ZZE122R-AEMNK (2001)
Toyota Corolla/Altis Sed/Wg
(0008- )RHD..SED
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 64127B - SUPPORT, LUGGAGE COMPARTMENT DOOR TORSION BAR | ||||
| 64127-33041 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 64127-33041 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64127-33041 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64401 - PANEL SUB-ASSY, LUGGAGE COMPARTMENT DOOR | ||||
| 64401-1A810 |
ZZE122..SED..(GCC,GEN);CE120,NZE12#,ZZE121..GEN LICENSE PLATE(330 X 165) & W(REAR SPOILER) |
1 | ||
| 64401-1E060 |
ZZE122..SED..(GCC,GEN);CE120,NZE12#,ZZE121..GEN LICENSE PLATE(330 X 165) & W(REAR SPOILER) |
1 | ||
| 64401-1A800 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 64401-1E050 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 64401-1A840 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..(ARL,GEN) LICENSE PLATE(520 X 120) |
1 | ||
| 64401-1A840 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) |
1 | ||
| 64401-1A880 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) & W(REAR SPOILER) |
1 | ||
| 64401-1A880 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) & W(REAR SPOILER) |
1 | ||
| 64401-12A10 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 64401-12A20 |
ZZE122..SED..(GCC,GEN);CE120,NZE12#,ZZE121..GEN LICENSE PLATE(330 X 165) & W(REAR SPOILER) |
1 | ||
| 64401-1A840 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) |
1 | ||
| 64401-1A880 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..(ARL,GEN) LICENSE PLATE(520 X 120) & W(REAR SPOILER) |
1 | ||
| 64455 - CUSHION, LUGGAGE COMPARTMENT DOOR SIDE, RH | ||||
| 64455-12010 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64455-12010 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64456 - CUSHION, LUGGAGE COMPARTMENT DOOR SIDE, LH | ||||
| 64456-12010 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64456-12010 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64461 - WEATHERSTRIP, LUGGAGE COMPARTMENT DOOR | ||||
| 64461-12540 |
NZE12#,ZZE12#..SED |
1 | ||
| 64461-12542 |
NZE120,ZZE122..SED..GCC;CE120,NZE12#,ZZE12#..RHD..SED..GEN |
1 | ||
| 64461-12542 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64503 - ARM SUB-ASSY, LUGGAGE COMPARTMENT DOOR HINGE, RH | ||||
| 64503-12150 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64503-12150 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64503-12150 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 64504 - ARM SUB-ASSY, LUGGAGE COMPARTMENT DOOR HINGE, LH | ||||
| 64503-12150 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64503-12150 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 64503-12150 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64511 - SUPPORT, LUGGAGE COMPARTMENT DOOR HINGE, RH | ||||
| 64511-12270 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 64511-12270 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64511-12270 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64512 - SUPPORT, LUGGAGE COMPARTMENT DOOR HINGE, LH | ||||
| 64511-12270 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 64511-12270 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64511-12270 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64531 - BAR, LUGGAGE DOOR HINGE TORSION, RH | ||||
| 64531-12660 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64531-12670 |
ZZE122..SED;CE120,NZE12#,ZZE121..GEN W(REAR SPOILER) |
1 | ||
| 64531-12740 |
ZZE122..SED..GCC;CE120,NZE12#,ZZE12#..RHD..SED..GEN W(REAR SPOILER) |
1 | ||
| 64531-12660 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) |
1 | ||
| 64531-12760 |
ZZE122..SED..(GCC,GEN);CE120,NZE12#,ZZE121..GEN LICENSE PLATE(330 X 165) & W(REAR SPOILER) |
1 | ||
| 64531-12750 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 64531-12740 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) & W(REAR SPOILER) |
1 | ||
| 64532 - BAR, LUGGAGE DOOR HINGE TORSION, LH | ||||
| 64532-12660 |
ZZE122..SED;CE120,NZE12#,ZZE121..GEN W(REAR SPOILER) |
1 | ||
| 64532-12650 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64532-12650 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) |
1 | ||
| 64532-12750 |
ZZE122..SED..(GCC,GEN);CE120,NZE12#,ZZE121..GEN LICENSE PLATE(330 X 165) & W(REAR SPOILER) |
1 | ||
| 64532-12740 |
ZZE122..SED..GCC;CE120,NZE12#,ZZE12#..RHD..SED..GEN W(REAR SPOILER) |
1 | ||
| 64532-12740 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) & W(REAR SPOILER) |
1 | ||
| 64532-12670 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 64559 - PIN, LUGGAGE DOOR HINGE | ||||
| 64559-12040 |
CE120,NZE12#,ZZE12#..SED |
2 | ||
| 64559-12040 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
2 | ||
| 64559-12040 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
2 | ||
| 64559 - PIN, LUGGAGE DOOR HINGE | ||||
| 64559-12040 |
CE120,NZE12#,ZZE12#..SED |
2 | ||
| 64559-12040 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
2 | ||
| 64559-12040 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
2 | ||
| 64607 - CABLE SUB-ASSY, LUGGAGE DOOR LOCK CONTROL | ||||
| 64607-12790 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64607-12790 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64610 - LOCK ASSY, LUGGAGE COMPARTMENT DOOR | ||||
| 64610-12350 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 64610-12350 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64610-12350 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) |
1 | ||
| 64610-12370 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 64610B - SPRING, TENSION(FOR LOCK) | ||||
| 90506-06010 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) WD=0.55,CW=16.75 |
1 | ||
| 90506-05002 |
CE120,NZE12#,ZZE12#..SED WD=0.55,CW=17.25 |
1 | ||
| 90506-06010 |
CE120,NZE12#,ZZE12#..SED WD=0.55,CW=16.75 |
1 | ||
| 64610B - SPRING, TENSION(FOR LOCK) | ||||
| 90506-06010 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) WD=0.55,CW=16.75 |
1 | ||
| 90506-05002 |
CE120,NZE12#,ZZE12#..SED WD=0.55,CW=17.25 |
1 | ||
| 90506-06010 |
CE120,NZE12#,ZZE12#..SED WD=0.55,CW=16.75 |
1 | ||
| 64621B - STRIKER, LUGGAGE COMPARTMENT DOOR LOCK | ||||
| 64621-12070 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 64621-12070 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64631 - PROTECTOR, LUGGAGE DOOR LOCK | ||||
| 64631-12050 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) |
1 | ||
| 64631-12050 |
CE120,NZE12#,ZZE12#..SED |
1 | ||
| 69759P - SNAP, DOOR LOCK CONTROL LINK | ||||
| 69759-24050 |
CE120,NZE12#,ZZE12#..SED..(ARL,GCC,GEN) |
1 | ||
| 69759-24050 |
NZE121..LX;CE120,NZE120,ZZE12#..SED..GEN LICENSE PLATE(520 X 120) |
1 | ||
| 69759-24010 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN) LICENSE PLATE(330 X 165) |
1 | ||
| 75129B - CUSHION, REAR LICENCE PLATE | ||||
| 75129-13020 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN,PKN) |
2 | ||
| 75129-13020 |
CE120,NZE12#,ZZE12#..SED..(GCC,GEN,PKN) |
2 | ||
| Common parts | ||||
| 82711-16790 | ||||
| 82711-1E300 | ||||
| 82711-1E600 | ||||
| 90105-06168 | ||||
| 90109-T0021 | ||||
| 90119-06779 | ||||
| 90469-01009 | ||||
| 90469-06005 | ||||
| 90959-01369 | ||||
| 91631-B0630 | ||||
| Linked diagrams | ||||
| 7701 | ||||
