XZB70R-ZGMSY (2018)
Toyota Coaster
(1801- )XZB70,80..RHD..4FC,5F
EXCEPT EURO 5
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44610 - BOOSTER ASSY, BRAKE | ||||
| 44610-36650 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) |
1 | ||
| 44704 - RESERVOIR SUB-ASSY, VACUUM | ||||
| 44704-36260 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
1 | ||
| 44704-36270 |
HZB60,70;XZB70,80..6FC |
1 | ||
| 44729 - GASKET, VACUUM TUBE | ||||
| 44729-36020 |
XZB60..GEN;XZB70..6FC..ARL;BZB60,HZB60,70,TRB60,70,XZB70,80..(5F,6FC)..(GCC,GEN,SA,TAIW) |
1 | ||
| 44730A - HOSE, VACUUM, NO.1 | ||||
| 90999-92002 |
XZB70..6FC..ARL;BZB60,XZB60,70,80..RHD..(5F,6FC)..(GEN,SA) L=180 |
2 | ||
| 44730A - HOSE, VACUUM, NO.1 | ||||
| 90999-92002 |
XZB70..6FC..ARL;BZB60,XZB60,70,80..RHD..(5F,6FC)..(GEN,SA) L=180 |
2 | ||
| 44730J - WAY(FOR BOOSTER VACUUM) | ||||
| 90413-09040 |
BZB60,70 |
1 | ||
| 90414-09001 |
XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
1 | ||
| 90413-09037 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
1 | ||
| 44730P - VALVE ASSY, VACUUM CHECK, NO.1 | ||||
| 44730-60050 |
HZB60,70;XZB70,80..6FC |
1 | ||
| 44730-60050 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
2 | ||
| 44730P - VALVE ASSY, VACUUM CHECK, NO.1 | ||||
| 44730-60050 |
HZB60,70;XZB70,80..6FC |
1 | ||
| 44730-60050 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
2 | ||
| 44753 - CLAMP, VACUUM RESERVOIR, NO.2 | ||||
| 44753-30320 |
XZB60..GEN;XZB70..6FC..ARL;BZB60,HZB60,70,TRB60,70,XZB70,80..(5F,6FC)..(GCC,GEN,SA,TAIW) |
1 | ||
| 44754D - BRACKET, VACUUM TUBE, NO.2 | ||||
| 44754-36110 |
BZB60,70 |
2 | ||
| 44754-36230 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) |
1 | ||
| 44754E - BRACKET, VACUUM TUBE, NO.3 | ||||
| 44754-36120 |
BZB60,HZB60,70 |
1 | ||
| 44754-36130 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) |
1 | ||
| 44754G - BRACKET, VACUUM TUBE, NO.5 | ||||
| 44754-36190 |
XZB70..6FC..ARL;BZB60,HZB60,70,XZB60,70,80..RHD..(5F,6FC)..(GEN,SA) |
1 | ||
| 44754J - BRACKET, VACUUM TUBE, NO.6 | ||||
| 44754-36180 |
XZB70..6FC..ARL;XZB60,80..(5F,6FC)..GEN;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW) |
1 | ||
| 44757B - BRACKET, VACUUM TANK CLAMP, NO.2 | ||||
| 44757-36060 |
XZB70..6FC..ARL;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW);BZB60,HZB60,70,XZB60,80..(01S,17S,19S,23S,25S,26S,30S)..(5F,6FC) |
1 | ||
| 44761C - TUBE, VACUUM PUMP TO CONNECTOR | ||||
| 44761-36263 |
XZB70..6FC..ARL;XZB60,80..(5F,6FC)..GEN;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW) |
1 | ||
| 44761-36180 |
HZB60,70 |
1 | ||
| 44761-36250 |
BZB60,70 |
1 | ||
| 44764G - TUBE, CONNECTOR TO BRAKE BOOSTER | ||||
| 44764-36590 |
BZB60,70 |
1 | ||
| 44764-36520 |
HZB60,70 |
1 | ||
| 44764-36630 |
XZB70,80..6FC;XZB70..GCC,TAIW;XZB70..RHD..(22S,23S,29S)..(GEN,SA) |
1 | ||
| 44765 - TUBE, CONNECTOR TO BRAKE BOOSTER, NO.2 | ||||
| 44765-36360 |
BZB60,70 |
1 | ||
| 44765-36370 |
HZB60,70..RHD;XZB70,80..6FC |
1 | ||
| 44765-36380 |
XZB60,70,80..RHD..5F..(GEN,SA) |
1 | ||
| 44771 - HOSE, VACUUM TUBE CONNECTOR | ||||
| 44771-36320 |
TRB60,70..GEN FRONT WHEEL BRAKE-DISC(ROTOR = 321MM)&ABS-WITH(ABS & VSC) |
1 | ||
| 90445-17141 |
XZB70..6FC..ARL;BZB60,HZB60,70,XZB60,70,80..RHD..(5F,6FC)..(GEN,SA) |
1 | ||
| 44771A - CLIP(FOR VACUUM TUBE CONNECTOR HOSE) | ||||
| 96133-41500 |
XZB60..GEN;XZB70..6FC..ARL;BZB60,HZB60,70,TRB60,70,XZB70,80..(5F,6FC)..(GCC,GEN,SA,TAIW) |
2 | ||
| 44771A - CLIP(FOR VACUUM TUBE CONNECTOR HOSE) | ||||
| 96133-41500 |
XZB60..GEN;XZB70..6FC..ARL;BZB60,HZB60,70,TRB60,70,XZB70,80..(5F,6FC)..(GCC,GEN,SA,TAIW) |
2 | ||
| 44772 - HOSE, CHECK VALVE TO CONNECTOR TUBE | ||||
| 44772-36100 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
2 | ||
| 44772-36100 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
1 | ||
| 44772 - HOSE, CHECK VALVE TO CONNECTOR TUBE | ||||
| 44772-36100 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
2 | ||
| 44772-36100 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
1 | ||
| 44772A - CLIP(FOR CHECK VALVE TO CONNECTOR TUBE) | ||||
| 96133-41500 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
2 | ||
| 96133-41500 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
4 | ||
| 44772A - CLIP(FOR CHECK VALVE TO CONNECTOR TUBE) | ||||
| 96133-41500 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
2 | ||
| 96133-41500 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
4 | ||
| 44772A - CLIP(FOR CHECK VALVE TO CONNECTOR TUBE) | ||||
| 96133-41500 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
2 | ||
| 96133-41500 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
4 | ||
| 44772A - CLIP(FOR CHECK VALVE TO CONNECTOR TUBE) | ||||
| 96133-41500 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
2 | ||
| 96133-41500 |
BZB60,XZB60,80..5F..GEN;XZB70..5F..(GCC,GEN,SA,TAIW) |
4 | ||
| 44774 - HOSE, UNION TO CONNECTOR TUBE | ||||
| 44774-36391 |
TRB60,70 |
1 | ||
| 44774-36360 |
BZB60,70 |
1 | ||
| 44774-36430 |
XZB60,70..(02S,17S,19S,22S,23S,25S,29S,30S)..(GCC,GEN,SA,TAIW) |
1 | ||
| 44774-36300 |
HZB60,70..RHD |
1 | ||
| 44774A - CLIP(FOR UNION TO CONNECTOR TUBE HOSE) | ||||
| 96133-41500 |
XZB60..GEN;XZB70..6FC..ARL;BZB60,HZB60,70,TRB60,70,XZB70,80..(5F,6FC)..(GCC,GEN,SA,TAIW) |
2 | ||
| 44774A - CLIP(FOR UNION TO CONNECTOR TUBE HOSE) | ||||
| 96133-41500 |
XZB60..GEN;XZB70..6FC..ARL;BZB60,HZB60,70,TRB60,70,XZB70,80..(5F,6FC)..(GCC,GEN,SA,TAIW) |
2 | ||
| 44775C - HOSE, CONNECTOR TO WAY | ||||
| 44775-36100 |
XZB70..6FC..ARL;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW);BZB60,HZB60,70,XZB60,80..(01S,17S,19S,23S,25S,26S,30S)..(5F,6FC) |
1 | ||
| 44775E - HOSE, WAY TO CONNECTOR | ||||
| 44775-36100 |
BZB60,70 |
1 | ||
| 44775-36090 |
XZB70..6FC..ARL;XZB60,80..(5F,6FC)..GEN;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW) |
1 | ||
| 44775-36100 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
1 | ||
| 44775K - CLIP(FOR CONNECTOR TO 3 WAY HOSE) | ||||
| 96133-41500 |
XZB70..6FC..ARL;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW);BZB60,HZB60,70,XZB60,80..(01S,17S,19S,23S,25S,26S,30S)..(5F,6FC) |
2 | ||
| 44775K - CLIP(FOR CONNECTOR TO 3 WAY HOSE) | ||||
| 96133-41500 |
XZB70..6FC..ARL;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW);BZB60,HZB60,70,XZB60,80..(01S,17S,19S,23S,25S,26S,30S)..(5F,6FC) |
2 | ||
| 44775L - CLIP(FOR 3 WAY TO CONNECTOR HOSE) | ||||
| 96133-41500 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
2 | ||
| 96133-41500 |
XZB70..6FC..ARL;BZB60,XZB60,80..(5F,6FC)..GEN;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW) |
2 | ||
| 44775L - CLIP(FOR 3 WAY TO CONNECTOR HOSE) | ||||
| 96133-41500 |
HZB60,70..GEN EXHAUST RETARDER-WITH |
2 | ||
| 96133-41500 |
XZB70..6FC..ARL;BZB60,XZB60,80..(5F,6FC)..GEN;XZB70..(5F,6FC)..(GCC,GEN,SA,TAIW) |
2 | ||
| 44776 - HOSE, BRAKE BOOSTER | ||||
| 44776-36190 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) |
1 | ||
| 44776A - HOSE, VACUUM RESERVOIR TO BRAKE BOOSTER | ||||
| 44776-36171 |
HZB60,70..RHD |
1 | ||
| 44776-36131 |
XZB70..6FC..ARL;BZB60,XZB60,70,80..RHD..(5F,6FC)..(GEN,SA) |
1 | ||
| 44776B - CLIP(FOR VACUUM RESERVOIR TO BRAKE BOOSTER) | ||||
| 96133-41500 |
XZB70..6FC..ARL;XZB70..RHD..(5F,6FC)..(GEN,SA);BZB60,HZB60,70,XZB60,80..(5F,6FC)..GEN |
2 | ||
| 44776B - CLIP(FOR VACUUM RESERVOIR TO BRAKE BOOSTER) | ||||
| 96133-41500 |
XZB70..6FC..ARL;XZB70..RHD..(5F,6FC)..(GEN,SA);BZB60,HZB60,70,XZB60,80..(5F,6FC)..GEN |
2 | ||
| 44776E - CLIP(FOR BRAKE BOOSTER HOSE) | ||||
| 96133-41500 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) NO.2:REFER ILLUST. |
1 | ||
| 96133-41500 |
HZB70..GCC;XZB60..GEN;XZB70..LHD;BZB60,TRB60,70 |
2 | ||
| 90467-16014 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) NO.1:REFER ILLUST. |
1 | ||
| 44776E - CLIP(FOR BRAKE BOOSTER HOSE) | ||||
| 96133-41500 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) NO.2:REFER ILLUST. |
1 | ||
| 96133-41500 |
HZB70..GCC;XZB60..GEN;XZB70..LHD;BZB60,TRB60,70 |
2 | ||
| 90467-16014 |
XZB70,80..6FC;XZB70..RHD..(22S,23S,29S)..(GEN,SA) NO.1:REFER ILLUST. |
1 | ||
| 44799 - WAY, BRAKE VACUUM HOSE | ||||
| 90414-10043 |
XZB70..6FC..ARL;HZB70,XZB70..GCC,TAIW;XZB60,70..RHD..(5F,6FC)..(GEN,SA);BZB60,TRB60,70,XZB80..(01S,17S,19S,20S,23S)..(5F,6FC) |
1 | ||
| 47264D - CLEVIS, BRAKE MASTER CYLINDER PUSH ROD | ||||
| 47264-22040 |
XZB70,80..6FC;TRB60,70,XZB70..GCC,TAIW;XZB70..RHD..(22S,23S,29S)..(GEN,SA) |
1 | ||
| 47264-50010 |
XZB70..LHD..GEN;BZB60,HZB60,70,TRB60,70,XZB60..GEN |
1 | ||
| Common parts | ||||
| 90105-08460 | ||||
| 90119-08A46 | ||||
| 90179-08038 | ||||
| 90179-08233 | ||||
| 90179-10065 | ||||
| 90461-10754 | ||||
| 90461-10780 | ||||
| 90464-00682 | ||||
| 91611-60814 | ||||
| 91651-60616 | ||||
| 91651-B0820 | ||||
| Linked diagrams | ||||
| 1905 | ||||
| 3104 | ||||
| 4710 | ||||
| 8401 | ||||
| 8414 | ||||
