NZE161R-AEXNK (2012)
Toyota Corolla/Axio
(1212- )4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-12G30B1 |
NZE161..4D..N LT.GRAY,TRIM21 |
1 | ||
| 71075-12G50A0 |
NZE161..E IVORY,TRIM20 |
1 | ||
| 71075-12G50B2 |
NZE161..E LT.GRAY,TRIM21 |
1 | ||
| 71075-12G30A1 |
NZE161..4D..N IVORY,TRIM20 |
1 | ||
| 71075-12G50A2 |
NZE161..E IVORY,TRIM20 |
1 | ||
| 71075-12G30A0 |
NZE161..4D..N IVORY,TRIM20 |
1 | ||
| 71075-12G31A2 |
NZE161..4D..N BEIGE,TRIM20 |
1 | ||
| 71075-12G50B4 |
NZE161..E LT.GRAY,TRIM21 |
1 | ||
| 71075-12G31B3 |
NZE161..4D..N LT.GRAY,TRIM21 |
1 | ||
| 71075-12G30B2 |
NZE161..4D..N LT.GRAY,TRIM21 |
1 | ||
| 71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE) | ||||
| 71077-12Q41A4 |
NZE161..E IVORY,TRIM20 |
1 | ||
| 71077-12Q41B5 |
NZE161..E LT.GRAY,TRIM21 |
1 | ||
| 71077-12Q91A4 |
NZE161..4D..N IVORY,TRIM20 |
1 | ||
| 71077-12Q91B3 |
NZE161..4D..N LT.GRAY,TRIM21 |
1 | ||
| 71077-12Q92B6 |
NZE161..4D..N LT.GRAY,TRIM21 |
1 | ||
| 71077-12Q91A3 |
NZE161..4D..N IVORY,TRIM20 |
1 | ||
| 71077-12Q41A5 |
NZE161..E IVORY,TRIM20 |
1 | ||
| 71077-12Q91B4 |
NZE161..4D..N LT.GRAY,TRIM21 |
1 | ||
| 71077-12Q41B6 |
NZE161..E LT.GRAY,TRIM21 |
1 | ||
| 71077-12Q92A6 |
NZE161..4D..N BEIGE,TRIM20 |
1 | ||
| 71281A - HINGE, REAR SEAT CENTER ARMREST | ||||
| 71281-12070 |
NZE161..E |
1 | ||
| 71398A - HOLDER, REAR SEAT BACK | ||||
| 71398-33010C0 |
NZE161..4D BLACK |
2 | ||
| 71398A - HOLDER, REAR SEAT BACK | ||||
| 71398-33010C0 |
NZE161..4D BLACK |
2 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71503-12240 |
NZE161..4D |
1 | ||
| 71651B - PAD, REAR SEAT BACK(FOR BENCH TYPE) | ||||
| 71507-12351 |
NZE161..4D..N |
1 | ||
| 71507-12341 |
NZE161..E |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-42020A0 |
NZE161..E W(LOCK)&W/O(BUTTON),IVORY,TRIM20 |
1 | ||
| 71931-42020P0 |
NZE161..E W(LOCK)&W/O(BUTTON),DK.CHARCOAL,TRIM21 |
1 | ||
| 71930-52030A0 |
NZE161..E W(LOCK)&W(BUTTON),IVORY,TRIM20 |
1 | ||
| 71930-52030B9 |
NZE161..E W(LOCK)&W(BUTTON),DK.CHARCOAL,TRIM21 |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-42020A0 |
NZE161..E W(LOCK)&W/O(BUTTON),IVORY,TRIM20 |
1 | ||
| 71931-42020P0 |
NZE161..E W(LOCK)&W/O(BUTTON),DK.CHARCOAL,TRIM21 |
1 | ||
| 71930-52030A0 |
NZE161..E W(LOCK)&W(BUTTON),IVORY,TRIM20 |
1 | ||
| 71930-52030B9 |
NZE161..E W(LOCK)&W(BUTTON),DK.CHARCOAL,TRIM21 |
1 | ||
| 71960B - HEADREST ASSY, REAR SEAT, CENTER | ||||
| 71960-12860B4 |
NZE161..E DK.GRAY,TRIM21 |
1 | ||
| 71960-12860A2 |
NZE161..E BEIGE,TRIM20 |
1 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
NZE161 |
2 | ||
| 72830 - ARMREST ASSY, REAR SEAT, CENTER | ||||
| 72830-12840A0 |
NZE161..E BEIGE,TRIM20 |
1 | ||
| 72830-12840B1 |
NZE161..E DK.GRAY,TRIM21 |
1 | ||
| 72868B - COVER, CENTER ARMREST HINGE | ||||
| 72868-12060A0 |
NZE161..E IVORY,TRIM20 |
1 | ||
| 72868-12060B0 |
NZE161..E DK.CHARCOAL,TRIM21 |
1 | ||
| 73705B - BRACKET SUB-ASSY, CROSS ANCHOR | ||||
| 73705-13020 |
NZE161..4D |
1 | ||
| 79956 - COVER, REAR SEAT LEG BRACKET | ||||
| 79957-12010 |
NZE161 |
2 | ||
| 79956 - COVER, REAR SEAT LEG BRACKET | ||||
| 79957-12010 |
NZE161 |
2 | ||
| Common parts | ||||
| 90109-08163 | ||||
| 90119-08C37 | ||||
| 90119-10409 | ||||
| 90206-10016 | ||||
| 90386-10033 | ||||
| 94150-80800 | ||||
| Linked diagrams | ||||
| 7104 | ||||
