ZZE142L-GEPNKV (2009)

Toyota Corolla/Altis

Production Jan 2009 - Jul 2010
Engine 1ZZFE
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(0901- )ZZE14#..GCC ; (1007- )ZRE141,142..XLI

Click highlighted areas on diagram

MANUAL MIRROR

diagram 87810 87910 87915A 87931 87940 87945B 87961 9016360024
Part # Description Qty Price
87810 - MIRROR ASSY, INNER REAR VIEW
87810-52041

ZZE14#..GCC

 1
87910 - MIRROR ASSY, OUTER REAR VIEW, RH
87910-02906

ZZE14#..GCC

NO PAINT REQ.,OUTSIDE REAR VIEW MIRROR-ELECTRIC RETRACTABLE(COLORED)

 1
87910-02905

ZZE142..GLI

NO PAINT REQ.

 1
87915A - COVER, OUTER MIRROR, RH
87915-02917

ZZE142..GLI

 1
87931 - OUTER MIRROR, RH
87931-02B60

ZZE14#..GCC

 1
87940 - MIRROR ASSY, OUTER REAR VIEW, LH
87940-02906

ZZE14#..GCC

NO PAINT REQ.,OUTSIDE REAR VIEW MIRROR-ELECTRIC RETRACTABLE(COLORED)

 1
87940-02905

ZZE142..GLI

NO PAINT REQ.

 1
87945B - COVER, OUTER MIRROR, LH
87945-02917

ZZE142..GLI

 1
87961 - MIRROR OUTER, LH
87961-02B50

ZZE14#..GCC

 1
Common parts
90163-60024

(0901- )ZZE14#..GCC ; (1007- )GCC ; (1007-)HTWCF

Click highlighted areas on diagram

REMOTE CONTROL MIRROR

diagram 87810 87810 87834 87910 87915A 87931 87940 87945B 87961 9016360024
Part # Description Qty Price
87810 - MIRROR ASSY, INNER REAR VIEW
87810-52041

ZZE14#..GCC

 1
87810 - MIRROR ASSY, INNER REAR VIEW
87810-52041

ZZE14#..GCC

 1
87910 - MIRROR ASSY, OUTER REAR VIEW, RH
87910-02906

ZZE14#..GCC

NO PAINT REQ.,OUTSIDE REAR VIEW MIRROR-ELECTRIC RETRACTABLE(COLORED)

 1
87910-02905

ZZE142..GLI

NO PAINT REQ.

 1
87915A - COVER, OUTER MIRROR, RH
87915-02917

ZZE142..GLI

 1
87931 - OUTER MIRROR, RH
87931-02B60

ZZE14#..GCC

 1
87940 - MIRROR ASSY, OUTER REAR VIEW, LH
87940-02906

ZZE14#..GCC

NO PAINT REQ.,OUTSIDE REAR VIEW MIRROR-ELECTRIC RETRACTABLE(COLORED)

 1
87940-02905

ZZE142..GLI

NO PAINT REQ.

 1
87945B - COVER, OUTER MIRROR, LH
87945-02917

ZZE142..GLI

 1
87961 - MIRROR OUTER, LH
87961-02B50

ZZE14#..GCC

 1
Common parts
90163-60024
