TE51L-LMQB (1976)
Toyota Corolla/Trueno
(7408-7902)KE50,TE47,51..LHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55074 - COVER SUB-ASSY, COWL INNER HEATER AIR | ||||
| 55077-12020 |
KE30,35,36,50,TE47,51..LHD..GEN W/O HEATER |
1 | ||
| 55701 - PANEL SUB-ASSY, COWL | ||||
| 55700-12070 |
KE50,TE47,51..LHD |
1 | ||
| 55701-12120 |
KE50,TE51..LHD OUTER |
1 | ||
| 55703-12061 |
KE50,TE51..LHD INNER |
1 | ||
| 55781 - LOUVER, COWL VENTILATOR | ||||
| 55711-12060 |
KE50,TE47,51..LHD |
1 | ||
| 55783A - PAD, COWL TOP SILENCER | ||||
| 55783-12060 |
TE47,51..LHD |
1 | ||
| 55791 - WEATHERSTRIP, HOOD TO COWL TOP | ||||
| 53383-12020 |
KE5#,TE47,51..CP,LB |
1 | ||
| 55791B - CLIP(FOR HOOD TO COWL TOP WEATHERSTRIP) | ||||
| 90467-07050 |
KE3#,50,TE3#,47,51 |
8 | ||
| 55792 - COVER, WIPER MOTOR SERVICE HOLE | ||||
| 55071-12010 |
KE5#,TE47,51..CP,LB MOTOR SIDE |
1 | ||
| 55071-20010 |
KE3#,5#,TE3#,47,51 |
3 | ||
| 55908 - NOZZLE SUB-ASSY, DEFROSTER, RH | ||||
| 55091-12010 |
KE3#,5#,TE3#,47,51 |
1 | ||
| 55909 - NOZZLE SUB-ASSY, DEFROSTER, LH | ||||
| 55092-12010 |
KE3#,5#,TE3#,47,51 |
1 | ||
| 55956 - NOZZLE, SIDE DEFROSTER | ||||
| 55962-12020 |
KE50,TE51..LHD LH |
1 | ||
| 55961-12030 |
KE50,TE51..LHD RH |
1 | ||
| 55956 - NOZZLE, SIDE DEFROSTER | ||||
| 55962-12020 |
KE50,TE51..LHD LH |
1 | ||
| 55961-12030 |
KE50,TE51..LHD RH |
1 | ||
| 55956 - NOZZLE, SIDE DEFROSTER | ||||
| 55962-12020 |
KE50,TE51..LHD LH |
1 | ||
| 55961-12030 |
KE50,TE51..LHD RH |
1 | ||
| 55956 - NOZZLE, SIDE DEFROSTER | ||||
| 55962-12020 |
KE50,TE51..LHD LH |
1 | ||
| 55961-12030 |
KE50,TE51..LHD RH |
1 | ||
| 56111 - GLASS, WINDSHIELD | ||||
| 56111-12240 |
KE50,TE47,51..EUR,GEN *TL,T=5.7 |
1 | ||
| 56111-12380 |
KE50,TE47,51 *TL,T=5.7 |
1 | ||
| 56111-12230 |
KE50,TE47,51..GEN *TZT,T=5.0 |
1 | ||
| 56121 - WEATHERSTRIP, WINDSHIELD | ||||
| 56121-12180 |
KE5#,TE47,51..CP,LB |
1 | ||
| Common parts | ||||
| 90159-60025 | ||||
| 90179-06097 | ||||
| 91666-40618 | ||||
| 93540-14008 | ||||
| 93540-14014 | ||||
| 93540-15014 | ||||
| Linked diagrams | ||||
| 8715 | ||||
(7902-7908)KE50,TE51..LHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55074 - COVER SUB-ASSY, COWL INNER HEATER AIR | ||||
| 55077-12020 |
KE30,35,36,50,TE47,51..LHD..GEN W/O HEATER |
1 | ||
| 55701 - PANEL SUB-ASSY, COWL | ||||
| 55700-12070 |
KE50,TE47,51..LHD |
1 | ||
| 55701-12120 |
KE50,TE51..LHD OUTER |
1 | ||
| 55703-12061 |
KE50,TE51..LHD INNER |
1 | ||
| 55701 - PANEL SUB-ASSY, COWL | ||||
| 55700-12070 |
KE50,TE47,51..LHD |
1 | ||
| 55701-12120 |
KE50,TE51..LHD OUTER |
1 | ||
| 55703-12061 |
KE50,TE51..LHD INNER |
1 | ||
| 55781 - LOUVER, COWL VENTILATOR | ||||
| 55711-12060 |
KE50,TE47,51..LHD |
1 | ||
| 55783A - PAD, COWL TOP SILENCER | ||||
| 55783-12060 |
TE47,51..LHD |
1 | ||
| 55791 - WEATHERSTRIP, HOOD TO COWL TOP | ||||
| 53383-12020 |
KE5#,TE47,51..CP,LB |
1 | ||
| 55791B - CLIP(FOR HOOD TO COWL TOP WEATHERSTRIP) | ||||
| 90467-07050 |
KE3#,50,TE3#,47,51 |
8 | ||
| 55792 - COVER, WIPER MOTOR SERVICE HOLE | ||||
| 55071-12010 |
KE5#,TE47,51..CP,LB MOTOR SIDE |
1 | ||
| 55071-20010 |
KE3#,5#,TE3#,47,51 |
3 | ||
| 55908 - NOZZLE SUB-ASSY, DEFROSTER, RH | ||||
| 55091-12010 |
KE3#,5#,TE3#,47,51 |
1 | ||
| 55909 - NOZZLE SUB-ASSY, DEFROSTER, LH | ||||
| 55092-12010 |
KE3#,5#,TE3#,47,51 |
1 | ||
| 55956 - NOZZLE, SIDE DEFROSTER | ||||
| 55962-12020 |
KE50,TE51..LHD LH |
1 | ||
| 55961-12030 |
KE50,TE51..LHD RH |
1 | ||
| 55956 - NOZZLE, SIDE DEFROSTER | ||||
| 55962-12020 |
KE50,TE51..LHD LH |
1 | ||
| 55961-12030 |
KE50,TE51..LHD RH |
1 | ||
| 56111 - GLASS, WINDSHIELD | ||||
| 56111-12240 |
KE50,TE47,51..EUR,GEN *TL,T=5.7 |
1 | ||
| 56111-12380 |
KE50,TE47,51 *TL,T=5.7 |
1 | ||
| 56111-12230 |
KE50,TE47,51..GEN *TZT,T=5.0 |
1 | ||
| 56121 - WEATHERSTRIP, WINDSHIELD | ||||
| 56121-12180 |
KE5#,TE47,51..CP,LB |
1 | ||
| Common parts | ||||
| 90159-60025 | ||||
| 90179-06097 | ||||
| 93540-14014 | ||||
| 93540-15014 | ||||
| Linked diagrams | ||||
| 8715 | ||||
