JZA80R-ALPVZW (1993)
Toyota Supra
(9305- )2JZGTE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11101 - HEAD SUB-ASSY, CYLINDER | ||||
| 11101-49365 |
2JZGTE..JZA80 |
1 | ||
| 11101A - BOLT(FOR CYLINDER HEAD SET) | ||||
| 90910-02102 |
2JZ#..JZA80 |
14 | ||
| 11101B - WASHER, PLATE(FOR CYLINDER HEAD SET) | ||||
| 90201-11018 |
2JZ#..JZA80 |
14 | ||
| 11101E - SENSOR, CAM POSITION | ||||
| 90919-05007 |
2JZGTE..JZA80 |
2 | ||
| 11101G - UNION(FOR CYLINDER HEAD) | ||||
| 90406-08011 |
2JZGTE..JZA80 NO.1 |
1 | ||
| 90406-17017 |
2JZGTE..JZA80 NO.2 |
1 | ||
| 11101G - UNION(FOR CYLINDER HEAD) | ||||
| 90406-08011 |
2JZGTE..JZA80 NO.1 |
1 | ||
| 90406-17017 |
2JZGTE..JZA80 NO.2 |
1 | ||
| 11115 - GASKET, CYLINDER HEAD | ||||
| 11115-46051 |
2JZGTE..JZA80 |
1 | ||
| 11117E - PLUG, W/HEAD STRAIGHT SCREW, NO.1 | ||||
| 90341-24010 |
2JZ#..JZA80 |
3 | ||
| 11117F - PLUG, W/HEAD STRAIGHT SCREW, NO.2 | ||||
| 90341-36001 |
2JZ#..JZA80 |
1 | ||
| 11117G - PLUG, W/HEAD STRAIGHT SCREW, NO.3 | ||||
| 90341-20002 |
2JZGTE..JZA80 |
6 | ||
| 11117H - GASKET(FOR WATER HOLE) | ||||
| 90430-20019 |
2JZGTE..JZA80 NO.3 |
6 | ||
| 90430-24010 |
2JZ#..JZA80 NO.1 |
3 | ||
| 90430-36003 |
2JZ#..JZA80 NO.2 |
1 | ||
| 11117H - GASKET(FOR WATER HOLE) | ||||
| 90430-20019 |
2JZGTE..JZA80 NO.3 |
6 | ||
| 90430-24010 |
2JZ#..JZA80 NO.1 |
3 | ||
| 90430-36003 |
2JZ#..JZA80 NO.2 |
1 | ||
| 11117H - GASKET(FOR WATER HOLE) | ||||
| 90430-20019 |
2JZGTE..JZA80 NO.3 |
6 | ||
| 90430-24010 |
2JZ#..JZA80 NO.1 |
3 | ||
| 90430-36003 |
2JZ#..JZA80 NO.2 |
1 | ||
| 11122 - BUSH, INTAKE VALVE GUIDE | ||||
| 11123-74030 |
2JZ#..JZA80 O/S 0.05 |
12 | ||
| 11122-74030 |
2JZ#..JZA80 STD |
12 | ||
| 11126 - BUSH, EXHAUST VALVE GUIDE | ||||
| 11122-16010 |
2JZ#..JZA80 STD |
12 | ||
| 11123-16010 |
2JZ#..JZA80 O/S 0.05 |
12 | ||
| 11131 - SEAT, INTAKE VALVE | ||||
| 11131-46020 |
2JZGTE..JZA80 STD |
12 | ||
| 11132-46020 |
2JZGTE..JZA80 O/S 0.03 |
12 | ||
| 11135 - SEAT, EXHAUST VALVE | ||||
| 11135-46050 |
2JZGTE..JZA80 STD |
12 | ||
| 11136-46050 |
2JZGTE..JZA80 O/S 0.03 |
12 | ||
| 11155A - PIN, RING W/HEAD | ||||
| 90253-11021 |
2JZ#..JZA80 |
28 | ||
| 11159A - BOLT(FOR HEAD TO CAMSHAFT BEARING CAP) | ||||
| 90119-08890 |
2JZ#..JZA80 |
28 | ||
| 11159B - WASHER, SEAL(FOR HEAD TO CAMSHAFT BEARING CAP) | ||||
| 90210-08033 |
2JZ#..JZA80 |
4 | ||
| 11201 - COVER SUB-ASSY, CYLINDER HEAD | ||||
| 11202-46020 |
2JZGTE..JZA80 EXHAUST SIDE |
1 | ||
| 11201-46040 |
2JZGTE..JZA80 INTAKE SIDE |
1 | ||
| 11201 - COVER SUB-ASSY, CYLINDER HEAD | ||||
| 11202-46020 |
2JZGTE..JZA80 EXHAUST SIDE |
1 | ||
| 11201-46040 |
2JZGTE..JZA80 INTAKE SIDE |
1 | ||
| 11201B - WASHER, SEAL(FOR CYLINDER HEAD COVER) | ||||
| 90210-07001 |
2JZGTE..JZA80 |
16 | ||
| 11213 - GASKET, CYLINDER HEAD COVER | ||||
| 11214-46010 |
2JZ#..JZA80 EXHAUST SIDE |
1 | ||
| 11213-46020 |
2JZ#..JZA80 INTAKE SIDE |
1 | ||
| 11213 - GASKET, CYLINDER HEAD COVER | ||||
| 11214-46010 |
2JZ#..JZA80 EXHAUST SIDE |
1 | ||
| 11213-46020 |
2JZ#..JZA80 INTAKE SIDE |
1 | ||
| 12108 - CAP SUB-ASSY, OIL FILLER | ||||
| 12180-46010 |
2JZ#..JZA80 |
1 | ||
| 12108A - GASKET(FOR OIL FILLER CAP) | ||||
| 12195-46011 |
2JZ#..JZA80 |
1 | ||
| Common parts | ||||
| 90105-06011 | ||||
| 90105-06166 | ||||
| 90116-08349 | ||||
| 90126-06001 | ||||
| 90179-06288 | ||||
| Linked diagrams | ||||
| 2501 | ||||
(9305- )2JZGTE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-06011 | ||||
| 90105-06166 | ||||
| 90116-08349 | ||||
| 90126-06001 | ||||
| 90179-06288 | ||||
| Linked diagrams | ||||
| 2501 | ||||
