ZZE142R-GEPGKX (2008)
Toyota Corolla/Altis
(0712- )ZRE141,142,ZZE14#..4FC
U340E,U341E
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32000 - CONVERTER ASSY, TORQUE | ||||
| 32000-52052 |
ZZE142..4FC..IND |
1 | ||
| 32101 - GEAR SUB-ASSY, DRIVE PLATE & RING | ||||
| 32101-12100 |
ZRE141,142..4FC |
1 | ||
| 32101-12091 |
ZZE142..4FC..IND |
1 | ||
| 32101A - BOLT(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90119-T0069 |
ZZE14#..4FC *8-1.25PX12-8,CLEAR,(L) |
5 | ||
| 90109-08107 |
ZZE14#..4FC *8-1.25PX12-8.4,BLACK |
1 | ||
| 90119-08269 |
ZZE14#..4FC *8-1.25PX12-8,CLEAR,(J) |
5 | ||
| 90109-08113 |
ZZE142..4FC..IND *8-1.25PX12-8.4,BLACK |
1 | ||
| 90109-08113 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) *8-1.25PX12-8.4,BLACK |
1 | ||
| 90119-08498 |
ZZE142..4FC..IND *8-1.25PX12-8,CLEAR |
5 | ||
| 90119-08498 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) *8-1.25PX12-8,YELLOW |
5 | ||
| 32101A - BOLT(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90119-T0069 |
ZZE14#..4FC *8-1.25PX12-8,CLEAR,(L) |
5 | ||
| 90109-08107 |
ZZE14#..4FC *8-1.25PX12-8.4,BLACK |
1 | ||
| 90119-08269 |
ZZE14#..4FC *8-1.25PX12-8,CLEAR,(J) |
5 | ||
| 90109-08113 |
ZZE142..4FC..IND *8-1.25PX12-8.4,BLACK |
1 | ||
| 90109-08113 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) *8-1.25PX12-8.4,BLACK |
1 | ||
| 90119-08498 |
ZZE142..4FC..IND *8-1.25PX12-8,CLEAR |
5 | ||
| 90119-08498 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) *8-1.25PX12-8,YELLOW |
5 | ||
| 32101C - BOLT, HEXAGON(FOR DRIVE PLATE SETTING) | ||||
| 90105-10048 |
ZRE143;ZZE142..18V..IND;ZZE142..(18E,18J)..TAIW;ZZE14#..4FC..(16E,16G,16J,16V,18E,18G,ALT,GLI,XLI)..(GCC,IDN,IND,MA,PHL,PKN,TH,VN) *10-1.25PX18-13,(J) |
8 | ||
| 90105-10048 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) *10-1.25PX18-13 |
8 | ||
| 90105-10048 |
ZZE142..4FC..IND *10-1.25PX18-13 |
8 | ||
| 90105-A0022 |
ZRE143;ZZE142..18V..IND;ZZE142..(18E,18J)..TAIW;ZZE14#..4FC..(16E,16G,16J,16V,18E,18G,ALT,GLI,XLI)..(GCC,IDN,IND,MA,PHL,PKN,TH,VN) *10-1.25PX18-13,(L) |
8 | ||
| 32116 - SPACER, DRIVE PLATE, FRONT | ||||
| 32116-12030 |
ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
1 | ||
| 32116-12020 |
ZZE142..4FC..IND |
1 | ||
| 32117 - SPACER, DRIVE PLATE, REAR | ||||
| 32117-12030 |
ZZE142..4FC..IND |
1 | ||
| 32117-12040 |
ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
1 | ||
| 35301 - BODY SUB-ASSY, FRONT OIL PUMP | ||||
| 35035-52040 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
1 | ||
| 35035-52040 |
ZZE142..4FC..IND |
1 | ||
| 35301A - SEAL, OIL (FOR FRONT OIL PUMP) | ||||
| 90311-38064 |
ZZE142..4FC..IND |
1 | ||
| 90311-38064 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
1 | ||
| 35301B - RING, O (FOR FRONT OIL PUMP BODY) | ||||
| 90301-99124 |
ZZE142..4FC..IND |
1 | ||
| 35301F - BOLT (FOR FRONT OIL PUMP SETTING) | ||||
| 90105-08301 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) *8-1.25PX22-20 |
7 | ||
| 90105-08301 |
ZZE142..4FC..IND *8-1.25PX22-20 |
7 | ||
| 35307F - BOLT (FOR STATOR SHAFT) | ||||
| 90148-60027 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
10 | ||
| 90148-60027 |
ZZE142..4FC..IND |
10 | ||
| 35321 - GEAR, FRONT OIL PUMP DRIVE | ||||
| 35321-52080 |
ZZE142..4FC..IND T=9.46-9.47,MARK 3 |
1 | ||
| 35321-52070 |
ZZE142..4FC..IND T=9.45-9.459,MARK 2 |
1 | ||
| 35321-52060 |
ZZE142..4FC..IND T=9.44-9.449,MARK 1 |
1 | ||
| 35321-52100 |
ZZE142..4FC..IND T=9.481-9.49,MARK 5 |
1 | ||
| 35321-52090 |
ZZE142..4FC..IND T=9.471-9.48,MARK 4 |
1 | ||
| 35321-52100 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.481-9.49,MARK 5 |
1 | ||
| 35321-52070 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.45-9.459,MARK 2 |
1 | ||
| 35321-52090 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.471-9.48,MARK 4 |
1 | ||
| 35321-52080 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.46-9.47,MARK 3 |
1 | ||
| 35321-52060 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.44-9.449,MARK 1 |
1 | ||
| 35322 - GEAR, FRONT OIL PUMP DRIVEN | ||||
| 35322-52080 |
ZZE142..4FC..IND T=9.46-9.47,MARK 3 |
1 | ||
| 35322-52070 |
ZZE142..4FC..IND T=9.45-9.459,MARK 2 |
1 | ||
| 35322-52060 |
ZZE142..4FC..IND T=9.44-9.449,MARK 1 |
1 | ||
| 35322-52090 |
ZZE142..4FC..IND T=9.471-9.48,MARK 4 |
1 | ||
| 35322-52100 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.481-9.49,MARK 5 |
1 | ||
| 35322-52090 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.471-9.48,MARK 4 |
1 | ||
| 35322-52070 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.45-9.459,MARK 2 |
1 | ||
| 35322-52100 |
ZZE142..4FC..IND T=9.481-9.49,MARK 5 |
1 | ||
| 35322-52080 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.46-9.47,MARK 3 |
1 | ||
| 35322-52060 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) T=9.44-9.449,MARK 1 |
1 | ||
| 35370 - SHAFT ASSY, STATOR | ||||
| 35370-52070 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
1 | ||
| 35370-52070 |
ZZE142..4FC..IND |
1 | ||
| 35370A - BEARING, THRUST NEEDLE ROLLER(FOR STATOR SHAFT) | ||||
| 90374-26003 |
ZZE142..4FC..IND |
1 | ||
| 90374-26003 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
1 | ||
| 35617 - RING, CLUTCH DRUM OIL SEAL | ||||
| 35613-52020 |
ZZE142..4FC..IND |
2 | ||
| 35613-52020 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
2 | ||
| 35617 - RING, CLUTCH DRUM OIL SEAL | ||||
| 35613-52020 |
ZZE142..4FC..IND |
2 | ||
| 35613-52020 |
ZZE141..16G..TH;ZRE141,142..4FC..(16E,16G,16V,D,GLI,N,XLI) |
2 | ||
