TE51L-LMQB (1976)
Toyota Corolla/Trueno
(7408-8004)2TB
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-25050 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-26014 |
2TB..TE47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700-26021 |
2TB..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE31,47,51..GEN,SA W/O HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE3#,47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700B - WASHER, SEAL(FOR AIR CLEANER) | ||||
| 90210-06023 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700B - WASHER, SEAL(FOR AIR CLEANER) | ||||
| 90210-06023 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06142 |
2T..TE3#,47,51 L=88,S=12&25 |
1 | ||
| 90116-06230 |
2TB..TE47,51 FR,L=74,S=12&25 |
1 | ||
| 90116-06142 |
2TB..TE47,51 RR,L=88,S=12&25 |
1 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06142 |
2T..TE3#,47,51 L=88,S=12&25 |
1 | ||
| 90116-06230 |
2TB..TE47,51 FR,L=74,S=12&25 |
1 | ||
| 90116-06142 |
2TB..TE47,51 RR,L=88,S=12&25 |
1 | ||
| 17705 - CAP SUB-ASSY, AIR CLEANER | ||||
| 17705-25030 |
2T..TE3#,47,51 |
1 | ||
| 17705-26011 |
2TB..TE3#,47,51 |
1 | ||
| 17706 - INLET SUB-ASSY, AIR CLEANER, NO.2 | ||||
| 17752-25010 |
2T,2TB..TE3#,47,51 W/HOT AIR INTAKE |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-24020 |
2TB..TE3#,47,51 |
2 | ||
| 17801-31010 |
2T..TE3#,47,51 |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-24020 |
2TB..TE3#,47,51 |
2 | ||
| 17801-31010 |
2T..TE3#,47,51 |
1 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17845 - GASKET, AIR CLEANER CAP | ||||
| 17845-26010 |
2TB..TE3#,47,51 |
1 | ||
| 17845-25010 |
2T..TE3#,47,51 |
1 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17881 - HOSE, AIR CLEANER, NO.1 | ||||
| 17881-26010 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17881-26020 |
2TB..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1) | ||||
| 90460-47036 |
2T,2TB..TE47,51 W/HOT AIR INTAKE |
2 | ||
| 17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1) | ||||
| 90460-47036 |
2T,2TB..TE47,51 W/HOT AIR INTAKE |
2 | ||
| Common parts | ||||
| 91611-40812 | ||||
| Linked diagrams | ||||
| 1709 | ||||
(7408-8004)2T
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-25050 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-26014 |
2TB..TE47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700-26021 |
2TB..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE31,47,51..GEN,SA W/O HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE3#,47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700B - WASHER, SEAL(FOR AIR CLEANER) | ||||
| 90210-06023 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06142 |
2T..TE3#,47,51 L=88,S=12&25 |
1 | ||
| 90116-06230 |
2TB..TE47,51 FR,L=74,S=12&25 |
1 | ||
| 90116-06142 |
2TB..TE47,51 RR,L=88,S=12&25 |
1 | ||
| 17705 - CAP SUB-ASSY, AIR CLEANER | ||||
| 17705-25030 |
2T..TE3#,47,51 |
1 | ||
| 17705-26011 |
2TB..TE3#,47,51 |
1 | ||
| 17706 - INLET SUB-ASSY, AIR CLEANER, NO.2 | ||||
| 17752-25010 |
2T,2TB..TE3#,47,51 W/HOT AIR INTAKE |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-24020 |
2TB..TE3#,47,51 |
2 | ||
| 17801-31010 |
2T..TE3#,47,51 |
1 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17845 - GASKET, AIR CLEANER CAP | ||||
| 17845-26010 |
2TB..TE3#,47,51 |
1 | ||
| 17845-25010 |
2T..TE3#,47,51 |
1 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17881 - HOSE, AIR CLEANER, NO.1 | ||||
| 17881-26010 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17881-26020 |
2TB..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1) | ||||
| 90460-47036 |
2T,2TB..TE47,51 W/HOT AIR INTAKE |
2 | ||
| 17881A - CLAMP(FOR AIR CLEANER HOSE, NO.1) | ||||
| 90460-47036 |
2T,2TB..TE47,51 W/HOT AIR INTAKE |
2 | ||
| Common parts | ||||
| 91611-40812 | ||||
| 91631-40620 | ||||
| Linked diagrams | ||||
| 1709 | ||||
(7408-8004)2T
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-25050 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-26014 |
2TB..TE47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700-26021 |
2TB..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE31,47,51..GEN,SA W/O HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE3#,47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700B - WASHER, SEAL(FOR AIR CLEANER) | ||||
| 90210-06023 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06142 |
2T..TE3#,47,51 L=88,S=12&25 |
1 | ||
| 90116-06230 |
2TB..TE47,51 FR,L=74,S=12&25 |
1 | ||
| 90116-06142 |
2TB..TE47,51 RR,L=88,S=12&25 |
1 | ||
| 17705 - CAP SUB-ASSY, AIR CLEANER | ||||
| 17705-25030 |
2T..TE3#,47,51 |
1 | ||
| 17705-26011 |
2TB..TE3#,47,51 |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-24020 |
2TB..TE3#,47,51 |
2 | ||
| 17801-31010 |
2T..TE3#,47,51 |
1 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17845 - GASKET, AIR CLEANER CAP | ||||
| 17845-26010 |
2TB..TE3#,47,51 |
1 | ||
| 17845-25010 |
2T..TE3#,47,51 |
1 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
2T,2TB..TE3#,47,51 |
2 | ||
| Common parts | ||||
| 91631-40620 | ||||
| Linked diagrams | ||||
| 1709 | ||||
(7408-8004)2TB
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17700 - CLEANER ASSY, AIR | ||||
| 17700-25050 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-26014 |
2TB..TE47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700-26021 |
2TB..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE31,47,51..GEN,SA W/O HOT AIR INTAKE |
1 | ||
| 17700-25060 |
2T..TE3#,47,51 W/O HOT AIR INTAKE |
1 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700A - NUT, WING(FOR AIR CLEANER) | ||||
| 94271-00600 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700B - WASHER, SEAL(FOR AIR CLEANER) | ||||
| 90210-06023 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700B - WASHER, SEAL(FOR AIR CLEANER) | ||||
| 90210-06023 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06142 |
2T..TE3#,47,51 L=88,S=12&25 |
1 | ||
| 90116-06230 |
2TB..TE47,51 FR,L=74,S=12&25 |
1 | ||
| 90116-06142 |
2TB..TE47,51 RR,L=88,S=12&25 |
1 | ||
| 17700F - BOLT, STUD(FOR AIR CLEANER SETTING) | ||||
| 90116-06142 |
2T..TE3#,47,51 L=88,S=12&25 |
1 | ||
| 90116-06230 |
2TB..TE47,51 FR,L=74,S=12&25 |
1 | ||
| 90116-06142 |
2TB..TE47,51 RR,L=88,S=12&25 |
1 | ||
| 17705 - CAP SUB-ASSY, AIR CLEANER | ||||
| 17705-25030 |
2T..TE3#,47,51 |
1 | ||
| 17705-26011 |
2TB..TE3#,47,51 |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-24020 |
2TB..TE3#,47,51 |
2 | ||
| 17801-31010 |
2T..TE3#,47,51 |
1 | ||
| 17801 - ELEMENT SUB-ASSY, AIR CLEANER FILTER | ||||
| 17801-24020 |
2TB..TE3#,47,51 |
2 | ||
| 17801-31010 |
2T..TE3#,47,51 |
1 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17841 - GASKET, FILTER ELEMENT | ||||
| 17841-25010 |
2T..TE3#,47,51 |
2 | ||
| 17841-24011 |
2TB..TE3#,47,51 |
4 | ||
| 17845 - GASKET, AIR CLEANER CAP | ||||
| 17845-26010 |
2TB..TE3#,47,51 |
1 | ||
| 17845-25010 |
2T..TE3#,47,51 |
1 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
2T,2TB..TE3#,47,51 |
2 | ||
| 17848 - GASKET, AIR CLEANER TO CARBURETOR | ||||
| 90430-63187 |
2T,2TB..TE3#,47,51 |
2 | ||
| Linked diagrams | ||||
| 1709 | ||||
