HDJ80L-GNPEXW (1990)
Toyota Land Cruiser
(9001-9501)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52051A - PAD SUB-ASSY, FRONT BUMPER | ||||
| 52051-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER) | ||||
| 90112-08073 |
FJ80,FZJ80,HDJ80,HZJ80 |
4 | ||
| 52111E - BAR, FRONT BUMPER | ||||
| 52111-60370 |
FJ80,FZJ80,HDJ80..VX |
1 | ||
| 52111-60380 |
FJ80,FZJ80,HDJ80..VX W(MECHANICAL WINCH) |
1 | ||
| 52112D - EXTENSION, FRONT BUMPER, RH | ||||
| 52102-60130 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52102-60070 |
FJ80,HDJ80..VX |
1 | ||
| 52102-60160 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52102-60080 |
FJ80,HDJ80..VX W(MECHANICAL WINCH) |
1 | ||
| 52102-60110 |
HDJ80..VX W(*OF) |
1 | ||
| 52113D - EXTENSION, FRONT BUMPER, LH | ||||
| 52103-60070 |
FJ80,HDJ80..VX |
1 | ||
| 52103-60130 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52103-60080 |
FJ80,HDJ80..VX W(MECHANICAL WINCH) |
1 | ||
| 52103-60160 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52103-60110 |
HDJ80..VX W(*OF) |
1 | ||
| 52133B - BRACKET, FRONT BUMPER EXTENSION MOUNTING, RH | ||||
| 52061-60010 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52133-60031 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52061-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52134B - BRACKET, FRONT BUMPER EXTENSION MOUNTING, LH | ||||
| 52062-60010 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52134-60031 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52062-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52141D - STAY, FRONT BUMPER, RH | ||||
| 52141-60060 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52142C - STAY, FRONT BUMPER, LH | ||||
| 52142-60050 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52143A - ARM, FRONT BUMPER, INNER RH | ||||
| 52143-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52144A - ARM, FRONT BUMPER, INNER LH | ||||
| 52144-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52149 - BRACKET, FRONT BUMPER, INNER | ||||
| 52149-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
2 | ||
| 52512 - FILLER, FRONT BUMPER, RH | ||||
| 52512-60030 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52512-60031 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52513 - FILLER, FRONT BUMPER, LH | ||||
| 52513-60021 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52513-60020 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52513-60022 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52521A - CLIP(FOR FRONT BUMPER RETAINER) | ||||
| 90467-04018 |
FJ80,FZJ80,HDJ80,HZJ80 |
4 | ||
| 52711 - MOULDING, FRONT BUMPER | ||||
| 52711-60010 |
FJ80,HDJ80,HZJ80..GX,VX |
1 | ||
| 52711-60020 |
HDJ80 W(*OF) |
1 | ||
| 52715 - RETAINER, FRONT BUMPER MOULDING, NO.1 | ||||
| 52715-60010 |
FZJ80,HDJ80,HZJ80..GX,VX |
6 | ||
| 52721 - MOULDING, FRONT BUMPER EXTENSION, RH | ||||
| 52721-60010 |
FJ80,HDJ80,HZJ80..GX,VX |
1 | ||
| 52721-60020 |
HDJ80 W(*OF) |
1 | ||
| 52722 - MOULDING, FRONT BUMPER EXTENSION, LH | ||||
| 52722-60020 |
HDJ80 W(*OF) |
1 | ||
| 52722-60010 |
FJ80,HDJ80,HZJ80..GX,VX |
1 | ||
| 53112C - GRILLE, RADIATOR, LOWER RH | ||||
| 53112-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 53113C - GRILLE, RADIATOR, LOWER LH | ||||
| 53113-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| Common parts | ||||
| 90119-06068 | ||||
| 90119-08126 | ||||
| 90119-10048 | ||||
| 90119-10612 | ||||
| 90159-60182 | ||||
| 90179-06009 | ||||
| 90179-08063 | ||||
| 90179-10068 | ||||
| 90189-06005 | ||||
| 90467-0705301 | ||||
| 90467-0705303 | ||||
| 93540-75020 | ||||
| 94180-40500 | ||||
| Linked diagrams | ||||
| 3615 | ||||
(9001-9501)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER) | ||||
| 90112-08073 |
FJ80,FZJ80,HDJ80,HZJ80 |
4 | ||
| 52111E - BAR, FRONT BUMPER | ||||
| 52111-60370 |
FJ80,FZJ80,HDJ80..VX |
1 | ||
| 52111-60380 |
FJ80,FZJ80,HDJ80..VX W(MECHANICAL WINCH) |
1 | ||
| 52112D - EXTENSION, FRONT BUMPER, RH | ||||
| 52102-60130 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52102-60070 |
FJ80,HDJ80..VX |
1 | ||
| 52102-60160 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52102-60080 |
FJ80,HDJ80..VX W(MECHANICAL WINCH) |
1 | ||
| 52102-60110 |
HDJ80..VX W(*OF) |
1 | ||
| 52113D - EXTENSION, FRONT BUMPER, LH | ||||
| 52103-60070 |
FJ80,HDJ80..VX |
1 | ||
| 52103-60130 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52103-60080 |
FJ80,HDJ80..VX W(MECHANICAL WINCH) |
1 | ||
| 52103-60160 |
HDJ80..VX W(*OF & WINCH) |
1 | ||
| 52103-60110 |
HDJ80..VX W(*OF) |
1 | ||
| 52133B - BRACKET, FRONT BUMPER EXTENSION MOUNTING, RH | ||||
| 52061-60010 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52133-60031 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52061-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52134B - BRACKET, FRONT BUMPER EXTENSION MOUNTING, LH | ||||
| 52062-60010 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52134-60031 |
FJ80,HDJ80,HZJ80 |
1 | ||
| 52062-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52141D - STAY, FRONT BUMPER, RH | ||||
| 52141-60060 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52142C - STAY, FRONT BUMPER, LH | ||||
| 52142-60050 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52143A - ARM, FRONT BUMPER, INNER RH | ||||
| 52143-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52144A - ARM, FRONT BUMPER, INNER LH | ||||
| 52144-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 52149 - BRACKET, FRONT BUMPER, INNER | ||||
| 52149-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
2 | ||
| 52521A - CLIP(FOR FRONT BUMPER RETAINER) | ||||
| 90467-04018 |
FJ80,FZJ80,HDJ80,HZJ80 |
4 | ||
| 52711 - MOULDING, FRONT BUMPER | ||||
| 52711-60010 |
FJ80,HDJ80,HZJ80..GX,VX |
1 | ||
| 52711-60020 |
HDJ80 W(*OF) |
1 | ||
| 52715 - RETAINER, FRONT BUMPER MOULDING, NO.1 | ||||
| 52715-60010 |
FZJ80,HDJ80,HZJ80..GX,VX |
6 | ||
| 52721 - MOULDING, FRONT BUMPER EXTENSION, RH | ||||
| 52721-60010 |
FJ80,HDJ80,HZJ80..GX,VX |
1 | ||
| 52721-60020 |
HDJ80 W(*OF) |
1 | ||
| 52722 - MOULDING, FRONT BUMPER EXTENSION, LH | ||||
| 52722-60020 |
HDJ80 W(*OF) |
1 | ||
| 52722-60010 |
FJ80,HDJ80,HZJ80..GX,VX |
1 | ||
| 53112C - GRILLE, RADIATOR, LOWER RH | ||||
| 53112-60020 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| 53113C - GRILLE, RADIATOR, LOWER LH | ||||
| 53113-60010 |
FJ80,FZJ80,HDJ80,HZJ80 |
1 | ||
| Common parts | ||||
| 90119-06068 | ||||
| 90119-08126 | ||||
| 90119-10048 | ||||
| 90119-10612 | ||||
| 90179-06009 | ||||
| 90179-08063 | ||||
| 90179-10068 | ||||
| 93540-75020 | ||||
| 94180-40500 | ||||
