RA61R-BCMMSW (1981)
Toyota Celica
(8108- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 90981-11018 |
AA63,MA61,RA6#,SA63,TA60 12V 1.2W W/O SOCKET |
10 | ||
| 99132-12034 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 90981-11018 |
AA63,MA61,RA6#,SA63,TA60 12V 1.2W W/O SOCKET |
10 | ||
| 99132-12034 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14040 |
AA63,MA61,RA6#,SA63,TA60 12V 1.4W |
11 | ||
| 83101-14030 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14040 |
AA63,MA61,RA6#,SA63,TA60 12V 1.4W |
11 | ||
| 83101-14030 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83247-14710 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83247-14711 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83247-1B810 |
AA63,RA61..RHD W/DIGITAL CLOCK |
1 | ||
| 83110 - SPEEDOMETER ASSY | ||||
| 83110-14380 |
MA61,RA61..RHD MILE |
1 | ||
| 83110-14380 |
RA61..RHD MILE |
1 | ||
| 83110-14381 |
RA61..RHD..EUG MILE |
1 | ||
| 83128 - KNOB, TRIP COUNTER | ||||
| 83128-14510 |
AA63,MA61,RA6#,SA63,TA60 |
1 | ||
| 83131 - DIAL, METER, NO.1 | ||||
| 83131-14430 |
RA61..RHD..XT |
1 | ||
| 83131-1D610 |
RA61..RHD MILE,W/DIGITAL CLOCK |
1 | ||
| 83132 - CASE, COMBINATION METER | ||||
| 83132-14610 |
RA61..RHD..XT |
1 | ||
| 83132-1B790 |
RA61..RHD W/DIGITAL CLOCK |
1 | ||
| 83133 - PLATE, COMBINATION METER, NO.1 | ||||
| 83133-14531 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83133-14530 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83133-14531 |
AA63,RA6#,SA63..RHD W/DIGITAL CLOCK |
1 | ||
| 83251 - METER, VOLTAGE | ||||
| 83251-14510 |
RA61..EUG;MA61,RA60,63,TA60..GT,SPR,ST,XT |
1 | ||
| 83251-14570 |
RA61..RHD;AA63,SA63,TA60;RA61..LHD..4FC;RA61..LHD..5F..EUG;RA61..5F..XT..(GEN,SAA) |
1 | ||
| 83270 - TACHOMETER ASSY, ENGINE | ||||
| 83242-14510 |
RA6#,SA63..RHD |
1 | ||
| 83310 - GAGE ASSY, FUEL RECEIVER | ||||
| 83243-14510 |
AA63,MA61,RA6#,SA63,TA60 |
1 | ||
| 83410 - GAGE ASSY, WATER TEMPERATURE RECEIVER | ||||
| 83244-1B010 |
AA63,RA61,SA63..RHD |
1 | ||
| 83244-14510 |
MA61,RA6#,TA60..ARL,EUR,GEN |
1 | ||
| 83244-1B050 |
AA63,RA61..RHD |
1 | ||
| 83510 - GAGE ASSY, OIL PRESSURE RECEIVER | ||||
| 83246-14510 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83246-14510 |
RA61..RHD..EUG |
1 | ||
| 83909 - KNOB, CLOCK | ||||
| 83909-14012 |
AA63,RA60,61,63,TA60 ANALOGUE |
1 | ||
| 83909-22180 |
AA63,MA61,RA60,61,63,SA63,TA60..GT,GTS,SPR,ST,XT DIGITAL |
1 | ||
| 83909 - KNOB, CLOCK | ||||
| 83909-14012 |
AA63,RA60,61,63,TA60 ANALOGUE |
1 | ||
| 83909-22180 |
AA63,MA61,RA60,61,63,SA63,TA60..GT,GTS,SPR,ST,XT DIGITAL |
1 | ||
| 83910 - CLOCK ASSY | ||||
| 83910-14300 |
RA61..RHD..XT DIGITAL |
1 | ||
| 83910 - CLOCK ASSY | ||||
| 83910-14300 |
RA61..RHD..XT DIGITAL |
1 | ||
| 83919 - SCREW, CLOCK | ||||
| 83919-14012 |
AA63,RA60,61,63,TA60 ANALOGUE |
1 | ||
| 83919-12230 |
AA63,MA61,RA6#,SA63,TA60..GT,GTS,SPR,ST,XT DIGITAL |
1 | ||
| 83919 - SCREW, CLOCK | ||||
| 83919-14012 |
AA63,RA60,61,63,TA60 ANALOGUE |
1 | ||
| 83919-12230 |
AA63,MA61,RA6#,SA63,TA60..GT,GTS,SPR,ST,XT DIGITAL |
1 | ||
| Common parts | ||||
| 93567-55016 | ||||
(8108- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83710 - CABLE ASSY, SPEEDOMETER DRIVE, NO.1 | ||||
| 83710-14410 |
RA6#..RHD..5F |
1 | ||
| 83710D - CLAMP (FOR SPEEDOMETER CABLE) | ||||
| 83791-14120 |
AA63,RA6#,TA60 |
1 | ||
| 83960 - MEMORIZER ASSY | ||||
| 83960-14020 |
AA63,MA61,RA6#,SA63..RHD |
1 | ||
| 83960-14020 |
TA60;MA61,RA61..RHD;RA61..LHD..ST..EUG;RA60,63..ARL,GEN,ME |
1 | ||
| Common parts | ||||
| 82711-22220 | ||||
| 83791-14110 | ||||
| 83791-14120 | ||||
| 83791-14130 | ||||
| 83791-14140 | ||||
| 83791-14150 | ||||
| 90468-05014 | ||||
| 91651-40614 | ||||
| 93566-15512 | ||||
(8308- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 90981-11018 |
AA63,MA61,RA6#,SA63,TA60 12V 1.2W W/O SOCKET |
10 | ||
| 99132-12034 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 90981-11018 |
AA63,MA61,RA6#,SA63,TA60 12V 1.2W W/O SOCKET |
10 | ||
| 99132-12034 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14040 |
AA63,MA61,RA6#,SA63,TA60 12V 1.4W |
11 | ||
| 83101-14030 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14040 |
AA63,MA61,RA6#,SA63,TA60 12V 1.4W |
11 | ||
| 83101-14030 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14040 |
AA63,MA61,RA6#,SA63,TA60 12V 1.4W |
11 | ||
| 83101-14030 |
AA63,MA61,RA6#,SA63,TA60 12V 3.4W |
9 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83247-14710 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83247-14711 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83247-1B810 |
AA63,RA61..RHD W/DIGITAL CLOCK |
1 | ||
| 83110 - SPEEDOMETER ASSY | ||||
| 83110-14380 |
MA61,RA61..RHD MILE |
1 | ||
| 83110-14380 |
RA61..RHD MILE |
1 | ||
| 83110-14381 |
RA61..RHD..EUG MILE |
1 | ||
| 83128 - KNOB, TRIP COUNTER | ||||
| 83128-14510 |
AA63,MA61,RA6#,SA63,TA60 |
1 | ||
| 83131 - DIAL, METER, NO.1 | ||||
| 83131-14430 |
RA61..RHD..XT |
1 | ||
| 83131-1D610 |
RA61..RHD MILE,W/DIGITAL CLOCK |
1 | ||
| 83132 - CASE, COMBINATION METER | ||||
| 83132-14610 |
RA61..RHD..XT |
1 | ||
| 83132-1B790 |
RA61..RHD W/DIGITAL CLOCK |
1 | ||
| 83133 - PLATE, COMBINATION METER, NO.1 | ||||
| 83133-14531 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83133-14530 |
MA61,RA61..RHD..(SPR,XT) |
1 | ||
| 83133-14531 |
AA63,RA6#,SA63..RHD W/DIGITAL CLOCK |
1 | ||
| 83270 - TACHOMETER ASSY, ENGINE | ||||
| 83242-14510 |
RA6#,SA63..RHD |
1 | ||
| 83310 - GAGE ASSY, FUEL RECEIVER | ||||
| 83243-14510 |
AA63,MA61,RA6#,SA63,TA60 |
1 | ||
| 83909 - KNOB, CLOCK | ||||
| 83909-14012 |
AA63,RA60,61,63,TA60 ANALOGUE |
1 | ||
| 83909-22180 |
AA63,MA61,RA60,61,63,SA63,TA60..GT,GTS,SPR,ST,XT DIGITAL |
1 | ||
| 83910 - CLOCK ASSY | ||||
| 83910-14300 |
RA61..RHD..XT DIGITAL |
1 | ||
| 83919 - SCREW, CLOCK | ||||
| 83919-14012 |
AA63,RA60,61,63,TA60 ANALOGUE |
1 | ||
| 83919-12230 |
AA63,MA61,RA6#,SA63,TA60..GT,GTS,SPR,ST,XT DIGITAL |
1 | ||
| Common parts | ||||
| 93567-55016 | ||||
