HDB30R-MRX1 (1990)

Toyota Coaster

Production Jan 1990 - Jan 1993
Engine 1HDT
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 2 OF 2(9001- )HDB30

Click highlighted areas on diagram

diagram 78024 78103 78104 78169 78180 78195 9011608208 9017908053 9038608044 9038608077 9046108677 9046210117 9046210117 9046808001 9050816134 91511B0812 91511B0812 9161140816 9161140816 9165140816 9414140840 9451140800 9461140800 9461140800 9538102518
Part # Description Qty Price
78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE
78024-90B00

BB20,21,30

 1
78180 - WIRE ASSY, ACCELERATOR
78180-90B00

BB20,21,30..RHD

 1
78180-90B14

HDB30,HZB30..RHD

 1
Common parts
90116-08208
90179-08053
90386-08044
90386-08077
90461-08677
90462-10117
90468-08001
90508-16134
91511-B0812
91611-40816
91651-40816
94141-40840
94511-40800
94611-40800
95381-02518

(9001- )HDB30

Click highlighted areas on diagram

diagram 78024 78103 78104 78169 78180 78195 9011608208 9017908053 9038608044 9038608077 9046400233 9046400366 9046808001 9050816134 91511B0812 91511B0812 91511B0812 9414140840 9451140800 9461140800 9461140800 9538102518
Part # Description Qty Price
78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE
78024-90B00

BB20,21,30

 1
78180 - WIRE ASSY, ACCELERATOR
78180-90B00

BB20,21,30..RHD

 1
78180-90B14

HDB30,HZB30..RHD

 1
Common parts
90116-08208
90179-08053
90386-08044
90386-08077
90464-00233
90464-00366
90468-08001
90508-16134
91511-B0812
94141-40840
94511-40800
94611-40800
95381-02518
