ZZE142R-GEMDKX (2008)

Toyota Corolla/Altis

Production Aug 2008 - May 2011
Engine 1ZZFE
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 2 OF 3(0712- )

Click highlighted areas on diagram

ENGINE ROOM(2/2) & EXTERIOR

diagram 11285A 11296C 11298B 17792D 69339C 74567A 74574 74751 88723J
Part # Description Qty Price
74751 - LABEL, TIRE PRESSURE INFORMATION
42661-12E70

ZZE142..IND

 1
88723J - LABEL, COOLER SERVICE CAUTION, NO.2
88733-20020

NDE140,ZZE142..IND

 1
88733-20020

CE140,NDE140,NZE140,ZRE141,142..IND,PKN

 1

ILLUST NO. 3 OF 3(0712- )

Click highlighted areas on diagram

INTERIOR

diagram 23923A 74515A 74541E 74559B 74597 74598A 74599B 87529B 89616
Part # Description Qty Price
74515A - PLATE, THEFT WARNING
74515-33020

NDE140,ZZE142..(18G,18V,E,G)..IND

 2
74559B - LABEL, FUEL INFORMATION
74559-14050

ZRE143..CVFC..(IDN,MA,PHL,VN);NZE140,ZRE141,142..GCC,IDN,IND,MA,PHL,PKN,VN

 1
74598A - LABEL, PASSENGER AIR BAG CAUTION
74598-02040

ZRE142..HTWCF;NDE140,ZRE141..RHD..(16E,16G,E,G);ZRE141,142..(16V,18G,18V,E,G)..(IDN,IND,MA,PHL,VN);ZRE142,143..(6F,CVFC)..(18E,18J,20G,20V)..(IDN,MA,PHL,TH,VN)..HTWC

 1
87529B - LABEL, A/C FILTER INFORMATION
87529-50010

ZZE142..IND

 1

ILLUST NO. 1 OF 3(0712- )

Click highlighted areas on diagram

ENGINE ROOM(1/2)

diagram 11295B 11295C 11296D 16793B 17791A
Part # Description Qty Price
16793B - LABEL, COOLING FAN INFORMATION
16793-46010

2C,1NDTV,2NZFE,1ZZFE,3ZZFE..CE140,NDE140,NZE140,ZZE14#..GCC,IND,PKN

 1
