FZJ80L-GCMRKW (1995)

Toyota Land Cruiser

Production Jan 1995 - Jan 1998
Engine 1FZFE
Transmission MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9501- )

Click highlighted areas on diagram

diagram 52111C 52111C 52111E 52112D 52113D 52141D 52142C 52143A 52144A 52149 52149 53112C 53113C 9010906187 9011908198 9011910048 9011910632 9011910715 9017906009 9017906009 9017908063 9017910134 9018906117 9018906155 9354085020
Part # Description Qty Price
52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER)
90112-08073

FJ80,FZJ80,HDJ80,HZJ80

 4
52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER)
90112-08073

FJ80,FZJ80,HDJ80,HZJ80

 4
52111E - BAR, FRONT BUMPER
52111-60510

FZJ80,HDJ80,HZJ80..GX,STD

 1
52111-60530

FZJ80,HDJ80..GX,STD

W(MECHANICAL WINCH)

 1
52111-60530

FZJ80,HDJ80,HZJ80..GX,STD

W(MECHANICAL WINCH)

 1
52112D - EXTENSION, FRONT BUMPER, RH
52102-60180

FZJ80,HDJ80,HZJ80..GX,STD

 1
52113D - EXTENSION, FRONT BUMPER, LH
52103-60180

FZJ80,HDJ80,HZJ80..GX,STD

 1
52141D - STAY, FRONT BUMPER, RH
52141-60060

FJ80,FZJ80,HDJ80,HZJ80

 1
52141-60080

FZJ80,HDJ80,HZJ80..LHD

W(MECHANICAL WINCH)

 1
52141-60080

FZJ80,HDJ80..LHD

W(MECHANICAL WINCH)

 1
52141-60070

FZJ80,HDJ80,HZJ80

 1
52142C - STAY, FRONT BUMPER, LH
52142-60060

FZJ80,HDJ80,HZJ80

 1
52142-60050

FJ80,FZJ80,HDJ80,HZJ80

 1
52142-60070

FZJ80,HDJ80..LHD

W(MECHANICAL WINCH)

 1
52142-60070

FZJ80,HDJ80,HZJ80..LHD

W(MECHANICAL WINCH)

 1
52143A - ARM, FRONT BUMPER, INNER RH
52143-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
52143-60040

FZJ80,HDJ80,HZJ80

 1
52144A - ARM, FRONT BUMPER, INNER LH
52144-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
52143-60040

FZJ80,HDJ80,HZJ80

 1
52149 - BRACKET, FRONT BUMPER, INNER
52149-60020

FJ80,FZJ80,HDJ80,HZJ80

 2
52149-60030

FZJ80,HDJ80,HZJ80

 2
52149 - BRACKET, FRONT BUMPER, INNER
52149-60020

FJ80,FZJ80,HDJ80,HZJ80

 2
52149-60030

FZJ80,HDJ80,HZJ80

 2
53112C - GRILLE, RADIATOR, LOWER RH
53112-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
53112-60030

FZJ80,HDJ80,HZJ80

 1
53113C - GRILLE, RADIATOR, LOWER LH
53113-60010

FJ80,FZJ80,HDJ80,HZJ80

 1
53113-60020

FZJ80,HDJ80,HZJ80

 1
Common parts
90109-06187
90119-08198
90119-10048
90119-10632
90119-10715
90179-06009
90179-08063
90179-10134
90189-06117
90189-06155
93540-85020

(9501- )

Click highlighted areas on diagram

diagram 52111C 52111C 52111E 52112D 52113D 52141D 52142C 52143A 52144A 52149 52149 53112C 53113C 9010906187 9011908198 9011910048 9011910632 9011910715 9017906009 9017906009 9017908063 9017910134 9018906117 9018906155 9354085020
Part # Description Qty Price
52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER)
90112-08073

FJ80,FZJ80,HDJ80,HZJ80

 4
52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER)
90112-08073

FJ80,FZJ80,HDJ80,HZJ80

 4
52111E - BAR, FRONT BUMPER
52111-60510

FZJ80,HDJ80,HZJ80..GX,STD

 1
52111-60530

FZJ80,HDJ80..GX,STD

W(MECHANICAL WINCH)

 1
52111-60530

FZJ80,HDJ80,HZJ80..GX,STD

W(MECHANICAL WINCH)

 1
52112D - EXTENSION, FRONT BUMPER, RH
52102-60180

FZJ80,HDJ80,HZJ80..GX,STD

 1
52113D - EXTENSION, FRONT BUMPER, LH
52103-60180

FZJ80,HDJ80,HZJ80..GX,STD

 1
52141D - STAY, FRONT BUMPER, RH
52141-60060

FJ80,FZJ80,HDJ80,HZJ80

 1
52141-60080

FZJ80,HDJ80,HZJ80..LHD

W(MECHANICAL WINCH)

 1
52141-60080

FZJ80,HDJ80..LHD

W(MECHANICAL WINCH)

 1
52141-60070

FZJ80,HDJ80,HZJ80

 1
52142C - STAY, FRONT BUMPER, LH
52142-60060

FZJ80,HDJ80,HZJ80

 1
52142-60050

FJ80,FZJ80,HDJ80,HZJ80

 1
52142-60070

FZJ80,HDJ80..LHD

W(MECHANICAL WINCH)

 1
52142-60070

FZJ80,HDJ80,HZJ80..LHD

W(MECHANICAL WINCH)

 1
52143A - ARM, FRONT BUMPER, INNER RH
52143-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
52143-60040

FZJ80,HDJ80,HZJ80

 1
52144A - ARM, FRONT BUMPER, INNER LH
52144-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
52143-60040

FZJ80,HDJ80,HZJ80

 1
52149 - BRACKET, FRONT BUMPER, INNER
52149-60020

FJ80,FZJ80,HDJ80,HZJ80

 2
52149-60030

FZJ80,HDJ80,HZJ80

 2
52149 - BRACKET, FRONT BUMPER, INNER
52149-60020

FJ80,FZJ80,HDJ80,HZJ80

 2
52149-60030

FZJ80,HDJ80,HZJ80

 2
53112C - GRILLE, RADIATOR, LOWER RH
53112-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
53112-60030

FZJ80,HDJ80,HZJ80

 1
53113C - GRILLE, RADIATOR, LOWER LH
53113-60010

FJ80,FZJ80,HDJ80,HZJ80

 1
53113-60020

FZJ80,HDJ80,HZJ80

 1
Common parts
90109-06187
90119-08198
90119-10048
90119-10632
90119-10715
90179-06009
90179-08063
90179-10134
90189-06117
90189-06155
93540-85020

(9501- )

Click highlighted areas on diagram

W(WINCH)

diagram 52051A 52111C 52111C 52111E 52112D 52113D 52141D 52142C 52143A 52143A 52149 52149 53112C 53113C 9010906187 9011908198 9011910048 9011910632 9017906009 9017906009 9017906009 9017908063 9017908063 9017910134 9018906155 9354085020
Part # Description Qty Price
52051A - PAD SUB-ASSY, FRONT BUMPER
52051-60010

FZJ80,HDJ80..LHD

 1
52051-60010

FZJ80,HDJ80,HZJ80..LHD

 1
52051-60010

FJ80,FZJ80,HDJ80,HZJ80

 1
52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER)
90112-08073

FJ80,FZJ80,HDJ80,HZJ80

 4
52111C - BOLT, ROUND HEAD SQUARE NECK(FOR FRONT BUMPER)
90112-08073

FJ80,FZJ80,HDJ80,HZJ80

 4
52111E - BAR, FRONT BUMPER
52111-60510

FZJ80,HDJ80,HZJ80..GX,STD

 1
52111-60530

FZJ80,HDJ80..GX,STD

W(MECHANICAL WINCH)

 1
52111-60530

FZJ80,HDJ80,HZJ80..GX,STD

W(MECHANICAL WINCH)

 1
52112D - EXTENSION, FRONT BUMPER, RH
52102-60180

FZJ80,HDJ80,HZJ80..GX,STD

 1
52113D - EXTENSION, FRONT BUMPER, LH
52103-60180

FZJ80,HDJ80,HZJ80..GX,STD

 1
52141D - STAY, FRONT BUMPER, RH
52141-60060

FJ80,FZJ80,HDJ80,HZJ80

 1
52141-60080

FZJ80,HDJ80,HZJ80..LHD

W(MECHANICAL WINCH)

 1
52141-60080

FZJ80,HDJ80..LHD

W(MECHANICAL WINCH)

 1
52141-60070

FZJ80,HDJ80,HZJ80

 1
52142C - STAY, FRONT BUMPER, LH
52142-60060

FZJ80,HDJ80,HZJ80

 1
52142-60050

FJ80,FZJ80,HDJ80,HZJ80

 1
52142-60070

FZJ80,HDJ80..LHD

W(MECHANICAL WINCH)

 1
52142-60070

FZJ80,HDJ80,HZJ80..LHD

W(MECHANICAL WINCH)

 1
52143A - ARM, FRONT BUMPER, INNER RH
52143-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
52143-60040

FZJ80,HDJ80,HZJ80

 1
52143A - ARM, FRONT BUMPER, INNER RH
52143-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
52143-60040

FZJ80,HDJ80,HZJ80

 1
52149 - BRACKET, FRONT BUMPER, INNER
52149-60020

FJ80,FZJ80,HDJ80,HZJ80

 2
52149-60030

FZJ80,HDJ80,HZJ80

 2
52149 - BRACKET, FRONT BUMPER, INNER
52149-60020

FJ80,FZJ80,HDJ80,HZJ80

 2
52149-60030

FZJ80,HDJ80,HZJ80

 2
53112C - GRILLE, RADIATOR, LOWER RH
53112-60020

FJ80,FZJ80,HDJ80,HZJ80

 1
53112-60030

FZJ80,HDJ80,HZJ80

 1
53113C - GRILLE, RADIATOR, LOWER LH
53113-60010

FJ80,FZJ80,HDJ80,HZJ80

 1
53113-60020

FZJ80,HDJ80,HZJ80

 1
Common parts
90109-06187
90119-08198
90119-10048
90119-10632
90179-06009
90179-08063
90179-10134
90189-06155
93540-85020
