RY12L-JR (1971)
Toyota Toyoace
Production
Sep 1971
-
Feb 1979
Engine
12R
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(7109-7902)RY10,12
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31121 - COVER, CLUTCH HOUSING, NO.1 | ||||
| 31121-35010 |
RY1# |
1 | ||
| 31121-25010 |
RY10,12 |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18081 |
RY1# |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 12157-10010 |
JY16,RY1# |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33111-35010 |
RY10,12 |
1 | ||
| 33111-25030 |
RY1# |
1 | ||
| 33111A - PLUG, MANUAL TRANSMISSION CASE | ||||
| 90341-18002 |
JY16,RY1# |
1 | ||
| 33111X - GASKET, TRANSMISSION CASE PLUG | ||||
| 12157-10010 |
JY16,RY1# |
1 | ||
| 33131 - RETAINER, BEARING, FRONT(MTM) | ||||
| 33131-35011 |
RY1# |
1 | ||
| 33131-35010 |
RY1# |
1 | ||
| 33131A - SEAL, OIL(FOR TRANSMISSION FRONT BEARING RETAINER) | ||||
| 90311-28004 |
RY1# |
1 | ||
| 90311-25001 |
RY1# |
1 | ||
| 90311-25141 |
RY1# |
1 | ||
| 90311-28003 |
RY1# |
1 | ||
| 33132 - GASKET, FRONT BEARING RETAINER(MTM) | ||||
| 33132-35010 |
RY1# |
1 | ||
| 33141 - RETAINER, TRANSMISSION BEARING, REAR | ||||
| 33141-35021 |
RY1# |
1 | ||
| 33141-35020 |
RY1# |
1 | ||
| 33141A - SEAL, OIL(FOR TRANSMISSION REAR BEARING RETAINER) | ||||
| 90311-38093 |
RY1# |
1 | ||
| 33157 - GASKET, TRANSMISSION CASE, NO.2 | ||||
| 33142-35010 |
RY1# |
1 | ||
| 33142-35011 |
RY1# |
1 | ||
| 33161 - COVER, MANUAL TRANSMISSION POWER TAKE-OFF | ||||
| 33161-35010 |
RY1# |
1 | ||
| 36633 - GASKET, POWER TAKE-OFF | ||||
| 33162-35010 |
RY1# |
1 | ||
| Common parts | ||||
| 90119-08115 | ||||
| 90119-10188 | ||||
| 91111-70832 | ||||
| 91111-70836 | ||||
| 91111-70850 | ||||
| 91611-40812 | ||||
| 91611-61030 | ||||
| 91611-61032 | ||||
| 91611-61050 | ||||
| 93180-18012 | ||||
| 94512-00800 | ||||
| 94611-10800 | ||||
