TE47L-MQZG (1974)
Toyota Corolla/Trueno
(7408-7511)2T
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16265 - HOSE, INTAKE MANIFOLD WATER | ||||
| 90445-21611 |
2T..TE3#,47,51 |
1 | ||
| 16265A - CLAMP OR CLIP, HOSE(FOR INTAKE MANIFOLD WATER) | ||||
| 96111-10220 |
2T,2TB..TE3#,47,51 |
2 | ||
| 16265A - CLAMP OR CLIP, HOSE(FOR INTAKE MANIFOLD WATER) | ||||
| 96111-10220 |
2T,2TB..TE3#,47,51 |
2 | ||
| 16305 - OUTLET SUB-ASSY, WATER BY-PASS | ||||
| 16305-25011 |
2T..TE3#,47,51 |
1 | ||
| 16347 - GASKET, WATER BY-PASS | ||||
| 16347-25011 |
2T..TE3#,47,51 |
1 | ||
| 17110B - UNION(FOR VENTILATION HOSE TO MANIFOLD) | ||||
| 90407-09001 |
2T..TE3#,47 |
1 | ||
| 90407-09045 |
2T,2TB..TE3#,47 |
1 | ||
| 17111 - MANIFOLD, INTAKE | ||||
| 17101-25903 |
2T..TE47 |
1 | ||
| 17111-26050 |
2T..TE47,51 |
1 | ||
| 17101-88220 |
2TG..TE47 |
1 | ||
| 17111-26051 |
2T..TE47,51 |
1 | ||
| 17111-88220 |
2TG..TE47 |
1 | ||
| 17111-26020 |
2T..TE47 |
1 | ||
| 17111A - PLUG, NO.1 | ||||
| 90345-51005 |
2T,2TB..TE3#,47,51 |
3 | ||
| 90072-34107 |
2T#..TE3#,47 |
2 | ||
| 90072-34107 |
2TG..TE47 |
1 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17104-25010 |
2T..TE3#,47 |
1 | ||
| 17141-26050 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17141-26010 |
2TB,2TG..TE47 |
1 | ||
| 17141-26010 |
2TG..TE47 |
1 | ||
| 17141-26011 |
2T#..TE3#,47,51 |
1 | ||
| 17141-26010 |
2T#..TE3#,47,51 |
1 | ||
| 17141-26011 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17151 - BOLT, STUD(FOR MANIFOLD TO CARBURETOR) | ||||
| 90116-08023 |
2T..TE47,51 L=41,S=14&14 |
4 | ||
| 90116-08110 |
2TG..TE47 L=43,S=12&12 |
8 | ||
| 90116-08010 |
2T..TE3#,47 L=39,S=13&13 |
8 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 92122-41022 |
2TG..TE47 L=37,S=15&15 |
3 | ||
| 90116-10007 |
2T#..TE3#,47,51 L=41,S=14&21 |
3 | ||
| 90116-10007 |
2T#..TE3#,47,51 L=41,S=14&21 |
3 | ||
| 92122-41022 |
2T#..TE3#,47 L=37,S=15&15 |
3 | ||
| 17153A - UNION(FOR AUTOMATIC CHOKE STOVE PIPE) | ||||
| 90402-18062 |
2T..TE3#,47 |
1 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08015 |
2T#..TE3#,47,51 L=37,S=13.5&13.5 |
12 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
7 | ||
| 90116-08201 |
2TG..TE47 L=37.4,S=13.7&13.7 |
5 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
4 | ||
| 90116-08002 |
2T,2TB..TE3#,47,51 L=37,S=13.5&13.5 |
4 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08015 |
2T#..TE3#,47,51 L=37,S=13.5&13.5 |
12 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
7 | ||
| 90116-08201 |
2TG..TE47 L=37.4,S=13.7&13.7 |
5 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
4 | ||
| 90116-08002 |
2T,2TB..TE3#,47,51 L=37,S=13.5&13.5 |
4 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-25010 |
2T#..TE3#,47,51 |
1 | ||
| 17173-25010 |
2TG..TE47 |
1 | ||
| 17173-25011 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17173-25011 |
2T#..TE3#,47,51 |
1 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-25020 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17177-88220 |
2TG..TE47 |
1 | ||
| 17177-25010 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17205 - PIPE, AUTOMATIC CHOKE STOVE INLET | ||||
| 17253-25010 |
2T..TE3#,47 |
1 | ||
| 17205A - HOSE(FOR AUTOMATIC CHOKE STOVE PIPE) | ||||
| 90445-11530 |
2T..TE3#,47 |
1 | ||
| 17205F - CLAMP(FOR AUTOMATIC CHOKE STOVE INLET PIPE) | ||||
| 90461-06896 |
2T..TE3#,47 |
1 | ||
| 17205G - CLAMP, NO.2(FOR AUTOMATIC CHOKE STOVE INLET PIPE) | ||||
| 90461-06895 |
2T..TE3#,47 |
1 | ||
| 17206 - PIPE, AUTOMATIC CHOKE STOVE OUTLET | ||||
| 17206-25010 |
2T..TE3#,47 |
1 | ||
| 17206A - CLAMP(FOR AUTOMATIC CHOKE STOVE OUTLET PIPE) | ||||
| 90461-05569 |
2T..TE3#,47 |
1 | ||
| 17251 - PIPE,AUTOMATIC CHOKE STOVE | ||||
| 17204-25010 |
2T..TE3#,47 |
1 | ||
| Common parts | ||||
| 90170-08046 | ||||
| 90461-05006 | ||||
| 91611-40825 | ||||
| 91621-40825 | ||||
| 91651-40816 | ||||
| 94110-40800 | ||||
| 94611-10800 | ||||
(7408-7902)2TG
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17111 - MANIFOLD, INTAKE | ||||
| 17101-25903 |
2T..TE47 |
1 | ||
| 17111-26050 |
2T..TE47,51 |
1 | ||
| 17101-88220 |
2TG..TE47 |
1 | ||
| 17111-26051 |
2T..TE47,51 |
1 | ||
| 17111-88220 |
2TG..TE47 |
1 | ||
| 17111-26020 |
2T..TE47 |
1 | ||
| 17111A - PLUG, NO.1 | ||||
| 90345-51005 |
2T,2TB..TE3#,47,51 |
3 | ||
| 90072-34107 |
2T#..TE3#,47 |
2 | ||
| 90072-34107 |
2TG..TE47 |
1 | ||
| 17111B - PLUG, NO.2 | ||||
| 90344-53011 |
2TG..TE47 |
2 | ||
| 17111U - UNION(FOR VACUUM SWITCHING VALVE) | ||||
| 90404-51093 |
2TG..TE47 EUROPE SPEC |
1 | ||
| 90404-51093 |
2TG..TE47 |
1 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-26010 |
2TB,2TG..TE47 |
1 | ||
| 17104-25010 |
2T..TE3#,47 |
1 | ||
| 17141-26050 |
2T..TE47,51 W/HOT AIR INTAKE |
1 | ||
| 17141-26010 |
2TG..TE47 |
1 | ||
| 17141-26011 |
2T#..TE3#,47,51 |
1 | ||
| 17141-26010 |
2T#..TE3#,47,51 |
1 | ||
| 17141-26011 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17151 - BOLT, STUD(FOR MANIFOLD TO CARBURETOR) | ||||
| 90116-08023 |
2T..TE47,51 L=41,S=14&14 |
4 | ||
| 90116-08110 |
2TG..TE47 L=43,S=12&12 |
8 | ||
| 90116-08010 |
2T..TE3#,47 L=39,S=13&13 |
8 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 92122-41022 |
2TG..TE47 L=37,S=15&15 |
3 | ||
| 90116-10007 |
2T#..TE3#,47,51 L=41,S=14&21 |
3 | ||
| 90116-10007 |
2T#..TE3#,47,51 L=41,S=14&21 |
3 | ||
| 92122-41022 |
2T#..TE3#,47 L=37,S=15&15 |
3 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08015 |
2T#..TE3#,47,51 L=37,S=13.5&13.5 |
12 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
7 | ||
| 90116-08201 |
2TG..TE47 L=37.4,S=13.7&13.7 |
5 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
4 | ||
| 90116-08002 |
2T,2TB..TE3#,47,51 L=37,S=13.5&13.5 |
4 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08015 |
2T#..TE3#,47,51 L=37,S=13.5&13.5 |
12 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
7 | ||
| 90116-08201 |
2TG..TE47 L=37.4,S=13.7&13.7 |
5 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
4 | ||
| 90116-08002 |
2T,2TB..TE3#,47,51 L=37,S=13.5&13.5 |
4 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08015 |
2T#..TE3#,47,51 L=37,S=13.5&13.5 |
12 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
7 | ||
| 90116-08201 |
2TG..TE47 L=37.4,S=13.7&13.7 |
5 | ||
| 90116-08015 |
2TG..TE47 L=37,S=13.5&13.5 |
4 | ||
| 90116-08002 |
2T,2TB..TE3#,47,51 L=37,S=13.5&13.5 |
4 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-25010 |
2T#..TE3#,47,51 |
1 | ||
| 17173-25010 |
2TG..TE47 |
1 | ||
| 17173-25011 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17173-25011 |
2T#..TE3#,47,51 |
1 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-25020 |
2T,2TB..TE3#,47,51 |
1 | ||
| 17177-88220 |
2TG..TE47 |
1 | ||
| 17177-25010 |
2T,2TB..TE3#,47,51 |
1 | ||
| Common parts | ||||
| 90170-08046 | ||||
| 90179-08146 | ||||
| 90201-08084 | ||||
| 91611-40825 | ||||
| 94110-40800 | ||||
| 94531-00800 | ||||
| Linked diagrams | ||||
| 1708 | ||||
