FJ45RP-KQ3 (1980)
Toyota Land Cruiser
(8008- )FJ4#..RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88460 - CONDENSER ASSY, COOLER | ||||
| 88460-60050 |
FJ40,45..WORB..ARL |
1 | ||
| 88460A - COVER, COOLER CONDENSER | ||||
| 88896-60040 |
FJ4#,HJ47..ARL,GEN LH |
1 | ||
| 88896-60030 |
FJ4#,HJ47..ARL,GEN RH |
1 | ||
| 88896-60040 |
BJ40,42,45..(PIC,V)..(ARL,GEN) LH |
1 | ||
| 88896-60050 |
BJ40,42,45..(PIC,V)..(ARL,GEN) RH |
1 | ||
| 88460A - COVER, COOLER CONDENSER | ||||
| 88896-60040 |
FJ4#,HJ47..ARL,GEN LH |
1 | ||
| 88896-60030 |
FJ4#,HJ47..ARL,GEN RH |
1 | ||
| 88896-60040 |
BJ40,42,45..(PIC,V)..(ARL,GEN) LH |
1 | ||
| 88896-60050 |
BJ40,42,45..(PIC,V)..(ARL,GEN) RH |
1 | ||
| 88470 - RECEIVER & DRYER ASSY, COOLER | ||||
| 88470-20070 |
BJ40,42,45,FJ4#,HJ47..ARL,GEN |
1 | ||
| 88470B - BOLT, FUSE | ||||
| 90099-04579 |
BJ40,42,45,FJ4#,HJ47..ARL,GEN |
1 | ||
| 88472 - BRACKET, RECEIVER TANK, NO.1 | ||||
| 88472-60030 |
FJ4#..ARL,GEN |
1 | ||
| 88472-60040 |
BJ40,42,45,HJ47..(PIC,V)..(ARL,GEN) |
1 | ||
| 88479 - FREON GAS, AIR CONDITIONER (DRUM, COOLER REFRIGERANT) | ||||
| 90986-02001 |
BJ40,42,45,FJ4#,HJ47..ARL,GEN 400G |
2 | ||
| 88645H - SWITCH, PRESSURE NO.1 | ||||
| 88645-22020 |
FJ40,45,HJ47..RHD..(PIC,V) |
1 | ||
| 88645-22020 |
BJ40,42,45..(PIC,V)..(ARL,GEN) |
1 | ||
| 88711 - HOSE, COOLER REFRIGERANT DISCHARGE, NO.1 | ||||
| 88711-60070 |
BJ40,42,45..(PIC,V)..(ARL,GEN) |
1 | ||
| 88711-60060 |
FJ4#..(3F,4F)..(ARL,GEN) |
1 | ||
| 88712 - HOSE, COOLER REFRIGERANT SUCTION, NO.1 | ||||
| 88712-60060 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88712-60100 |
FJ40,45..RHD..(PIC,V) |
1 | ||
| 88712-60061 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88716A - PIPE, COOLER REFRIGERANT LIQUID, A | ||||
| 88716-60110 |
BJ40,42,45,HJ47..(PIC,V)..(ARL,GEN) |
1 | ||
| 88716-60150 |
FJ4#..ARL,GEN |
1 | ||
| 88716B - PIPE, COOLER REFRIGERANT LIQUID, B | ||||
| 88716-60121 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88716-60122 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88710-60050 |
FJ40,45..RHD..(PIC,V) |
1 | ||
| 88716E - PIPE, COOLER REFRIGERANT LIQUID, E | ||||
| 88716-60230 |
BJ40,42,45,FJ40,45,HJ47..RHD..(PIC,V) |
1 | ||
| 88717A - PIPE, COOLER REFRIGERANT SUCTION, A | ||||
| 88717-60060 |
BJ40,42,45,FJ40,45..RHD..(PIC,V) |
1 | ||
| 88717B - PIPE, COOLER REFRIGERANT SUCTION, B | ||||
| 88899-60030 |
BJ40,42,45,FJ40,45,HJ47..RHD..(PIC,V) |
1 | ||
| Common parts | ||||
| 88467-22010 | ||||
| 88569-22040 | ||||
| 88569-60010 | ||||
| 88578-60020 | ||||
| 88688-60130 | ||||
| 88688-60140 | ||||
| 88714-30290 | ||||
| 88714-90A00 | ||||
| 88714-90A01 | ||||
| 88714-95A00 | ||||
| 88718-12130 | ||||
| 88718-14280 | ||||
| 88718-60190 | ||||
| 88718-60200 | ||||
| 88718-60250 | ||||
| 88718-60260 | ||||
| 88718-60261 | ||||
| 90099-00871 | ||||
| 90099-32073 | ||||
| 90119-08175 | ||||
| 90159-80308 | ||||
| 90461-08157 | ||||
| 90480-26003 | ||||
| 90480-36003 | ||||
| 93385-16020 | ||||
| 93510-05120 | ||||
| 93540-15012 | ||||
| 94110-40600 | ||||
(8008- )FJ40,45..RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88460 - CONDENSER ASSY, COOLER | ||||
| 88460-60050 |
FJ40,45..WORB..ARL |
1 | ||
| 88460A - COVER, COOLER CONDENSER | ||||
| 88896-60040 |
FJ4#,HJ47..ARL,GEN LH |
1 | ||
| 88896-60030 |
FJ4#,HJ47..ARL,GEN RH |
1 | ||
| 88896-60040 |
BJ40,42,45..(PIC,V)..(ARL,GEN) LH |
1 | ||
| 88896-60050 |
BJ40,42,45..(PIC,V)..(ARL,GEN) RH |
1 | ||
| 88460A - COVER, COOLER CONDENSER | ||||
| 88896-60040 |
FJ4#,HJ47..ARL,GEN LH |
1 | ||
| 88896-60030 |
FJ4#,HJ47..ARL,GEN RH |
1 | ||
| 88896-60040 |
BJ40,42,45..(PIC,V)..(ARL,GEN) LH |
1 | ||
| 88896-60050 |
BJ40,42,45..(PIC,V)..(ARL,GEN) RH |
1 | ||
| 88470 - RECEIVER & DRYER ASSY, COOLER | ||||
| 88470-20070 |
BJ40,42,45,FJ4#,HJ47..ARL,GEN |
1 | ||
| 88470B - BOLT, FUSE | ||||
| 90099-04579 |
BJ40,42,45,FJ4#,HJ47..ARL,GEN |
1 | ||
| 88472 - BRACKET, RECEIVER TANK, NO.1 | ||||
| 88472-60030 |
FJ4#..ARL,GEN |
1 | ||
| 88472-60040 |
BJ40,42,45,HJ47..(PIC,V)..(ARL,GEN) |
1 | ||
| 88479 - FREON GAS, AIR CONDITIONER (DRUM, COOLER REFRIGERANT) | ||||
| 90986-02001 |
BJ40,42,45,FJ4#,HJ47..ARL,GEN 400G |
2 | ||
| 88645H - SWITCH, PRESSURE NO.1 | ||||
| 88645-22020 |
FJ40,45,HJ47..RHD..(PIC,V) |
1 | ||
| 88645-22020 |
BJ40,42,45..(PIC,V)..(ARL,GEN) |
1 | ||
| 88711 - HOSE, COOLER REFRIGERANT DISCHARGE, NO.1 | ||||
| 88711-60070 |
BJ40,42,45..(PIC,V)..(ARL,GEN) |
1 | ||
| 88711-60060 |
FJ4#..(3F,4F)..(ARL,GEN) |
1 | ||
| 88712 - HOSE, COOLER REFRIGERANT SUCTION, NO.1 | ||||
| 88712-60060 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88712-60100 |
FJ40,45..RHD..(PIC,V) |
1 | ||
| 88712-60061 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88716A - PIPE, COOLER REFRIGERANT LIQUID, A | ||||
| 88716-60150 |
FJ4#..ARL,GEN |
1 | ||
| 88716-60110 |
BJ40,42,45,HJ47..(PIC,V)..(ARL,GEN) |
1 | ||
| 88716B - PIPE, COOLER REFRIGERANT LIQUID, B | ||||
| 88716-60121 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88716-60122 |
BJ40,42,45..RHD..(PIC,V) |
1 | ||
| 88710-60050 |
FJ40,45..RHD..(PIC,V) |
1 | ||
| 88716E - PIPE, COOLER REFRIGERANT LIQUID, E | ||||
| 88716-60230 |
BJ40,42,45,FJ40,45,HJ47..RHD..(PIC,V) |
1 | ||
| 88717A - PIPE, COOLER REFRIGERANT SUCTION, A | ||||
| 88717-60060 |
BJ40,42,45,FJ40,45..RHD..(PIC,V) |
1 | ||
| 88717B - PIPE, COOLER REFRIGERANT SUCTION, B | ||||
| 88899-60030 |
BJ40,42,45,FJ40,45,HJ47..RHD..(PIC,V) |
1 | ||
| 88717C - PIPE, COOLER REFRIGERANT SUCTION, C | ||||
| 88717-60050 |
FJ40,45..RHD..(PIC,V) |
1 | ||
| Common parts | ||||
| 88467-22010 | ||||
| 88569-20060 | ||||
| 88578-60020 | ||||
| 88714-30290 | ||||
| 88718-14280 | ||||
| 88718-60170 | ||||
| 88718-60180 | ||||
| 88718-60250 | ||||
| 88718-60260 | ||||
| 88718-60261 | ||||
| 90099-00871 | ||||
| 90099-14056 | ||||
| 90099-32073 | ||||
| 90119-08175 | ||||
| 90159-80308 | ||||
| 90461-08585 | ||||
| 90461-08703 | ||||
| 90461-10507 | ||||
| 90480-26003 | ||||
| 90480-36003 | ||||
| 93385-16020 | ||||
| 93385-18014 | ||||
| 93385-18020 | ||||
| 93510-05120 | ||||
| 93540-15012 | ||||
| 94110-40600 | ||||
