Toyota Lexus is250c GSE20 OVERDRIVE & ELECTRONIC CONTROLLED TRANSMISSION

Part #	Description	Period	Qty
84570B - SWITCH ASSY, KICK DOWN
84570-30100	GSE20..LHD..6FC	04/2009 - 12/2999	1
84579A - BRACKET, KICK DOWN SWITCH
84579-30060	GSE20..LHD..6F	04/2009 - 08/2010	1
84722 - SWITCH, TRANSMISSION CONTROL
84722-20240	GSE20..LHD..6FC	04/2009 - 07/2015	1
89413B - SENSOR, TRANSMISSION REVOLUTION
89413-32010	GSE20 (J)	07/2013 - 07/2015	2
89413-32010	GSE20..6FC	04/2009 - 07/2013	2
89413-0C010	GSE20 (L)	07/2013 - 07/2015	2
89413B - SENSOR, TRANSMISSION REVOLUTION
89413-32010	GSE20 (J)	07/2013 - 07/2015	2
89413-32010	GSE20..6FC	04/2009 - 07/2013	2
89413-0C010	GSE20 (L)	07/2013 - 07/2015	2
89413D - RING, O(FOR TRANSMISSION REVOLUTION SENSOR)
90301-11008	GSE20..6FC	04/2009 - 12/2999	2
89413D - RING, O(FOR TRANSMISSION REVOLUTION SENSOR)
90301-11008	GSE20..6FC	04/2009 - 12/2999	2
Common parts
90119-06120
90179-06274
91611-B0614
Linked diagrams
7801

GSE20L-AKTLHW (2009)
