TA12-HDF (1970)
Toyota Carina
(7012-7509)DLX,STD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42611 - WHEEL, DISC | ||||
| 42611-22030 |
TA1# 4.5J-13,FOR W/TUBE |
2 | ||
| 42611-22010 |
TA1# |
2 | ||
| 42611-14120 |
TA1#..DLX,STD 4.5J-13,FOR TUBELESS |
2 | ||
| 42611-14060 |
TA1#..DLX,STD 4.5J-13,FOR TUBELESS |
2 | ||
| 42611-20040 |
TA1# 4J-13 |
2 | ||
| 42611-20050 |
TA1#..DLX,STD 4J-13 |
2 | ||
| 42611-22080 |
TA1#..DLX,STD 4.5J-13,FOR TUBELESS |
2 | ||
| 42611-20060 |
TA1#..DLX,STD 4J-13 |
2 | ||
| 42611-22090 |
TA1# 4.5J-13,FOR W/TUBE |
2 | ||
| 42611-14130 |
TA1#..DLX,STD 4.5J-13,FOR W/TUBE |
2 | ||
| 42611B - BOLT, HUB (FOR FRONT AXLE) | ||||
| 90942-02021 |
TA1# |
8 | ||
| 42611C - NUT, HUB (FOR FRONT AXLE) | ||||
| 90942-01007 |
TA10,12 |
8 | ||
| 42611D - WEIGHT, BALANCE(FOR FRONT DISC WHEEL) | ||||
| 90942-03025 |
TA1# 50G. |
1 | ||
| 90942-03017 |
TA1# 20G. |
1 | ||
| 90942-03022 |
TA1# 40G. |
1 | ||
| 90942-03020 |
TA1# 30G. |
1 | ||
| 90942-03027 |
TA1# 60G. |
1 | ||
| 90942-03029 |
TA1# 70G. |
1 | ||
| 90942-03031 |
TA1# 80G. |
1 | ||
| 90942-03041 |
TA1# 10G. |
1 | ||
| 43442 - CAP, KNUCKLE GREASE RETAINER, INNER | ||||
| 43442-14010 |
TA1#..DLX,STD |
2 | ||
| 43445 - GASKET, KNUCKLE GREASE RETAINER CAP | ||||
| 43445-14010 |
TA1#..DLX,STD T=0.3 |
2 | ||
| 43501 - DRUM SUB-ASSY, FRONT BRAKE | ||||
| 43512-20050 |
TA1#..DLX,STD |
1 | ||
| 43512-14010 |
TA1#..DLX,STD |
1 | ||
| 43501A - PIECE, BALANCE (FOR FRONT BRAKE DRUM) | ||||
| 90937-01117 |
TA1#..DLX,STD 10G,10G. |
1 | ||
| 90937-01144 |
TA1#..DLX,STD 50G. |
1 | ||
| 90937-01142 |
TA1#..DLX,STD 30G. |
1 | ||
| 90937-01141 |
TA1#..DLX,STD 20G. |
1 | ||
| 90937-01143 |
TA1#..DLX,STD 40G. |
1 | ||
| 90937-01145 |
TA1#..DLX,STD 10G,60G. |
1 | ||
| 43501B - BOLT, SET (FOR FRONT BRAKE DRUM SETTING) | ||||
| 90113-10007 |
TA1#..DLX,STD |
2 | ||
| 43510 - HUB AND BRAKE DRUM ASSY, FRONT AXLE, RH | ||||
| 43510-19026 |
TA1#..DLX,STD |
1 | ||
| 43510-12060 |
TA1#..DLX,STD |
1 | ||
| 43510-19025 |
TA1#..DLX,STD |
1 | ||
| 43510A - SEAL, OIL (FOR FRONT AXLE HUB) | ||||
| 90311-40108 |
TA1# TA2 40 52 7 |
2 | ||
| 43510B - BEARING, TAPERED ROLLER (FOR FRONT AXLE INNER BEARING) | ||||
| 90368-26027 |
TA1# L44649/L44610 |
2 | ||
| 43510C - BEARING, TAPERED ROLLER (FOR FRONT AXLE OUTER BEARING) | ||||
| 90368-17017 |
TA1# LM 11749/710 |
2 | ||
| 43510D - WASHER, CLAW (FOR STEERING KNUCKLE WASHER) | ||||
| 90214-16010 |
TA1# |
2 | ||
| 43510E - NUT (FOR STEERING KNUCKLE) | ||||
| 90170-16137 |
TA1# |
2 | ||
| 43514 - CAP, FRONT HUB GREASE | ||||
| 43514-20010 |
TA1# |
2 | ||
| 43520 - HUB AND BRAKE DRUM ASSY, FRONT AXLE, LH | ||||
| 43510-19025 |
TA1#..DLX,STD |
1 | ||
| 43510-12060 |
TA1#..DLX,STD |
1 | ||
| 43510-19026 |
TA1#..DLX,STD |
1 | ||
| 43525 - CAP, FRONT WHEEL ADJUSTING LOCK | ||||
| 43525-20011 |
TA1# |
2 | ||
| Common parts | ||||
| 95381-04025 | ||||
(7012-7707)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42611 - WHEEL, DISC | ||||
| 42611-22030 |
TA1# 4.5J-13,FOR W/TUBE |
2 | ||
| 42611-22010 |
TA1# |
2 | ||
| 42611-14120 |
TA1#..DLX,STD 4.5J-13,FOR TUBELESS |
2 | ||
| 42611-14060 |
TA1#..DLX,STD 4.5J-13,FOR TUBELESS |
2 | ||
| 42611-20040 |
TA1# 4J-13 |
2 | ||
| 42611-20050 |
TA1#..DLX,STD 4J-13 |
2 | ||
| 42611-22080 |
TA1#..DLX,STD 4.5J-13,FOR TUBELESS |
2 | ||
| 42611-20060 |
TA1#..DLX,STD 4J-13 |
2 | ||
| 42611-22090 |
TA1# 4.5J-13,FOR W/TUBE |
2 | ||
| 42611-14130 |
TA1#..DLX,STD 4.5J-13,FOR W/TUBE |
2 | ||
| 42611B - BOLT, HUB (FOR FRONT AXLE) | ||||
| 90942-02021 |
TA1# |
8 | ||
| 42611C - NUT, HUB (FOR FRONT AXLE) | ||||
| 90942-01007 |
TA10,12 |
8 | ||
| 42611D - WEIGHT, BALANCE(FOR FRONT DISC WHEEL) | ||||
| 90942-03025 |
TA1# 50G. |
1 | ||
| 90942-03017 |
TA1# 20G. |
1 | ||
| 90942-03022 |
TA1# 40G. |
1 | ||
| 90942-03020 |
TA1# 30G. |
1 | ||
| 90942-03027 |
TA1# 60G. |
1 | ||
| 90942-03029 |
TA1# 70G. |
1 | ||
| 90942-03031 |
TA1# 80G. |
1 | ||
| 90942-03041 |
TA1# 10G. |
1 | ||
| 43510A - SEAL, OIL (FOR FRONT AXLE HUB) | ||||
| 90311-40108 |
TA1# TA2 40 52 7 |
2 | ||
| 43510B - BEARING, TAPERED ROLLER (FOR FRONT AXLE INNER BEARING) | ||||
| 90368-26027 |
TA1# L44649/L44610 |
2 | ||
| 43510C - BEARING, TAPERED ROLLER (FOR FRONT AXLE OUTER BEARING) | ||||
| 90368-17017 |
TA1# LM 11749/710 |
2 | ||
| 43510D - WASHER, CLAW (FOR STEERING KNUCKLE WASHER) | ||||
| 90214-16010 |
TA1# |
2 | ||
| 43510E - NUT (FOR STEERING KNUCKLE) | ||||
| 90170-16137 |
TA1# |
2 | ||
| 43511 - HUB, FRONT AXLE | ||||
| 43502-19015 |
TA1# |
2 | ||
| 43512 - DISC, FRONT | ||||
| 43512-20032 |
TA1# |
2 | ||
| 43514 - CAP, FRONT HUB GREASE | ||||
| 43514-20010 |
TA1# |
2 | ||
| 43525 - CAP, FRONT WHEEL ADJUSTING LOCK | ||||
| 43525-20011 |
TA1# |
2 | ||
| Common parts | ||||
| 91111-71025 | ||||
| 94531-01000 | ||||
| 95381-04025 | ||||
