SV11L-UHPEEC (1983)

Toyota Camry

Production Mar 1983 - Oct 1986
Engine 2SELC
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(8210-8406)

Click highlighted areas on diagram

diagram 52021 52115A 52116A 52119A 52521 52525B 52526B 52535 52536 52537 52538 52543 52544 52611 9010906061 9010906061 9010906061 9011906099 9011910085 9015960165 9017906068 9018906006 9046709030 9046804030
Part # Description Qty Price
52021 - REINFORCEMENT SUB-ASSY, FRONT BUMPER
52021-32030

CV1#,SV1#

W/*UB

 1
52021-32010

CV10,SV1#

 1
52115A - SUPPORT, FRONT BUMPER SIDE, RH
52115-32010

CV1#,SV1#

 1
52116A - SUPPORT, FRONT BUMPER SIDE, LH
52115-32010

CV1#,SV1#

 1
52119A - COVER, FRONT BUMPER
52119-32040

CV10,SV1#

W/O *HC,BLACK

 1
52119-32070

CV10,SV1#..EUR

W/*HC,BLACK

 1
52119-32904

CV1#,SV1#..(GL,GLI)..EUR

W/*UB,W/*HC,PAINTING

 1
52119-32901

CV10,SV1#..GL,GLI

W/O *HC,TREATED FOR PAINTIN

 1
52119-32160

CV1#,SV1#

W/*UB,W/O *HC,BLACK

 1
52119-32903

CV1#,SV1#..GL,GLI

W/*UB,W/O *HC,PAINTING

 1
52119-32130

CV1#,SV1#..EUR

W/P.P. BUMPER,W/O *HC

 1
52119-32902

CV10,SV1#..(GL,GLI)..EUR

W/*HC,TREATED PAINTIN

 1
52119-32140

CV1#,SV1#..EUR

W/P.P. BUMPER,W/*HC

 1
52119-32150

CV1#,SV1#..EUR

W/*UB,W/*HC,BLACK

 1
52521 - RETAINER, FRONT BUMPER, UPPER CENTER
52521-32050

CV1#,SV1#..EUR

W/*UB,W/*HC

 1
52521-32010

CV10,SV1#

W/O *HC

 1
52521-32020

CV10,SV1#..EUR

W/*HC

 1
52521-32040

CV1#,SV1#

W/*UB,W/O *HC

 1
52525B - RETAINER, FRONT BUMPER, LOWER SIDE RH
52526-32010

CV10,SV1#

 1
52526B - RETAINER, FRONT BUMPER, LOWER SIDE LH
52527-32010

CV10,SV1#

 1
52535 - RETAINER, FRONT BUMPER SIDE, RH
52535-32010

CV10,SV1#

 2
52535-32020

CV1#,SV1#

W/*UB

 1
52536 - RETAINER, FRONT BUMPER SIDE, LH
52535-32010

CV10,SV1#

 2
52535-32020

CV1#,SV1#

W/*UB

 1
52537 - RETAINER, FRONT BUMPER END, RH
52537-32020

CV10,SV1#

 1
52537-32030

CV1#,SV1#

W/*UB

 1
52538 - RETAINER, FRONT BUMPER END, LH
52538-32030

CV1#,SV1#

W/*UB

 1
52538-32020

CV10,SV1#

 1
52611 - ABSORBER, FRONT BUMPER ENERGY
52611-32050

CV1#,SV1#

W/*UB

 1
52611-32020

CV10,SV1#

W/O *HC

 1
52611-32030

CV10,SV1#..EUR

W/*HC

 1
Common parts
90109-06061
90119-06099
90119-10085
90159-60165
90179-06068
90189-06006
90467-09030
90468-04030

(8406- )EUR

Click highlighted areas on diagram

diagram 52011A 52012A 52115A 52116A 52119A 52422A 52423A 52526A 52526A 52702 52703 52711 9011906022 9011906106 9011908126 9011908126 9011910085 9015960182 9017905147 9017906119 9018906006
Part # Description Qty Price
52011A - ARM SUB-ASSY, FRONT BUMPER, RH
52011-32040

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
52012A - ARM SUB-ASSY, FRONT BUMPER, LH
52012-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
52115A - SUPPORT, FRONT BUMPER SIDE, RH
52115-32010

CV1#,SV1#

 1
52116A - SUPPORT, FRONT BUMPER SIDE, LH
52115-32010

CV1#,SV1#

 1
52119A - COVER, FRONT BUMPER
52119-32040

CV10,SV1#

W/O *HC,BLACK

 1
52119-32070

CV10,SV1#..EUR

W/*HC,BLACK

 1
52119-32904

CV1#,SV1#..(GL,GLI)..EUR

W/*UB,W/*HC,PAINTING

 1
52119-32901

CV10,SV1#..GL,GLI

W/O *HC,TREATED FOR PAINTIN

 1
52119-32160

CV1#,SV1#

W/*UB,W/O *HC,BLACK

 1
52119-32903

CV1#,SV1#..GL,GLI

W/*UB,W/O *HC,PAINTING

 1
52119-32130

CV1#,SV1#..EUR

W/P.P. BUMPER,W/O *HC

 1
52119-32902

CV10,SV1#..(GL,GLI)..EUR

W/*HC,TREATED PAINTIN

 1
52119-32140

CV1#,SV1#..EUR

W/P.P. BUMPER,W/*HC

 1
52119-32150

CV1#,SV1#..EUR

W/*UB,W/*HC,BLACK

 1
52422A - PAD, FRONT BUMPER, RH
52422-32010

CV1#,SV1#

 1
52423A - PAD, FRONT BUMPER, LH
52423-32010

CV1#,SV1#

 1
52526A - RETAINER, FRONT BUMPER, LOWER NO.1
52565-16020

CV1#,SV1#..EUR

W/P.P. BUMPER

 8
52526-32030

CV1#,SV1#

W/*UB

 1
52526A - RETAINER, FRONT BUMPER, LOWER NO.1
52565-16020

CV1#,SV1#..EUR

W/P.P. BUMPER

 8
52526-32030

CV1#,SV1#

W/*UB

 1
52702 - MOULDING SUB-ASSY, FRONT BUMPER SIDE, RH
52702-32010

CV1#,SV1#

W/*UB

 1
52702-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
52703 - MOULDING SUB-ASSY, FRONT BUMPER SIDE, LH
52703-32010

CV1#,SV1#

W/*UB

 1
52703-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
52711 - MOULDING, FRONT BUMPER
52711-32010

CV1#,SV1#

W/*UB

 1
52711-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
Common parts
90119-06022
90119-06106
90119-08126
90119-10085
90159-60182
90179-05147
90179-06119
90189-06006

(8406- )

Click highlighted areas on diagram

diagram 52021 52115A 52116A 52119A 52422A 52423A 52521 52526A 52535 52536 52537 52538 52539 52549 52611 52702 52703 52711 9010906061 9011906022 9011906106 9011910085 9015960165 9017905147 9017905147 9017906068 9018906006 9046709030 9046804030
Part # Description Qty Price
52021 - REINFORCEMENT SUB-ASSY, FRONT BUMPER
52021-32030

CV1#,SV1#

W/*UB

 1
52021-32010

CV10,SV1#

 1
52115A - SUPPORT, FRONT BUMPER SIDE, RH
52115-32010

CV1#,SV1#

 1
52116A - SUPPORT, FRONT BUMPER SIDE, LH
52115-32010

CV1#,SV1#

 1
52119A - COVER, FRONT BUMPER
52119-32040

CV10,SV1#

W/O *HC,BLACK

 1
52119-32070

CV10,SV1#..EUR

W/*HC,BLACK

 1
52119-32904

CV1#,SV1#..(GL,GLI)..EUR

W/*UB,W/*HC,PAINTING

 1
52119-32901

CV10,SV1#..GL,GLI

W/O *HC,TREATED FOR PAINTIN

 1
52119-32160

CV1#,SV1#

W/*UB,W/O *HC,BLACK

 1
52119-32903

CV1#,SV1#..GL,GLI

W/*UB,W/O *HC,PAINTING

 1
52119-32130

CV1#,SV1#..EUR

W/P.P. BUMPER,W/O *HC

 1
52119-32902

CV10,SV1#..(GL,GLI)..EUR

W/*HC,TREATED PAINTIN

 1
52119-32140

CV1#,SV1#..EUR

W/P.P. BUMPER,W/*HC

 1
52119-32150

CV1#,SV1#..EUR

W/*UB,W/*HC,BLACK

 1
52422A - PAD, FRONT BUMPER, RH
52422-32010

CV1#,SV1#

 1
52423A - PAD, FRONT BUMPER, LH
52423-32010

CV1#,SV1#

 1
52521 - RETAINER, FRONT BUMPER, UPPER CENTER
52521-32050

CV1#,SV1#..EUR

W/*UB,W/*HC

 1
52521-32010

CV10,SV1#

W/O *HC

 1
52521-32020

CV10,SV1#..EUR

W/*HC

 1
52521-32040

CV1#,SV1#

W/*UB,W/O *HC

 1
52526A - RETAINER, FRONT BUMPER, LOWER NO.1
52565-16020

CV1#,SV1#..EUR

W/P.P. BUMPER

 8
52526-32030

CV1#,SV1#

W/*UB

 1
52535 - RETAINER, FRONT BUMPER SIDE, RH
52535-32010

CV10,SV1#

 2
52535-32020

CV1#,SV1#

W/*UB

 1
52536 - RETAINER, FRONT BUMPER SIDE, LH
52535-32010

CV10,SV1#

 2
52535-32020

CV1#,SV1#

W/*UB

 1
52537 - RETAINER, FRONT BUMPER END, RH
52537-32020

CV10,SV1#

 1
52537-32030

CV1#,SV1#

W/*UB

 1
52538 - RETAINER, FRONT BUMPER END, LH
52538-32030

CV1#,SV1#

W/*UB

 1
52538-32020

CV10,SV1#

 1
52539 - RETAINER, FRONT BUMPER SIDE, NO.3 RH
52539-32010

CV1#,SV1#

W/*UB

 1
52549 - RETAINER, FRONT BUMPER SIDE, NO.3 LH
52549-32010

CV1#,SV1#

W/*UB

 1
52611 - ABSORBER, FRONT BUMPER ENERGY
52611-32050

CV1#,SV1#

W/*UB

 1
52611-32020

CV10,SV1#

W/O *HC

 1
52611-32030

CV10,SV1#..EUR

W/*HC

 1
52702 - MOULDING SUB-ASSY, FRONT BUMPER SIDE, RH
52702-32010

CV1#,SV1#

W/*UB

 1
52702-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
52703 - MOULDING SUB-ASSY, FRONT BUMPER SIDE, LH
52703-32010

CV1#,SV1#

W/*UB

 1
52703-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
52711 - MOULDING, FRONT BUMPER
52711-32010

CV1#,SV1#

W/*UB

 1
52711-32020

CV1#,SV1#..EUR

W/P.P. BUMPER

 1
Common parts
90109-06061
90119-06022
90119-06106
90119-10085
90159-60165
90179-05147
90179-06068
90189-06006
90467-09030
90468-04030
