ST202R-BLMSK (1993)

Toyota Celica

Production Nov 1993 - Aug 1999
Engine 3SFE
Transmission MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9311- )

Click highlighted areas on diagram

diagram 11283 11284 11286 11288 11289 11291 11292 11298 1356410010 16701G 17700C
Part # Description Qty Price
11284 - PLATE, ENGINE BOLT INFORMATION
11284-74040

3SFE,5SFE..ST202,204

 1
11288 - PLATE, ENGINE SYSTEM
11288-74090

3SFE..ST202

 1
11292 - PLATE, ENGINE NAME, NO.2
11292-74101

3SFE..ST202

 1
16701G - LABEL, CAUTION
88723-12100

3S#,5SFE..ST20#

 1
88723-20081

3S#,5SFE..ST20#

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
90917-07118

3S#,5SFE..ST20#

 1
Common parts
13564-10010
