KP62L-PHKRS (1978)
Toyota Starlet
(7810-8208)3KH
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 21112 - HORN, AIR | ||||
| 21112-12070 |
2K,3K#..KP60,62 |
1 | ||
| 21209 - FLOAT SUB-ASSY | ||||
| 21209-24010 |
2K,3K#..KP60,62 |
1 | ||
| 21234 - PIPE OR HOSE | ||||
| 21234-24230 |
2K,3K#..KP6# |
1 | ||
| 21234-13150 |
2K,3K#..KP60,62 |
1 | ||
| 21235 - PIPE OR HOSE, CONNECTING | ||||
| 21235-24580 |
3K#..KP62 |
1 | ||
| 21271 - SCREW, IDLE ADJUSTING | ||||
| 21271-24100 |
2K,3KH..KP60,62..GEN |
1 | ||
| 21272 - SCREW, 1ST IDLE ADJUSTING | ||||
| 21273-24230 |
2K,3K#..KP6# |
1 | ||
| 21273 - SCREW, THROTTLE ADJUSTING | ||||
| 21273-50010 |
2K,3K#..KP60,62 |
1 | ||
| 21301 - VALVE SUB-ASSY, NEEDLE | ||||
| 21301-24030 |
2K,3K#..KP6# |
1 | ||
| 21313 - BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT) | ||||
| 21313-11020 |
2K,3K#,4K#..KP6# |
1 | ||
| 21314 - BALL, STEEL, NO.2(FOR PUMP PLUNGER) | ||||
| 21314-60010 |
2K,3K#,4K#..KP6# |
1 | ||
| 21341 - VALVE, POWER | ||||
| 21341-24030 |
2K,3K#,4K#..KP6# |
1 | ||
| 21351 - PISTON, POWER | ||||
| 21351-33080 |
2K,3K#..KP60,62 |
1 | ||
| 21353 - PLUNGER, PUMP | ||||
| 21305-22011 |
2K,3K#,4K#..KP6# |
1 | ||
| 21414 - SHAFT, CHOKE | ||||
| 21054-24010 |
2K,3K#..KP60,62 |
1 | ||
| 21538 - RETAINER, BALL CHECK | ||||
| 21538-31010 |
2K,3K#,4K#..KP6# |
1 | ||
| 21561 - WEIGHT, PUMP DISCHARGE | ||||
| 21561-22010 |
2K,3K#,4K#..KP6# |
1 | ||
| 21572 - STOP, POWER PISTON | ||||
| 21572-33080 |
3KH..KP62 |
1 | ||
| 21611 - GASKET, MAIN JET | ||||
| 21611-22010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21611 - GASKET, MAIN JET | ||||
| 21611-22010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21614 - GASKET, VENTURI | ||||
| 21614-22010 |
2K,3K#..KP60,62 |
2 | ||
| 21614 - GASKET, VENTURI | ||||
| 21614-22010 |
2K,3K#..KP60,62 |
2 | ||
| 21617 - GASKET, MAIN PASSAGE PLUG | ||||
| 21617-30010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21618 - GASKET, NEEDLE VALVE SEAT | ||||
| 21618-24030 |
2K,3K#..KP6# |
1 | ||
| 21621 - GASKET, UNION NIPPLE | ||||
| 21633-24030 |
2K,3K#,4K#..KP6# |
1 | ||
| 21622 - GASKET, AIR HORN | ||||
| 21622-24440 |
2K,3K#..KP60,62 |
1 | ||
| 21623 - GASKET, BODY FLANGE | ||||
| 21623-24300 |
2K,3K#..KP60,62 |
1 | ||
| 21699 - BOOT(FOR PUMP PLUNGER) | ||||
| 21699-21061 |
2K,3K#..KP6# |
1 | ||
| 21722 - SPRING, PUMP DAMPING | ||||
| 21722-22010 |
2K,3K#,4K#..KP6# |
1 | ||
| 21723 - SPRING, IDLE ADJUSTING | ||||
| 21723-21030 |
2K,3K#,4K#..KP6# |
1 | ||
| 21724 - SPRING, THROTTLE ADJUSTING | ||||
| 21726-40010 |
2K,3K#..KP60,62 |
1 | ||
| 21726 - SPRING, 1ST IDLE ADJUSTING | ||||
| 21864-24230 |
2K,3K#..KP60,62 |
1 | ||
| 21763 - PIN, FLOAT LEVER | ||||
| 21763-29270 |
2K,3K#..KP60,62 |
1 | ||
| 21781 - PLUG, MAIN PASSAGE(FOR CARBURETOR JET) | ||||
| 21781-30020 |
2K,3K#,4K#..KP6# |
1 | ||
| 21791 - RING, SNAP, NO.1(FOR CARBURETOR LINK) | ||||
| 21791-60010 |
2K,3K#..KP60,62 |
1 | ||
| 21826 - SCREW, PUMP ARM SET | ||||
| 21826-31012 |
2K,3K#,4K#..KP6# |
1 | ||
| 21831 - SCREW, POWER PISTON STOP | ||||
| 21842-33010 |
3K#..KP62 |
1 | ||
| 21834 - SCREW, SET, NO.2(FOR CARBURETOR BODY SET) | ||||
| 21834-31010 |
2K,3K#,4K#..KP6# |
1 | ||
| 21835 - SCREW, SET, NO.3(FOR CARBURETOR BODY SET) | ||||
| 21835-40010 |
2K,3K#,4K#..KP6# |
1 | ||
| 21852 - NUT, THROTTLE LEVER SET | ||||
| 21852-30010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21852 - NUT, THROTTLE LEVER SET | ||||
| 21852-30010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21881 - WASHER, LOCK(FOR THROTTLE SHAFT) | ||||
| 21881-60010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21881 - WASHER, LOCK(FOR THROTTLE SHAFT) | ||||
| 21881-60010 |
2K,3K#,4K#..KP6# |
2 | ||
| 21934E - RING, O(FOR SOLENOID VALVE) | ||||
| 21655-44101 |
2K,3K#,4K#..KP6# |
1 | ||
| 21934F - GASKET | ||||
| 21617-10010 |
2K,3K#,4K#..KP6# |
1 | ||
| Common parts | ||||
| 21821-24030 | ||||
| 21821-31140 | ||||
| 21821-34380 | ||||
| 21873-21010 | ||||
| 21885-44010 | ||||
| 93289-15016 | ||||
| 94511-00400 | ||||
| 94511-00500 | ||||
| 94512-00600 | ||||
| 94611-10300 | ||||
| 95381-01610 | ||||
