED,WG W/O AIR CONDITIONER |
1 | ||
| 55453 - COVER, RADIO TUNER OPENING | ||||
| 55522-12060 |
KE70,TE7#..(SED,WG)..RHD..(EUR,SA) |
1 | ||
| 55522-12100 |
KE70,TE71..(DV,SED,WG)..(EUR,GEN,SAA) |
1 | ||
| 55505B - BRACKET, GLOVE COMPARTMENT DOOR LOCK MOUNTING | ||||
| 55378-12060 |
AE71,KE70,TE7#..DV,SED,WG |
1 | ||
| 55506 - BUTTON SUB-ASSY, GLOVE COMPARTMENT DOOR LOCK | ||||
| 55560-1203001 |
KE70,TE7#..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SA,SAA) BLACK |
1 | ||
| 55507 - HINGE SUB-ASSY, GLOVE COMPARTMENT DOOR | ||||
| 55505-12030 |
KE70,TE7#..(SED,WG)..RHD..(DX,GL,XL)..(EUR,GEN,SA) |
1 | ||
| 55510 - DOOR ASSY, GLOVE COMPARTMENT | ||||
| 55550-1219001 |
CE70,KE70,TE71..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SAA) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55550-1219015 |
KE70,TE7#..(SED,WG)..(DX,GL,XL) BEIGE,BEIGE,TRIM4# |
1 | ||
| 55550-1219004 |
CE70,KE70,TE71..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SAA) BLUE,BLUE,TRIM8# |
1 | ||
| 55510 - DOOR ASSY, GLOVE COMPARTMENT | ||||
| 55550-1219001 |
CE70,KE70,TE71..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SAA) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55550-1219015 |
KE70,TE7#..(SED,WG)..(DX,GL,XL) BEIGE,BEIGE,TRIM4# |
1 | ||
| 55550-1219004 |
CE70,KE70,TE71..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SAA) BLUE,BLUE,TRIM8# |
1 | ||
| 55510A - CUSHION(FOR GLOVE COMPARTMENT DOOR) | ||||
| 55557-16010 |
KE70,TE7#..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SA,SAA) |
1 | ||
| 55545 - COVER, FUSE BOX OPENING | ||||
| 55540-1201004 |
KE70,TE71..DV,SED,WG BLUE,BLUE,TRIM8# |
1 | ||
| 55540-1201015 |
KE70,TE71..DV,SED,WG BEIGE,BEIGE,TRIM4# |
1 | ||
| 55545-1201006 |
KE70,TE71..(DV,SED,WG)..(EUR,GEN,SAA) D-BROWN,BROWN,TRIM4# |
1 | ||
| 55540-1201001 |
KE70,TE71..DV,SED,WG BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55590 - PLATE ASSY, GROVE COMPARTMENT DOOR LOCK STRIKER | ||||
| 55590-12010 |
KE70,TE7#..(SED,WG)..(DX,GL,XL)..(EUR,GEN,SA,SAA) |
1 | ||
| 55619B - COVER, SWITCH HOLE, NO.3 | ||||
| 55538-14010 |
KE70..RHD..EUG W/O RR FOG LAMP SWITCH |
1 | ||
| 55633 - SUPPORT, INSTRUMENT PANEL UNDER TRAY, NO.2 | ||||
| 55632-12050 |
AE71,CE70,KE70,TE7# TYPE A |
1 | ||
| 55633 - SUPPORT, INSTRUMENT PANEL UNDER TRAY, NO.2 | ||||
| 55632-12050 |
AE71,CE70,KE70,TE7# TYPE A |
1 | ||
| 55650 - REGISTER ASSY, INSTRUMENT PANEL, NO.1 | ||||
| 55650-1204006 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) D-BROWN,BROWN,TRIM4# |
1 | ||
| 55650-1204001 |
KE70,TE71..(DV,SED,WG)..RHD..(ARL,EUR,GEN) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55650-1204004 |
CE70,KE70,TE71..(DV,SED,WG)..RHD..(ARL,EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 55650-1204015 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) BEIGE,BEIGE,TRIM4# |
1 | ||
| 55651 - REGISTER, INSTRUMENT PANEL, NO.1 | ||||
| 55670-12030 |
KE70..(DV,SED,WG)..EUR |
1 | ||
| 55670-12060 |
KE70,TE71..(DV,SED,WG)..(EUR,GEN,SAA) |
1 | ||
| 55660 - REGISTER ASSY, INSTRUMENT PANEL, NO.2 | ||||
| 55660-1208003 |
KE70..RHD..EUG GRAY,GRAY,TRIM0#,2# |
1 | ||
| 55660-1208004 |
KE70..RHD..EUG BLUE,BLUE,TRIM8# |
1 | ||
| 55660-1208006 |
KE70..RHD..EUG BROWN,BROWN,TRIM4# |
1 | ||
| 55660-1217001 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) BLACK,BLACK,TRIM0#,2# |
1 | ||
| 55660-1217006 |
KE70,TE71..(DV,SED,WG)..RHD..(EUR,GEN) D-BROWN,BROWN,TRIM4# |
1 | ||
| 55691 - BASE, INSTRUMENT PANEL NAME | ||||
| 55512-12080 |
AE71,CE70,KE70,TE7#..DV,SED,WG |
2 | ||
| Common parts | ||||
| 90119-06022 | ||||
| 90119-06104 | ||||
| 90159-50082 | ||||
| 90159-60025 | ||||
| 90179-06019 | ||||
| 90179-06097 | ||||
| 90183-05009 | ||||
| 90183-05094 | ||||
| 90463-05001 | ||||
| 90541-03015 | ||||
| 91666-40616 | ||||
| 93229-54010 | ||||
| 93249-55008 | ||||
| 93540-14010 | ||||
| 93540-15012 | ||||
| 93540-15014 | ||||
| 93540-15016 | ||||
| 93540-55016 | ||||
| 93560-55016 | ||||
| 93567-55016 | ||||
