FJ45RP-KQ (1975)
Toyota Land Cruiser
(7501-7904)FJ45,HJ45 ; (7904-8007)HJ45..ARL..IV; (7904-8007)FJ45,HJ45..EUR,GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47202 - RESERVOIR SUB-ASSY, BRAKE MASTER CYLINDER | ||||
| 47202-30010 |
FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47202-60010 |
BJ4#,FJ4#,55,HJ45 FOR TANDEM MASTER CYLINDER |
1 | ||
| 47202T - RING(FOR BRAKE MASTER CYLINDER RESERVOIR, NO.1) | ||||
| 90562-18151 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47205 - RESERVOIR SET, BRAKE MASTER CYLINDER(FOR REAR SIDE) | ||||
| 47202-60010 |
FJ45,HJ45 |
1 | ||
| 47202-60030 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47205T - RING(FOR BRAKE MASTER CYLINDER RESERVOIR, NO.2) | ||||
| 90562-18151 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47210 - CYLINDER ASSY, MASTER, W/O BOOSTER | ||||
| 47200-35011 |
FJ4# SINGLE MASTER CYLINDER |
1 | ||
| 47201-60090 |
FJ45..ARL;HJ45..PIC..ARL |
1 | ||
| 47201-60040 |
FJ45,HJ45 |
1 | ||
| 47210K - CYLINDER KIT, BRAKE MASTER | ||||
| 04471-35014 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 04493-60030 |
FJ45,HJ45 |
1 | ||
| 47210P - PLUG, BLEEDER(FOR BRAKE MASTER CYLINDER) | ||||
| 47547-40010 |
FJ45,HJ45 |
2 | ||
| 47547-40010 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 47210Q - CAP, BLEEDER PLUG(FOR BRAKE MASTER CYLINDER) | ||||
| 47548-60010 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47548-60010 |
FJ45,HJ45 |
1 | ||
| 47210T - BOLT(FOR BRAKE MASTER CYLINDER) | ||||
| 90109-06011 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 90109-06008 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47214 - PLUG, MASTER CYLINDER | ||||
| 47214-25011 |
FJ4# |
1 | ||
| 47214A - GASKET(FOR MASTER CYLINDER CAP) | ||||
| 90430-32052 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47230 - CAP ASSY, BRAKE MASTER CYLINDER RESERVOIR FILLER | ||||
| 47230-12011 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47230-20030 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47230R - CAP ASSY, RESERVOIR, NO.2(FOR REAR SIDE) | ||||
| 84460-20051 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47230-20030 |
FJ45,HJ45 |
1 | ||
| 47231 - BOLT, BRAKE MASTER CYLINDER RESERVOIR SET | ||||
| 47231-30010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47231-35010 |
FJ4#,55,HJ45 |
2 | ||
| 47231 - BOLT, BRAKE MASTER CYLINDER RESERVOIR SET | ||||
| 47231-30010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47231-35010 |
FJ4#,55,HJ45 |
2 | ||
| 47264 - CLEVIS, MASTER CYLINDER PUSH ROD | ||||
| 47264-35010 |
BJ4#,FJ4#,55,HJ45 FOR FRONT DRUM BRAKE |
1 | ||
| 47275 - GASKET, BRAKE MASTER CYLINDER | ||||
| 47275-22010 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47280 - VALVE ASSY, BRAKE MASTER CYLINDER OUTLET CHECK | ||||
| 47281-55010 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47280-35010 |
BJ4#,FJ4#,55,HJ45 FOR TANDEM FRONT DRUM BRAKE |
1 | ||
| 47290 - VALVE ASSY, MASTER CYLINDER OUTLET(FOR REAR SIDE) | ||||
| 47280-35010 |
BJ4#,FJ4#,55,HJ45 FOR FRONT DRUM BRAKE |
1 | ||
| 47299R - STRAINER, MASTER CYLINDER RESERVOIR, REAR | ||||
| 47299-20010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| Common parts | ||||
| 90179-08146 | ||||
| 94120-41000 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(7501-7608)ARL,GEN ; (7501-7608)EUR..IV ; (7608-7709)BJ40,FJ40..GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47202 - RESERVOIR SUB-ASSY, BRAKE MASTER CYLINDER | ||||
| 47202-30010 |
FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47202-60010 |
BJ4#,FJ4#,55,HJ45 FOR TANDEM MASTER CYLINDER |
1 | ||
| 47210 - CYLINDER ASSY, MASTER, W/O BOOSTER | ||||
| 47200-35011 |
FJ4# SINGLE MASTER CYLINDER |
1 | ||
| 47201-60090 |
FJ45..ARL;HJ45..PIC..ARL |
1 | ||
| 47201-60040 |
FJ45,HJ45 |
1 | ||
| 47210A - BOLT OR STUD BOLT(FOR BRAKE MASTER CYLINDER SETTING) | ||||
| 91111-40825 |
BJ4#,FJ4#,55,HJ45 |
3 | ||
| 47210K - CYLINDER KIT, BRAKE MASTER | ||||
| 04471-35014 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 04493-60030 |
FJ45,HJ45 |
1 | ||
| 47230 - CAP ASSY, BRAKE MASTER CYLINDER RESERVOIR FILLER | ||||
| 47230-12011 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47230-20030 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47231 - BOLT, BRAKE MASTER CYLINDER RESERVOIR SET | ||||
| 47231-30010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47231-35010 |
FJ4#,55,HJ45 |
2 | ||
| 47232 - WASHER, BRAKE RESERVOIR SET BOLT | ||||
| 47232-30010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47232-35010 |
FJ4#,55,HJ45 |
2 | ||
| 47261 - ROD, MASTER CYLINDER PUSH | ||||
| 47261-35020 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47264 - CLEVIS, MASTER CYLINDER PUSH ROD | ||||
| 47264-35010 |
BJ4#,FJ4#,55,HJ45 FOR FRONT DRUM BRAKE |
1 | ||
| 47265 - BOOT, MASTER CYLINDER | ||||
| 47265-35011 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47280 - VALVE ASSY, BRAKE MASTER CYLINDER OUTLET CHECK | ||||
| 47281-55010 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47280-35010 |
BJ4#,FJ4#,55,HJ45 FOR TANDEM FRONT DRUM BRAKE |
1 | ||
| Common parts | ||||
| 94120-41000 | ||||
| 94512-00800 | ||||
(7904-8007)HJ45..ARL..CBU ; (7904-8007)BJ40,FJ40,45,55..ARL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47202P - UNION, RESERVOIR(FOR BRAKE MASTER CYLINDER SIDE) | ||||
| 90405-10125 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47202Q - BOLT, RESERVOIR UNION(FOR BRAKE MASTER CYLINDER SIDE) | ||||
| 90401-16078 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47202R - GASKET, RESERVOIR UNION(FOR BRAKE MASTER CYLINDER SIDE) | ||||
| 90430-16242 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
2 | ||
| 47202R - GASKET, RESERVOIR UNION(FOR BRAKE MASTER CYLINDER SIDE) | ||||
| 90430-16242 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
2 | ||
| 47205 - RESERVOIR SET, BRAKE MASTER CYLINDER(FOR REAR SIDE) | ||||
| 47202-60010 |
FJ45,HJ45 |
1 | ||
| 47202-60030 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47210 - CYLINDER ASSY, MASTER, W/O BOOSTER | ||||
| 47200-35011 |
FJ4# SINGLE MASTER CYLINDER |
1 | ||
| 47201-60090 |
FJ45..ARL;HJ45..PIC..ARL |
1 | ||
| 47201-60040 |
FJ45,HJ45 |
1 | ||
| 47210K - CYLINDER KIT, BRAKE MASTER | ||||
| 04471-35014 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 04493-60030 |
FJ45,HJ45 |
1 | ||
| 47210T - BOLT(FOR BRAKE MASTER CYLINDER) | ||||
| 90109-06011 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 90109-06008 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47230R - CAP ASSY, RESERVOIR, NO.2(FOR REAR SIDE) | ||||
| 84460-20051 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47230-20030 |
FJ45,HJ45 |
1 | ||
| 47231 - BOLT, BRAKE MASTER CYLINDER RESERVOIR SET | ||||
| 47231-30010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47231-35010 |
FJ4#,55,HJ45 |
2 | ||
| 47232 - WASHER, BRAKE RESERVOIR SET BOLT | ||||
| 47232-30010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47232-35010 |
FJ4#,55,HJ45 |
2 | ||
| 47236 - TUBE, RESERVOIR BRAKE | ||||
| 47234-60010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| 47236A - CLIP(FOR RESERVOIR TUBE) | ||||
| 90467-16001 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
2 | ||
| 47264 - CLEVIS, MASTER CYLINDER PUSH ROD | ||||
| 47264-35010 |
BJ4#,FJ4#,55,HJ45 FOR FRONT DRUM BRAKE |
1 | ||
| 47265 - BOOT, MASTER CYLINDER | ||||
| 47265-35011 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47275 - GASKET, BRAKE MASTER CYLINDER | ||||
| 47275-22010 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 47280 - VALVE ASSY, BRAKE MASTER CYLINDER OUTLET CHECK | ||||
| 47281-55010 |
BJ4#,FJ4#,55,HJ45 FOR SINGLE MASTER CYLINDER |
1 | ||
| 47280-35010 |
BJ4#,FJ4#,55,HJ45 FOR TANDEM FRONT DRUM BRAKE |
1 | ||
| 47290 - VALVE ASSY, MASTER CYLINDER OUTLET(FOR REAR SIDE) | ||||
| 47280-35010 |
BJ4#,FJ4#,55,HJ45 FOR FRONT DRUM BRAKE |
1 | ||
| 47299R - STRAINER, MASTER CYLINDER RESERVOIR, REAR | ||||
| 47299-20010 |
HJ45..PIC..ARL;BJ40,FJ40,45,55..ARL |
1 | ||
| Common parts | ||||
| 90179-08146 | ||||
| 94120-41000 | ||||
