BB10R-MDZER (1979)
Toyota Coaster
Production
Nov 1979
-
Apr 1982
Engine
2B
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(7708-8106)
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52102 - BRACKET SUB-ASSY, FRONT BUMPER, RH | ||||
| 52103-90500 |
BB10,RB1# |
1 | ||
| 52103 - BRACKET SUB-ASSY, FRONT BUMPER, LH | ||||
| 52104-90500 |
BB10,RB1# |
1 | ||
| 52105 - STAY SUB-ASSY, FRONT BUMPER, RH | ||||
| 52115-90501 |
BB10,RB1#..RHD LWR |
1 | ||
| 52116-90501 |
BB10,RB1#..RHD UPR |
1 | ||
| 52105 - STAY SUB-ASSY, FRONT BUMPER, RH | ||||
| 52115-90501 |
BB10,RB1#..RHD LWR |
1 | ||
| 52116-90501 |
BB10,RB1#..RHD UPR |
1 | ||
| 52106 - STAY SUB-ASSY, FRONT BUMPER, LH | ||||
| 52114-90500 |
BB10,RB1#..RHD LWR |
1 | ||
| 52117-90500 |
BB10,RB1#..RHD UPR |
1 | ||
| 52106 - STAY SUB-ASSY, FRONT BUMPER, LH | ||||
| 52114-90500 |
BB10,RB1#..RHD LWR |
1 | ||
| 52117-90500 |
BB10,RB1#..RHD UPR |
1 | ||
| 52111 - BUMPER ASSY, FRONT | ||||
| 52101-90924 |
BB10,RB1#..GEN,IRQ |
1 | ||
| 52101-90503 |
BB10,RB13..GEN,IRQ |
1 | ||
| 52134 - SPACER, FRONT BUMPER BAR BRACKET | ||||
| 52134-90500 |
BB10,RB1# |
4 | ||
| 52134 - SPACER, FRONT BUMPER BAR BRACKET | ||||
| 52134-90500 |
BB10,RB1# |
4 | ||
| Common parts | ||||
| 90112-10046 | ||||
| 90179-08017 | ||||
| 90179-08096 | ||||
| 90179-08146 | ||||
| 90179-10125 | ||||
| 91655-40825 | ||||
| 91655-41025 | ||||
(8106- )
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52105 - STAY SUB-ASSY, FRONT BUMPER, RH | ||||
| 52115-90501 |
BB10,RB1#..RHD LWR |
1 | ||
| 52116-90501 |
BB10,RB1#..RHD UPR |
1 | ||
| 52105 - STAY SUB-ASSY, FRONT BUMPER, RH | ||||
| 52115-90501 |
BB10,RB1#..RHD LWR |
1 | ||
| 52116-90501 |
BB10,RB1#..RHD UPR |
1 | ||
| 52106 - STAY SUB-ASSY, FRONT BUMPER, LH | ||||
| 52114-90500 |
BB10,RB1#..RHD LWR |
1 | ||
| 52117-90500 |
BB10,RB1#..RHD UPR |
1 | ||
| 52106 - STAY SUB-ASSY, FRONT BUMPER, LH | ||||
| 52114-90500 |
BB10,RB1#..RHD LWR |
1 | ||
| 52117-90500 |
BB10,RB1#..RHD UPR |
1 | ||
| 52111 - BUMPER ASSY, FRONT | ||||
| 52101-90924 |
BB10,RB1#..GEN,IRQ |
1 | ||
| 52101-90503 |
BB10,RB13..GEN,IRQ |
1 | ||
| Common parts | ||||
| 90179-08017 | ||||
| 90179-08096 | ||||
| 90179-10125 | ||||
| 91655-40825 | ||||
| 91655-41025 | ||||
