NLP130L-CGFGXW (2011)
Toyota Yaris/Hybrid (Frp)
(1107- )3D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 62111B - CLIP(FOR COWL SIDE TRIM) | ||||
| 90467-10161 |
KSP130,NHP130,NLP130,NSP130 |
2 | ||
| 62111C - BOARD, COWL SIDE TRIM, RH | ||||
| 62111-0D120C0 |
KSP130,NHP130,NLP130,NSP130 BLACK,TRIM1# |
1 | ||
| 62112 - BOARD, COWL SIDE TRIM, LH | ||||
| 62112-0D120C0 |
KSP130,NHP130,NLP130,NSP130..LHD BLACK,TRIM1# |
1 | ||
| 62117B - CLIP, NO.1(FOR COWL SIDE TRIM) | ||||
| 90467-06193C0 |
KSP130,NHP130,NLP130,NSP130 BLACK,TRIM1# |
2 | ||
| 62170A - AIR BAG ASSY, CURTAIN SHIELD, RH | ||||
| 62170-0D030 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
1 | ||
| 62170-0D030 |
KSP130,NLP130,NSP130..5F,6F,CVFC REGULATION COMPLIANCE LABEL & NAME PLATE-EUROPE NTA NAME PLATE(EXCEPT WVTA)&VSC-WITHOUT |
1 | ||
| 62170-0D031 |
KSP130,NHP130,NLP130,NSP130 |
1 | ||
| 62170-0D030 |
KSP130,NLP130,NSP130..LHD..(5F,6F,CVFC) TURKEY SPEC&VSC-WITHOUT |
1 | ||
| 62170-0D031 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
1 | ||
| 62170-0D030 |
KSP130,NHP130,NLP130,NSP130 |
1 | ||
| 62170-0D031 |
KSP130,NLP130,NSP130..LHD..(5F,6F,CVFC) TURKEY SPEC&VSC-WITHOUT |
1 | ||
| 62170-0D031 |
KSP130,NLP130,NSP130..5F,6F,CVFC REGULATION COMPLIANCE LABEL & NAME PLATE-EUROPE NTA NAME PLATE(EXCEPT WVTA)&VSC-WITHOUT |
1 | ||
| 62170B - BOLT, W/WASHER | ||||
| 90119-06869 |
KSP130,NLP130,NSP130..5F,6F,CVFC REGULATION COMPLIANCE LABEL & NAME PLATE-EUROPE NTA NAME PLATE(EXCEPT WVTA)&VSC-WITHOUT |
2 | ||
| 90119-06869 |
KSP130,NHP130,NLP130,NSP130 |
2 | ||
| 90119-06869 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
2 | ||
| 90119-06869 |
KSP130,NLP130,NSP130..LHD..(5F,6F,CVFC) TURKEY SPEC&VSC-WITHOUT |
2 | ||
| 62180A - AIR BAG ASSY, CURTAIN SHIELD, LH | ||||
| 62180-0D030 |
KSP130,NHP130,NLP130,NSP130 |
1 | ||
| 62180-0D030 |
KSP130,NLP130,NSP130..5F,6F,CVFC REGULATION COMPLIANCE LABEL & NAME PLATE-EUROPE NTA NAME PLATE(EXCEPT WVTA)&VSC-WITHOUT |
1 | ||
| 62180-0D031 |
KSP130,NHP130,NLP130,NSP130 |
1 | ||
| 62180-0D031 |
KSP130,NLP130,NSP130..5F,6F,CVFC REGULATION COMPLIANCE LABEL & NAME PLATE-EUROPE NTA NAME PLATE(EXCEPT WVTA)&VSC-WITHOUT |
1 | ||
| 62180-0D030 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
1 | ||
| 62180-0D031 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
1 | ||
| 62180-0D030 |
KSP130,NLP130,NSP130..LHD..(5F,6F,CVFC) TURKEY SPEC&VSC-WITHOUT |
1 | ||
| 62180-0D031 |
KSP130,NLP130,NSP130..LHD..(5F,6F,CVFC) TURKEY SPEC&VSC-WITHOUT |
1 | ||
| 62189A - SPACER, CURTAIN SHIELD AIR BAG CLIP | ||||
| 62189-33010 |
KSP130,NLP130,NSP130..5F,6F,CVFC REGULATION COMPLIANCE LABEL & NAME PLATE-EUROPE NTA NAME PLATE(EXCEPT WVTA)&VSC-WITHOUT |
12 | ||
| 62189-33010 |
KSP130,NLP130,NSP130..LHD..(5F,6F,CVFC) TURKEY SPEC&VSC-WITHOUT |
12 | ||
| 62189-33010 |
KSP130,NHP130,NLP130,NSP130 |
12 | ||
| 62189-33010 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
12 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62211-0D230B0 |
NLP130;KSP130,NSP130..ACTIV,LOUNG,STYLE LT.GRAY,TRIM1# |
1 | ||
| 62211-0D260B0 |
NSP130..LOUNG,STYLE;KSP130,NLP130..LHD..(5F,6F)..(LOUNG,STYLE) VSC-WITHOUT&AUDIO-DISPLAY 8SPEAKER BLUETOOTH,LT.GRAY,TRIM1# |
1 | ||
| 62211-0D220B0 |
NLP130..LHD..6F;KSP130,NSP130..ACTIV,LOUNG,STYLE VSC-WITHOUT,LT.GRAY,TRIM1# |
1 | ||
| 62211-0D430B0 |
NLP130,NSP130..LHD..ACTIV;NLP130,NSP130..LOUNG,STYLE;KSP130..LHD..(ACTIV,LOUNG) AUDIO-DISPLAY 8SPEAKER BLUETOOTH,LT.GRAY,TRIM1# |
1 | ||
| 62211-0D410B0 |
NLP130;KSP130,NHP130,NSP130..ACTIV,LOUNG,STYLE LT.GRAY,TRIM1# |
1 | ||
| 62211-0D240B0 |
KSP130..LHD..LOUNG;NLP130,NSP130..LOUNG,STYLE AUDIO-DISPLAY 8SPEAKER BLUETOOTH,LT.GRAY,TRIM1# |
1 | ||
| 62211T - CLIP(FOR FRONT PILLAR GARNISH) | ||||
| 90467-10161 |
KSP130,NHP130,NLP130,NSP130 |
2 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62212-0D260B0 |
NSP130..LOUNG,STYLE;KSP130,NLP130..LHD..(5F,6F)..(LOUNG,STYLE) VSC-WITHOUT&AUDIO-DISPLAY 8SPEAKER BLUETOOTH,LT.GRAY,TRIM1# |
1 | ||
| 62212-0D220B0 |
NLP130..LHD..6F;KSP130,NSP130..ACTIV,LOUNG,STYLE VSC-WITHOUT,LT.GRAY,TRIM1# |
1 | ||
| 62212-0D430B0 |
NLP130,NSP130..LHD..ACTIV;NLP130,NSP130..LOUNG,STYLE;KSP130..LHD..(ACTIV,LOUNG) AUDIO-DISPLAY 8SPEAKER BLUETOOTH,LT.GRAY,TRIM1# |
1 | ||
| 62212-0D240B0 |
KSP130..LHD..LOUNG;NLP130,NSP130..LOUNG,STYLE AUDIO-DISPLAY 8SPEAKER BLUETOOTH,LT.GRAY,TRIM1# |
1 | ||
| 62212-0D410B0 |
NLP130;KSP130,NHP130,NSP130..ACTIV,LOUNG,STYLE LT.GRAY,TRIM1# |
1 | ||
| 62212-0D230B0 |
NLP130;KSP130,NSP130..ACTIV,LOUNG,STYLE LT.GRAY,TRIM1# |
1 | ||
| 62217G - CLIP, FRONT PILLAR GARNISH | ||||
| 62217-52030 |
KSP130,NLP130,NSP130 LH |
1 | ||
| 62217-52050 |
KSP130,NLP130,NSP130 RH |
1 | ||
| 62217-52110 |
KSP130,NHP130,NLP130,NSP130 RH |
1 | ||
| 62217-52100 |
KSP130,NHP130,NLP130,NSP130 LH |
1 | ||
| 90467-10161 |
NSP130..LOUNG,STYLE;KSP130,NLP130..LHD..(5F,6F)..(LOUNG,STYLE) VSC-WITHOUT&AUDIO-DISPLAY 8SPEAKER BLUETOOTH |
2 | ||
| 90467-10161 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
2 | ||
| 62217G - CLIP, FRONT PILLAR GARNISH | ||||
| 62217-52030 |
KSP130,NLP130,NSP130 LH |
1 | ||
| 62217-52050 |
KSP130,NLP130,NSP130 RH |
1 | ||
| 62217-52110 |
KSP130,NHP130,NLP130,NSP130 RH |
1 | ||
| 62217-52100 |
KSP130,NHP130,NLP130,NSP130 LH |
1 | ||
| 90467-10161 |
NSP130..LOUNG,STYLE;KSP130,NLP130..LHD..(5F,6F)..(LOUNG,STYLE) VSC-WITHOUT&AUDIO-DISPLAY 8SPEAKER BLUETOOTH |
2 | ||
| 90467-10161 |
KSP130,NSP130;NLP130..LHD..6F VSC-WITHOUT |
2 | ||
| 62223D - PLATE, FRONT PILLAR GARNISH, UPPER RH | ||||
| 62223-0D010 |
KSP130..LHD..LOUNG;NLP130,NSP130..LOUNG,STYLE AUDIO-DISPLAY 8SPEAKER BLUETOOTH |
1 | ||
| 62223-0D010 |
NSP130..LOUNG,STYLE;KSP130,NLP130..LHD..(5F,6F)..(LOUNG,STYLE) VSC-WITHOUT&AUDIO-DISPLAY 8SPEAKER BLUETOOTH |
1 | ||
| 62224B - PLATE, FRONT PILLAR GARNISH, UPPER LH | ||||
| 62224-0D010 |
KSP130..LHD..LOUNG;NLP130,NSP130..LOUNG,STYLE AUDIO-DISPLAY 8SPEAKER BLUETOOTH |
1 | ||
| 62224-0D010 |
NSP130..LOUNG,STYLE;KSP130,NLP130..LHD..(5F,6F)..(LOUNG,STYLE) VSC-WITHOUT&AUDIO-DISPLAY 8SPEAKER BLUETOOTH |
1 | ||
| 62311B - WEATHERSTRIP, FRONT DOOR OPENING TRIM, RH | ||||
| 62311-0D160 |
KSP130,NLP130,NSP130..3D |
1 | ||
| 62312B - WEATHERSTRIP, FRONT DOOR OPENING TRIM, LH | ||||
| 62312-0D150 |
KSP130,NLP130,NSP130..3D |
1 | ||
| 62401A - CLIP (FOR CENTER PILLAR GARNISH PANEL, UPPER) | ||||
| 90467-10167 |
KSP130,NHP130,NLP130,NSP130 |
2 | ||
| 62411B - GARNISH, CENTER PILLAR, UPPER RH | ||||
| 62411-0D190B0 |
NLP130..3D LT.GRAY,TRIM1# |
1 | ||
| 62412B - GARNISH, CENTER PILLAR, UPPER LH | ||||
| 62412-0D190B0 |
NLP130..3D LT.GRAY,TRIM1# |
1 | ||
| 62451A - CLIP, SIDE GARNISH | ||||
| 90467-10167 |
KSP130,NLP130,NSP130..3D RH |
3 | ||
| 90467-10161 |
KSP130,NLP130,NSP130..3D LH |
3 | ||
| 62451C - GARNISH, ROOF SIDE RAIL, REAR RH | ||||
| 62451-0D020B0 |
KSP130,NLP130,NSP130..3D LT.GRAY,TRIM1# |
1 | ||
| 62452C - GARNISH, ROOF SIDE RAIL, REAR LH | ||||
| 62452-0D020B0 |
KSP130,NLP130,NSP130..3D LT.GRAY,TRIM1# |
1 | ||
| 62471A - GARNISH, ROOF SIDE, INNER RH | ||||
| 62471-0D360B0 |
KSP130,NSP130..3D;NLP130..LHD..3D..6F VSC-WITHOUT,LT.GRAY,TRIM1# |
1 | ||
| 62471-0D350B0 |
KSP130,NLP130,NSP130..3D LT.GRAY,TRIM1# |
1 | ||
| 62471J - CLIP (FOR ROOF SIDE GARNISH) | ||||
| 90467-A0033 |
KSP130,NHP130,NLP130,NSP130 |
6 | ||
| 62472A - GARNISH, ROOF SIDE, INNER LH | ||||
| 62472-0D400B0 |
KSP130,NSP130..3D;NLP130..LHD..3D..6F VSC-WITHOUT,LT.GRAY,TRIM1# |
1 | ||
| 62472-0D390B0 |
KSP130,NLP130,NSP130..3D LT.GRAY,TRIM1# |
1 | ||
| 62472G - CLIP(FOR ROOF SIDE GARNISH) | ||||
| 63395-12150 |
KSP130,NLP130,NSP130..3D |
4 | ||
| 62510P - PANEL ASSY, QUARTER TRIM, FRONT RH | ||||
| 62510-0D080C0 |
KSP130,NLP130,NSP130..3D BLACK,TRIM1# |
1 | ||
| 62511B - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 90467-10161 |
KSP130,NLP130,NSP130..3D |
8 | ||
| 62511G - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 63395-12150 |
KSP130,NLP130,NSP130..3D |
6 | ||
| 62520P - PANEL ASSY, QUARTER TRIM, FRONT LH | ||||
| 62520-0D080C0 |
KSP130,NLP130,NSP130..3D BLACK,TRIM1# |
1 | ||
| 67913 - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-0D200C0 |
KSP130,NLP130,NSP130..3D BLACK,TRIM1# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-0D190C0 |
KSP130,NLP130,NSP130..3D BLACK,TRIM1# |
1 | ||
| Common parts | ||||
| 90167-W0007 | ||||
| 90189-05096 | ||||
| 90467-10161 | ||||
| 90467-15033 | ||||
| Linked diagrams | ||||
| 7104 | ||||
