KPX10L-EHDGSC (2020)
Toyota C-Hr(China)
Production
May 2020
-
Sep 9999
Engine
4KM
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(2005- )D,N
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81496 - GUIDE, REAR COMBINATION LAMP | ||||
| 81496-0D030 |
KPX10 |
4 | ||
| 81496B - GUIDE, REAR LAMP | ||||
| 76817-26040 |
KPX10 |
2 | ||
| 81496C - GUIDE, REAR COMBINATION LAMP, NO.2 | ||||
| 90467-C0019 |
KPX10 |
2 | ||
| 81497 - COVER, REAR COMBINATION LAMP, RH | ||||
| 81497-F4040 |
KPX10 |
1 | ||
| 81498 - COVER, REAR COMBINATION LAMP, LH | ||||
| 81498-F4040 |
KPX10 |
1 | ||
| 81536C - LED, TAIL & STOP LAMP | ||||
| 81536-F4080 |
KPX10..D,N |
2 | ||
| 81550 - LAMP ASSY, REAR COMBINATION, RH | ||||
| 81550-F4110 |
KPX10..G |
1 | ||
| 81550-F4101 |
KPX10..D,N |
1 | ||
| 81550L - BULB, REAR TURN SIGNAL LAMP | ||||
| 90981-15029 |
KPX10..D,N 12V 21W,AMBER |
2 | ||
| 81550N - BULB, BACK UP LAMP | ||||
| 90981-11059 |
KPX10..D,N 12V 16W |
2 | ||
| 81550P - SOCKET, BACK UP LAMP | ||||
| 90069-81119 |
KPX10..D,N |
2 | ||
| 81551D - LENS & BODY, REAR COMBINATION LAMP, RH | ||||
| 81551-F4101 |
KPX10..D,N |
1 | ||
| 81555H - SOCKET & WIRE, REAR COMBINATION LAMP | ||||
| 81555-F4080 |
KPX10..D,N |
2 | ||
| 81560 - LAMP ASSY, REAR COMBINATION, LH | ||||
| 81560-F4101 |
KPX10..D,N |
1 | ||
| 81560-F4110 |
KPX10..G |
1 | ||
| 81561D - LENS & BODY, REAR COMBINATION LAMP, LH | ||||
| 81561-F4101 |
KPX10..D,N |
1 | ||
| 81580D - LAMP ASSY, REAR, RH | ||||
| 81580-F4080 |
KPX10..G |
1 | ||
| 81580-F4071 |
KPX10..D,N |
1 | ||
| 81581C - LENS AND BODY, REAR LAMP, RH | ||||
| 81581-F4071 |
KPX10..D,N |
1 | ||
| 81584A - GASKET, REAR LAMP RH | ||||
| 81584-F4060 |
KPX10..G |
1 | ||
| 81584-F4050 |
KPX10..D,N |
1 | ||
| 81590A - LAMP ASSY, REAR, LH | ||||
| 81590-F4080 |
KPX10..G |
1 | ||
| 81590-F4071 |
KPX10..D,N |
1 | ||
| 81591B - LENS AND BODY, REAR LAMP, LH | ||||
| 81591-F4071 |
KPX10..D,N |
1 | ||
| 81594A - GASKET, REAR LAMP LH | ||||
| 81594-F4060 |
KPX10..G |
1 | ||
| 81594-F4050 |
KPX10..D,N |
1 | ||
| Common parts | ||||
| 90069-32081 | ||||
| 90159-60621 | ||||
| 90176-C0002 | ||||
| 90178-C0057 | ||||
| 90189-06235 | ||||
| 90189-06242 | ||||
(2005- )G
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81496 - GUIDE, REAR COMBINATION LAMP | ||||
| 81496-0D030 |
KPX10 |
4 | ||
| 81496B - GUIDE, REAR LAMP | ||||
| 76817-26040 |
KPX10 |
2 | ||
| 81496C - GUIDE, REAR COMBINATION LAMP, NO.2 | ||||
| 90467-C0019 |
KPX10 |
2 | ||
| 81497 - COVER, REAR COMBINATION LAMP, RH | ||||
| 81497-F4040 |
KPX10 |
1 | ||
| 81498 - COVER, REAR COMBINATION LAMP, LH | ||||
| 81498-F4040 |
KPX10 |
1 | ||
| 81550 - LAMP ASSY, REAR COMBINATION, RH | ||||
| 81550-F4110 |
KPX10..G |
1 | ||
| 81550-F4101 |
KPX10..D,N |
1 | ||
| 81560 - LAMP ASSY, REAR COMBINATION, LH | ||||
| 81560-F4101 |
KPX10..D,N |
1 | ||
| 81560-F4110 |
KPX10..G |
1 | ||
| 81580D - LAMP ASSY, REAR, RH | ||||
| 81580-F4080 |
KPX10..G |
1 | ||
| 81580-F4071 |
KPX10..D,N |
1 | ||
| 81584A - GASKET, REAR LAMP RH | ||||
| 81584-F4060 |
KPX10..G |
1 | ||
| 81584-F4050 |
KPX10..D,N |
1 | ||
| 81585C - SOCKET & WIRE, REAR LAMP, RH | ||||
| 81585-F4060 |
KPX10..G |
1 | ||
| 81590A - LAMP ASSY, REAR, LH | ||||
| 81590-F4080 |
KPX10..G |
1 | ||
| 81590-F4071 |
KPX10..D,N |
1 | ||
| 81594A - GASKET, REAR LAMP LH | ||||
| 81594-F4060 |
KPX10..G |
1 | ||
| 81594-F4050 |
KPX10..D,N |
1 | ||
| 81595 - SOCKET & WIRE, REAR LAMP, LH | ||||
| 81585-F4060 |
KPX10..G |
1 | ||
| Common parts | ||||
| 90159-60621 | ||||
| 90176-C0002 | ||||
| 90178-C0057 | ||||
| 90189-06235 | ||||
| 90189-06242 | ||||
