TA12-K (1970)
Toyota Carina
(7012-7509)DLX,STD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04905 - CUP KIT, FRONT WHEEL CYLINDER | ||||
| 04905-14010 |
TA1#..DLX,STD |
1 | ||
| 47041 - PLATE SUB-ASSY, BRAKE BACKING, FRONT RH | ||||
| 47041-14012 |
TA1#..DLX,STD |
1 | ||
| 47041-14011 |
TA1#..DLX,STD |
1 | ||
| 47041D - BOLT(FOR BACKING PLATE TO STEERING KNUCKLE SETTING) | ||||
| 90101-10366 |
TA1#..DLX,STD |
8 | ||
| 91111-71014 |
TA1# |
8 | ||
| 47042 - PLATE SUB-ASSY, BRAKE BACKING, FRONT LH | ||||
| 47042-14011 |
TA1#..DLX,STD |
1 | ||
| 47042-14012 |
TA1#..DLX,STD |
1 | ||
| 47410C - SPRING(FOR FRONT BRAKE SHOE HOLD DOWN) | ||||
| 47446-10010 |
TA1#..DLX,STD |
4 | ||
| 47410D - SPRING, TENSION(FOR FRONT BRAKE SHOE RETURN) | ||||
| 90506-18313 |
TA1# |
2 | ||
| 90506-18313 |
TA1#..DLX,STD |
2 | ||
| 47410E - SPRING, TENSION(FOR FRONT BRAKE SHOE RETURN) | ||||
| 90506-18313 |
TA1#..DLX,STD |
2 | ||
| 90506-18313 |
TA1# |
2 | ||
| 47410L - SHOE KIT, FRONT BRAKE | ||||
| 04494-14010 |
TA1#..DLX,STD |
1 | ||
| 04494-14020 |
TA1#..DLX,STD |
1 | ||
| 04494-14010 |
TA1# |
1 | ||
| 47447 - PIN, SHOE HOLD DOWN SPRING(FOR FRONT BRAKE) | ||||
| 47447-10010 |
TA1#..DLX,STD |
4 | ||
| 47491 - PLUG, HOLE(FOR FRONT BRAKE) | ||||
| 47491-30020 |
TA1# |
4 | ||
| 47491-20020 |
TA1# |
4 | ||
| 47491-20020 |
TA1#..DLX,STD |
4 | ||
| 47510 - CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR FRONT OR UPPER | ||||
| 47510-19066 |
TA1# |
1 | ||
| 47510-19065 |
TA1# |
1 | ||
| 47510-19066 |
TA1#..DLX,STD |
1 | ||
| 47510A - SEAT, UNION(FOR FRONT WHEEL BRAKE CYLINDER) | ||||
| 90410-03015 |
TA1#..DLX,STD |
6 | ||
| 47510A - SEAT, UNION(FOR FRONT WHEEL BRAKE CYLINDER) | ||||
| 90410-03015 |
TA1#..DLX,STD |
6 | ||
| 47510K - CYLINDER KIT, FRONT WHEEL | ||||
| 04473-14011 |
TA1# |
4 | ||
| 04473-14011 |
TA1#..DLX,STD |
4 | ||
| 47520 - CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR REAR OR LOWER) | ||||
| 47520-19055 |
TA1# |
1 | ||
| 47520-19056 |
TA1# |
1 | ||
| 47520-19056 |
TA1#..DLX,STD |
1 | ||
| 47530 - CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR FRONT OR UPPER | ||||
| 47530-19065 |
TA1# |
1 | ||
| 47530-19066 |
TA1#..DLX,STD |
1 | ||
| 47530-19066 |
TA1# |
1 | ||
| 47540 - CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR REAR OR LOWER) | ||||
| 47540-19055 |
TA1# |
1 | ||
| 47540-19056 |
TA1#..DLX,STD |
1 | ||
| 47540-19056 |
TA1# |
1 | ||
| 47547 - PLUG, BLEEDER(FOR FRONT DRUM BRAKE) | ||||
| 47547-12020 |
TA1# DISC BRAKE |
2 | ||
| 47547-12010 |
TA1#..DLX,STD FOR DRUM BRAKE |
2 | ||
| 47548 - CAP, BLEEDER PLUG(FOR DRUM BRAKE, FRONT) | ||||
| 31478-30010 |
TA1#..DLX,STD |
2 | ||
| 47551 - NUT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE | ||||
| 47551-12021 |
TA1# |
2 | ||
| 47551-14010 |
TA1# |
2 | ||
| 47551-14010 |
TA1#..DLX,STD RH.SCREW |
2 | ||
| 47551 - NUT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE | ||||
| 47551-12021 |
TA1# |
2 | ||
| 47551-14010 |
TA1# |
2 | ||
| 47551-14010 |
TA1#..DLX,STD RH.SCREW |
2 | ||
| 47552 - NUT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE | ||||
| 47552-12021 |
TA1# |
2 | ||
| 47552-14010 |
TA1#..DLX,STD LH.SCREW |
2 | ||
| 47552 - NUT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE | ||||
| 47552-12021 |
TA1# |
2 | ||
| 47552-14010 |
TA1#..DLX,STD LH.SCREW |
2 | ||
| 47553 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAK | ||||
| 47553-12011 |
TA1# |
2 | ||
| 47553-12011 |
TA1#..DLX,STD RH.SCREW |
2 | ||
| 47553 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAK | ||||
| 47553-12011 |
TA1# |
2 | ||
| 47553-12011 |
TA1#..DLX,STD RH.SCREW |
2 | ||
| 47554 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAK | ||||
| 47554-12011 |
TA1# |
2 | ||
| 47554-12011 |
TA1#..DLX,STD LH.SCREW |
2 | ||
| 47554 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAK | ||||
| 47554-12011 |
TA1# |
2 | ||
| 47554-12011 |
TA1#..DLX,STD LH.SCREW |
2 | ||
| 47555 - SPRING, ADJUSTER LOCK(FOR FRONT BRAKE) | ||||
| 47556-14010 |
TA1# LH. |
2 | ||
| 47555-14010 |
TA1# RH. |
2 | ||
| 47556-14011 |
TA1# LH. |
2 | ||
| 47555-14011 |
TA1#..DLX,STD RH. |
2 | ||
| 47555-14011 |
TA1# RH. |
2 | ||
| 47556-14011 |
TA1#..DLX,STD LH. |
2 | ||
| 47555 - SPRING, ADJUSTER LOCK(FOR FRONT BRAKE) | ||||
| 47556-14010 |
TA1# LH. |
2 | ||
| 47555-14010 |
TA1# RH. |
2 | ||
| 47556-14011 |
TA1# LH. |
2 | ||
| 47555-14011 |
TA1#..DLX,STD RH. |
2 | ||
| 47555-14011 |
TA1# RH. |
2 | ||
| 47556-14011 |
TA1#..DLX,STD LH. |
2 | ||
| 47651 - LINING, FRONT BRAKE SHOE(FOR FRONT OR UPPER) | ||||
| 47651-14010 |
TA1#..DLX,STD |
2 | ||
| 47651-14011 |
TA1#..DLX,STD |
2 | ||
| 47652 - LINING, FRONT BRAKE SHOE(FOR REAR OR LOWER) | ||||
| 47651-14010 |
TA1#..DLX,STD |
2 | ||
| 47651-14011 |
TA1#..DLX,STD |
2 | ||
| Common parts | ||||
| 90159-50124 | ||||
| 91611-40814 | ||||
| 94531-01000 | ||||
