MA70R-BLPVF (1988)
Toyota Supra
(8808- )7MGTE ; (8808- )7MGE..GEN,V ; (8908- )7MGE..4FC..C
12V 80A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27060-42030 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) 12V 80A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27064 - SEAL, ALTERNATOR PLATE | ||||
| 27064-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10160 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27330-76030 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10140 |
7MG#..MA70 |
1 | ||
| 90099-10140 |
7MG#..MA70 |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-50040 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27357-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27384 - WASHER | ||||
| 27384-50030 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27384-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27388 - COVER, ALTERNATOR BRUSH | ||||
| 27388-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-42030 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27443 - COVER, ALTERNATOR BEARING | ||||
| 27443-63020 |
7MG#..MA70 |
1 | ||
| 27443-63020 |
7MG#..MA70 |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-16010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| Common parts | ||||
| 27387-42020 | ||||
| 27389-42010 | ||||
| 90099-00195 | ||||
| 90099-00197 | ||||
| 90099-04966 | ||||
| 90099-05171 | ||||
| 90099-05172 | ||||
| 90099-05232 | ||||
| 90105-10017 | ||||
| 90119-08682 | ||||
| 90179-08146 | ||||
| 90179-10016 | ||||
| 93319-14025 | ||||
(8808- )
12V 70A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27060-42030 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) 12V 80A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10160 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27330-76030 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10140 |
7MG#..MA70 |
1 | ||
| 90099-10140 |
7MG#..MA70 |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-50040 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27357-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-42030 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27443 - COVER, ALTERNATOR BEARING | ||||
| 27443-63020 |
7MG#..MA70 |
1 | ||
| 27443-63020 |
7MG#..MA70 |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-16010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| Common parts | ||||
| 27387-70170 | ||||
| 27389-63020 | ||||
| 90099-00949 | ||||
| 90099-00959 | ||||
| 90099-04966 | ||||
| 90099-05119 | ||||
| 90099-05171 | ||||
| 90099-05172 | ||||
| 90105-10017 | ||||
| 90119-08682 | ||||
| 90179-06158 | ||||
| 90179-10016 | ||||
| 93319-14025 | ||||
(8808- )
12V 80A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27060-42030 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) 12V 80A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27064 - SEAL, ALTERNATOR PLATE | ||||
| 27064-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10160 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27330-76030 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10140 |
7MG#..MA70 |
1 | ||
| 90099-10140 |
7MG#..MA70 |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-50040 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27357-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27384 - WASHER | ||||
| 27384-50030 |
7MGTE..MA70;7MGE..MA70..GEN,V;7MGE..MA70..4FC..C |
1 | ||
| 27384-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27388 - COVER, ALTERNATOR BRUSH | ||||
| 27388-42010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-42030 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| 27443 - COVER, ALTERNATOR BEARING | ||||
| 27443-63020 |
7MG#..MA70 |
1 | ||
| 27443-63020 |
7MG#..MA70 |
1 | ||
| 27700A - REGULATOR ASSY, GENERATOR | ||||
| 27700-16010 |
7MGTE..MA70;7MGE..MA70..4FC;7MGE..MA70..5F..(GEN,V) |
1 | ||
| Common parts | ||||
| 27387-42020 | ||||
| 27389-42010 | ||||
| 90099-00195 | ||||
| 90099-00197 | ||||
| 90099-04966 | ||||
| 90099-05171 | ||||
| 90099-05172 | ||||
| 90099-05232 | ||||
| 90105-10017 | ||||
| 90119-08682 | ||||
| 90179-08146 | ||||
| 90179-10016 | ||||
| 93319-14025 | ||||
