MA70L-BLPVFA (1988)
Toyota Supra
(8808- )4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-06144 | ||||
| 90159-40109 | ||||
| 90179-08041 | ||||
| 90463-12570 | ||||
| 90468-14004 | ||||
| 90468-14011 | ||||
| 93315-15012 | ||||
| 94120-40800 | ||||
| 94512-00800 | ||||
| 94613-10800 | ||||
| Linked diagrams | ||||
| 8410 | ||||
(8808- )4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33058 - BRACKET SUB-ASSY, SHIFT LOCK SOLENOID | ||||
| 33058-14020 |
MA70..4FC |
1 | ||
| 33501G - BUSH (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90385-11003 |
MA70..4FC |
2 | ||
| 33501G - BUSH (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90385-11003 |
MA70..4FC |
2 | ||
| 33502 - PLATE SUB-ASSY, SHIFT LEVER | ||||
| 33502-14160 |
MA70..4FC |
1 | ||
| 33502A - COLLAR (FOR FLOOR SHIFT SETTING) | ||||
| 90387-06065 |
MA70..4FC OD=8.8 |
4 | ||
| 33503A - COLLAR(FOR SHIFT LEVER) | ||||
| 90387-08095 |
MA70..4FC |
1 | ||
| 33503F - LEVER SUB-ASSY, SHIFT(FOR FLOOR SHIFT) | ||||
| 33055-14020 |
MA70..4FC |
1 | ||
| 33504F - KNOB SUB-ASSY, SHIFT LEVER | ||||
| 33542-3205011 |
MA70..4FC BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33542-3205011 |
MA70..4FC BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33542-3205011 |
MA70..4FC..TWC BLACK,TRIM1#,3#,8# |
1 | ||
| 33542-3205011 |
MA70..4FC..USA BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33542-3205011 |
MA70..4FC BLACK,TRIM1#,3#,8# |
1 | ||
| 33511 - SHAFT, CONTROL (FOR FLOOR SHIFT) | ||||
| 33511-14010 |
MA70..4FC |
1 | ||
| 33522F - SEAT, SHIFT LEVER PLATE (FOR FLOOR SHIFT) | ||||
| 33522-14030 |
MA70..4FC |
1 | ||
| 33550D - BULB, POSITION INDICATOR LAMP | ||||
| 90981-11018 |
MA70..4FC 12V 1.2W W/O SOCKET |
1 | ||
| 33550E - CAP, POSITION INDICATOR LAMP | ||||
| 90339-04014 |
MA70..4FC |
1 | ||
| 33555 - BOOT, SHIFT LEVER | ||||
| 33555-14060 |
MA70..4FC |
1 | ||
| 33558A - SEAL, SHIFT LEVER BOOT DUST, NO.1 | ||||
| 33558-14010 |
MA70..4FC |
1 | ||
| 33563 - BUTTON, SHIFT LOCK RELEASE | ||||
| 33563-14020 |
MA70..4FC |
1 | ||
| 33622 - COVER, SHIFT LEVER KNOB, NO.1 | ||||
| 33622-1602011 |
MA70..4FC..TWC NEW BLACK,TRIM1#,3#,8# |
1 | ||
| 33622-1602011 |
MA70..4FC NEW BLACK,TRIM1#,3#,8# |
1 | ||
| 33622-1602011 |
MA70..4FC NEW BLACK,TRIM3#,8# |
1 | ||
| 33622-1602011 |
MA70..4FC..USA NEW BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33622-1602011 |
MA70..4FC NEW BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33623 - BUTTON, SHIFT LEVER KNOB | ||||
| 33623-1602011 |
MA70..4FC..TWC NEW BLACK,TRIM1#,3#,8# |
1 | ||
| 33623-1602011 |
MA70..4FC NEW BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33623-1602011 |
MA70..4FC NEW BLACK,TRIM1#,3#,8# |
1 | ||
| 33623-1602011 |
MA70..4FC..USA NEW BLACK,TRIM1#,3#,4#,8# |
1 | ||
| 33623-1602011 |
MA70..4FC NEW BLACK,TRIM1#,3#,8# |
1 | ||
| 33623A - SPRING, COMPRESSION (FOR SHIFT LEVER KNOB BUTTON) | ||||
| 90501-07009 |
MA70..4FC |
1 | ||
| 33625 - SLEEVE, SHIFT LEVER KNOB | ||||
| 33625-32010 |
MA70..4FC |
1 | ||
| 33631 - ROD, DETENT | ||||
| 33631-14070 |
MA70..4FC |
1 | ||
| 33631A - SPRING, COMPRESSION (FOR DETENT ROD) | ||||
| 90501-07074 |
MA70..4FC |
1 | ||
| 33631D - PIN, GROOVED (FOR DETENT ROD) | ||||
| 90256-04003 |
MA70..4FC |
1 | ||
| 33635 - GUIDE, WIRE (FOR SHIFT LEVER) | ||||
| 33635-14030 |
MA70..4FC |
1 | ||
| 33636 - GUIDE, WIRE, NO.2 (FOR SHIFT LEVER) | ||||
| 33636-35010 |
MA70..4FC |
1 | ||
| 33675 - ROD, TRANSMISSION CONTROL (FOR FLOOR SHIFT) | ||||
| 33675-14160 |
MA70..4FC |
1 | ||
| 33675B - BUSH (FOR TRANSMISSION CONTROL ROD) | ||||
| 90389-08005 |
MA70..4FC |
1 | ||
| 33675C - GROMMET (FOR TRANSMISSION CONTROL ROD) | ||||
| 90480-17177 |
MA70..4FC |
1 | ||
| 33723F - SWIVEL, CONNECTING ROD (FOR FLOOR SHIFT) | ||||
| 33723-22010 |
MA70..4FC |
1 | ||
| 33723G - BUSH (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90389-08005 |
MA70..4FC |
1 | ||
| 33723H - GROMMET (FOR FLOOR SHIFT CONTROL SHAFT) | ||||
| 90480-17001 |
MA70..4FC |
1 | ||
| 33805 - PLATE SUB-ASSY, SHIFT LOCK (FOR FLOOR SHIFT) | ||||
| 33805-14020 |
MA70..4FC |
1 | ||
| 33878 - LABEL, SHIFT LOCK INFORMATION, NO.2 | ||||
| 33878-14010 |
MA70..4FC |
1 | ||
| 35906 - WIRE SUB-ASSY, INDICATOR LAMP | ||||
| 35906-14020 |
MA70..4FC |
1 | ||
| 35921 - PLATE, CONTROL POSITION INDICATOR | ||||
| 35921-14210 |
MA70..4FC |
1 | ||
| 35971A - HOUSING, POSITION INDICATOR, UPPER | ||||
| 35971-14150 |
MA70..4FC |
1 | ||
| 35972 - COVER, POSITION INDICATOR HOUSING | ||||
| 35972-14080 |
MA70..4FC |
1 | ||
| 35974 - HOUSING, POSITION INDICATOR, LOWER | ||||
| 35974-14150 |
MA70..4FC |
1 | ||
| 35975 - COVER, SLIDE (FOR POSITION INDICATOR) | ||||
| 35975-14090 |
MA70..4FC |
1 | ||
| Common parts | ||||
| 90119-06144 | ||||
| 90159-40109 | ||||
| 90179-08041 | ||||
| 90463-12570 | ||||
| 90468-14004 | ||||
| 90501-06051 | ||||
| 93315-15012 | ||||
| 94120-40800 | ||||
| 94512-00800 | ||||
| 94613-10800 | ||||
| 95381-02020 | ||||
| Linked diagrams | ||||
| 8401 | ||||
| 8410 | ||||
