NZE140R-GEMDKP (2011)
Toyota Corolla/Altis
(0712- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 62111C - BOARD, COWL SIDE TRIM, RH | ||||
| 62111-02220E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62112 - BOARD, COWL SIDE TRIM, LH | ||||
| 62112-02220E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62211-02340E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62212-02340E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62217G - CLIP, FRONT PILLAR GARNISH | ||||
| 62217-52010 |
CE140,NZE140 |
2 | ||
| 62217H - CLIP, CENTER PILLER GARNISH | ||||
| 90467-10167 |
CE140,NZE140 |
2 | ||
| 62311B - WEATHERSTRIP, FRONT DOOR OPENING TRIM, RH | ||||
| 62311-02180E0 |
CE140,NZE140 GREGE,TRIM4# |
1 | ||
| 62312B - WEATHERSTRIP, FRONT DOOR OPENING TRIM, LH | ||||
| 62312-02180E0 |
CE140,NZE140 GREGE,TRIM4# |
1 | ||
| 62331A - WEATHERSTRIP, REAR DOOR OPENING TRIM, RH | ||||
| 62331-02220E0 |
CE140,NZE140 GREGE,TRIM4# |
1 | ||
| 62332A - WEATHERSTRIP, REAR DOOR OPENING TRIM, LH | ||||
| 62332-02220E0 |
CE140,NZE140 GREGE,TRIM4# |
1 | ||
| 62411 - GARNISH, CENTER PILLAR, RH | ||||
| 62410-02190E1 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62412 - GARNISH, CENTER PILLAR, LH | ||||
| 62420-02180E1 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62413A - GARNISH, CENTER PILLAR, LOWER RH | ||||
| 62413-02190E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62413C - CLIP (FOR CENTER LOWER GARNISH) | ||||
| 62217-13010 |
CE140,NZE140 |
4 | ||
| 62414A - GARNISH, CENTER PILLAR, LOWER LH | ||||
| 62414-02190E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62470A - GARNISH ASSY, ROOF SIDE, INNER RH | ||||
| 62470-02250E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62473C - BOARD, ROOF SIDE INNER GARNISH, RH | ||||
| 62473-02080B0 |
CE140,NZE140,ZRE141..PKN DK.GRAY,TRIM4# |
1 | ||
| 62474C - BOARD, ROOF SIDE INNER GARNISH, LH | ||||
| 62474-02080B0 |
CE140,NZE140,ZRE141..PKN DK.GRAY,TRIM4# |
1 | ||
| 62480A - GARNISH ASSY, ROOF SIDE, INNER LH | ||||
| 62480-02250E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62551E - CLIP(FOR REAR SEAT SIDE GARNISH) | ||||
| 90467-10167 |
CE140,NZE140 BLUE |
2 | ||
| 62551E - CLIP(FOR REAR SEAT SIDE GARNISH) | ||||
| 90467-10167 |
CE140,NZE140 BLUE |
2 | ||
| 62551F - GARNISH, REAR SEAT SIDE, RH | ||||
| 62551-02230E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 62552F - GARNISH, REAR SEAT SIDE, LH | ||||
| 62552-02210E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 67911B - PLATE, FRONT DOOR SCUFF, OUTSIDE, RH | ||||
| 67911-02150E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 67912A - PLATE, FRONT DOOR SCUFF, OUTSIDE LH | ||||
| 67911-02150E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 67913 - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-02210E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-02210E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 67917A - PLATE, REAR DOOR SCUFF, RH | ||||
| 67917-02200E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| 67918A - PLATE, REAR DOOR SCUFF, LH | ||||
| 67918-02200E0 |
CE140,NZE140,ZRE141..PKN GREGE,TRIM4# |
1 | ||
| Common parts | ||||
| 90167-T0012 | ||||
| 90189-05096 | ||||
| 90467-06147 | ||||
| 93568-55018 | ||||
| Linked diagrams | ||||
| 7104 | ||||
