AL20R-ZGHNSW (1982)
Toyota Tercel
(8205- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83710 - CABLE ASSY, SPEEDOMETER DRIVE, NO.1 | ||||
| 83710-16070 |
AL20..RHD..3FC METER-ADAPTER |
1 | ||
| 83710-16100 |
AL20,21..3FC MISSION-ADAPTER |
1 | ||
| 83710 - CABLE ASSY, SPEEDOMETER DRIVE, NO.1 | ||||
| 83710-16070 |
AL20..RHD..3FC METER-ADAPTER |
1 | ||
| 83710-16100 |
AL20,21..3FC MISSION-ADAPTER |
1 | ||
| 83710 - CABLE ASSY, SPEEDOMETER DRIVE, NO.1 | ||||
| 83710-16070 |
AL20..RHD..3FC METER-ADAPTER |
1 | ||
| 83710-16100 |
AL20,21..3FC MISSION-ADAPTER |
1 | ||
| Common parts | ||||
| 82711-12220 | ||||
| 83791-16030 | ||||
| 93567-55016 | ||||
(8205- )DLX,GL,SR5..ARL,EUR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
AL2# 12V 3.4W |
7 | ||
| 90981-11018 |
AL2# 12V 1.2W W/O SOCKET |
5 | ||
| 83109-28010 |
AL2#..ARL,EUR 12V3.4W W(GREEN CAP) |
3 | ||
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
AL2# 12V 3.4W |
7 | ||
| 90981-11018 |
AL2# 12V 1.2W W/O SOCKET |
5 | ||
| 83109-28010 |
AL2#..ARL,EUR 12V3.4W W(GREEN CAP) |
3 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14030 |
AL20,25..RHD 12V 3.4W |
7 | ||
| 83101-14040 |
AL2# 12V 1.4W |
5 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-14030 |
AL20,25..RHD 12V 3.4W |
7 | ||
| 83101-14040 |
AL2# 12V 1.4W |
5 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83247-1G050 |
AL20,25..RHD..EUG W/CLOCK |
1 | ||
| 83247-1G030 |
AL20,25..RHD..EUG |
1 | ||
| 83247-16590 |
AL20,25..RHD..EUG W/TACHOMETER & DIGITAL CLOCK |
1 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83247-1G050 |
AL20,25..RHD..EUG W/CLOCK |
1 | ||
| 83247-1G030 |
AL20,25..RHD..EUG |
1 | ||
| 83247-16590 |
AL20,25..RHD..EUG W/TACHOMETER & DIGITAL CLOCK |
1 | ||
| 83110 - SPEEDOMETER ASSY | ||||
| 83110-16420 |
AL20,25..RHD..EUG |
1 | ||
| 83110-16421 |
AL20,25..RHD..EUG |
1 | ||
| 83110-16430 |
AL20,25..RHD..EUG W/*TAC |
1 | ||
| 83110-16431 |
AL20,25..RHD..EUG W/*TAC |
1 | ||
| 83128 - KNOB, TRIP COUNTER | ||||
| 83128-16090 |
AL2#..(DLX,GL)..EUR W/TACHOMETER |
1 | ||
| 83128-16110 |
AL25..SR5;AL20,25..RHD..(EUR,GEN) |
1 | ||
| 83132 - CASE, COMBINATION METER | ||||
| 83132-16470 |
AL20,25..RHD..EUG W/TACHOMETER |
1 | ||
| 83132-16570 |
AL20,25..RHD..EUG |
1 | ||
| 83134 - COVER, COMBINATION METER, NO.1 | ||||
| 83133-16530 |
AL20,25..RHD..EUG |
1 | ||
| 83133-16450 |
AL20,25..RHD..EUG W/TACHOMETER & DIGITAL CLOCK |
1 | ||
| 83133-16650 |
AL20,25..RHD..EUG W/TACHOMETER & DIGITAL CLOCK |
1 | ||
| 83133-16510 |
AL20,25..RHD..EUG W/CLOCK |
1 | ||
| 83270 - TACHOMETER ASSY, ENGINE | ||||
| 83242-16130 |
AL20,25..RHD..EUG |
1 | ||
| 83310 - GAGE ASSY, FUEL RECEIVER | ||||
| 83243-16350 |
AL20,25..RHD..EUG W/TACHOMETER |
1 | ||
| 83243-16410 |
AL20,25..RHD..EUG |
1 | ||
| 83410 - GAGE ASSY, WATER TEMPERATURE RECEIVER | ||||
| 83244-16370 |
AL20,25..RHD..EUG W/TACHOMETER |
1 | ||
| 83909 - KNOB, CLOCK | ||||
| 83909-14012 |
AL2#..DLX,GL,STD ANALOGUE |
1 | ||
| 83909-16050 |
AL2#..(DLX,GL)..EUR DIGITAL |
1 | ||
| 83910 - CLOCK ASSY | ||||
| 83910-16050 |
AL20,25..RHD..EUG DIGITAL |
1 | ||
| 83910-16060 |
AL2#..DLX,GL,STD ANALOGUE |
1 | ||
| 83919 - SCREW, CLOCK | ||||
| 83919-12230 |
AL2#..(DLX,GL)..EUR DIGITAL |
1 | ||
| 83919-14012 |
AL2#..DLX,GL,STD ANALOGUE |
1 | ||
| Common parts | ||||
| 90099-00909 | ||||
| 90099-00917 | ||||
| 90099-00929 | ||||
| 90099-00944 | ||||
