FJ43R-KC (1980)
Toyota Land Cruiser
(8008-8102)BJ45,FJ45..EUR ; (8102-8410)EUR ; (8210-8410)FJ45,HJ47..ARL ; (8301-8506
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90201-23360 | ||||
| 91131-50840 | ||||
| 91611-60814 | ||||
| 91656-40820 | ||||
| 94110-40800 | ||||
| 94110-41000 | ||||
| 94141-40800 | ||||
| 94512-00800 | ||||
| 94512-01000 | ||||
| 95381-02020 | ||||
(8008-8210)FJ4#,HJ47..RHD ; (8210-8410)FJ40..ARL; (8210-8506)FJ4#,HJ47..RHD..GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47159 - BRACKET, PROPORTIONING VALVE | ||||
| 47159-30110 |
FJ40;BJ40,42,43,46,FJ43..EUR,GEN |
1 | ||
| 47190 - VALVE ASSY, PROPORTIONING & BY-PASS | ||||
| 47190-14020 |
FJ40;BJ40,42,43,46,FJ43..EUR,GEN |
1 | ||
| 47311 - TUBE, FRONT BRAKE, NO.1 | ||||
| 47311-30320 |
FJ40;BJ40,42,43,46,FJ43..EUR,GEN FR DISC BRAKE |
1 | ||
| 47311B - WAY, NO.1(FOR FRONT BRAKE TUBE) | ||||
| 90414-10009 |
BJ4#..RHD;FJ4#,HJ47..3F,4F |
1 | ||
| 90414-10009 |
BJ4#..RHD;FJ40,43,HJ47 |
1 | ||
| 47311G - HOSE, FLEXIBLE(FOR BRAKE TUBE) | ||||
| 96940-32605 |
FJ4#,HJ47 |
1 | ||
| 47312 - TUBE, FRONT BRAKE, NO.2 | ||||
| 47312-60430 |
FJ4#,HJ47..RHD FR DRUM BRAKE |
1 | ||
| 47312-60360 |
FJ40,43..RHD;FJ40..TPC..5F FR DISC BRAKE |
1 | ||
| 47312-60390 |
BJ40,42,43,46..RHD..GEN FR DISC BRAKE |
1 | ||
| 47312-60370 |
BJ40,42,43,45..RHD..GEN FR DRUM BRAKE |
1 | ||
| 47312 - TUBE, FRONT BRAKE, NO.2 | ||||
| 47312-60430 |
FJ4#,HJ47..RHD FR DRUM BRAKE |
1 | ||
| 47312-60360 |
FJ40,43..RHD;FJ40..TPC..5F FR DISC BRAKE |
1 | ||
| 47312-60390 |
BJ40,42,43,46..RHD..GEN FR DISC BRAKE |
1 | ||
| 47312-60370 |
BJ40,42,43,45..RHD..GEN FR DRUM BRAKE |
1 | ||
| 47312E - WAY, NO.2(FOR FRONT BRAKE TUBE) | ||||
| 90413-10042 |
FJ4#,HJ47 |
1 | ||
| 47313 - TUBE, FRONT BRAKE, NO.3 | ||||
| 47329-60070 |
FJ4#,HJ47 |
1 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 96910-32305 |
BJ4#,FJ4#,HJ47 |
2 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 96910-32305 |
BJ4#,FJ4#,HJ47 |
2 | ||
| 47314 - TUBE, FRONT BRAKE, NO.4 | ||||
| 47315-60280 |
FJ4#,HJ47 |
1 | ||
| 47315 - TUBE, FRONT BRAKE, NO.5 | ||||
| 47316-60160 |
FJ4#,HJ47 |
1 | ||
| 47316A - HOSE, FLEXIBLE(FOR REAR BRAKE TUBE) | ||||
| 96940-34305 |
BJ4#,FJ4#,HJ47 |
1 | ||
| 47321 - TUBE, REAR BRAKE, NO.1 | ||||
| 47321-60100 |
FJ40;BJ40,42,43,46,FJ43..EUR,GEN |
1 | ||
| 47322 - TUBE, REAR BRAKE, NO.2 | ||||
| 47322-60330 |
FJ4#,HJ47..RHD FR DRUM BRAKE |
1 | ||
| 47322-60270 |
BJ40,42,43,45..RHD..GEN FR DRUM BRAKE |
1 | ||
| 47322-60260 |
FJ40,43..RHD;FJ40..TPC..5F FR DISC BRAKE |
1 | ||
| 47322-60290 |
BJ40,42,43,46..RHD..GEN FR DISC BRAKE |
1 | ||
| 47322 - TUBE, REAR BRAKE, NO.2 | ||||
| 47322-60330 |
FJ4#,HJ47..RHD FR DRUM BRAKE |
1 | ||
| 47322-60270 |
BJ40,42,43,45..RHD..GEN FR DRUM BRAKE |
1 | ||
| 47322-60260 |
FJ40,43..RHD;FJ40..TPC..5F FR DISC BRAKE |
1 | ||
| 47322-60290 |
BJ40,42,43,46..RHD..GEN FR DISC BRAKE |
1 | ||
| 47323 - TUBE, REAR BRAKE, NO.3 | ||||
| 47323-60060 |
FJ43 |
1 | ||
| 47323A - WAY, NO.3(FOR REAR BRAKE TUBE) | ||||
| 90413-10031 |
BJ40,42,43,46 |
1 | ||
| 90413-10086 |
BJ45,FJ4#,HJ47 |
1 | ||
| 47326 - TUBE, REAR BRAKE, NO.6 | ||||
| 47325-60020 |
BJ45,FJ4#,HJ47 |
1 | ||
| 47325-60040 |
BJ40,42,43,46 |
1 | ||
| 47327 - TUBE, REAR BRAKE, NO.7 | ||||
| 47326-60040 |
BJ40,42,43,46 |
1 | ||
| 47326-60020 |
BJ45,FJ4#,HJ47 |
1 | ||
| 47341B - TUBE, WHEEL CYLINDER, FRONT RH NO.1 | ||||
| 47341-60020 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..(3F,4F)..(ARL,GEN) FR DRUM BRAKE |
1 | ||
| 47341-60030 |
BJ40,42,43,46,FJ40,43 FR DISC BRAKE |
1 | ||
| 47341-60030 |
BJ40,42,43,46,FJ40,43;BJ45,FJ45,HJ47..ARL,EUR FR DISC BRAKE |
1 | ||
| 47341-60021 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN FR DRUM BRAKE |
1 | ||
| 47341B - TUBE, WHEEL CYLINDER, FRONT RH NO.1 | ||||
| 47341-60020 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..(3F,4F)..(ARL,GEN) FR DRUM BRAKE |
1 | ||
| 47341-60030 |
BJ40,42,43,46,FJ40,43 FR DISC BRAKE |
1 | ||
| 47341-60030 |
BJ40,42,43,46,FJ40,43;BJ45,FJ45,HJ47..ARL,EUR FR DISC BRAKE |
1 | ||
| 47341-60021 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN FR DRUM BRAKE |
1 | ||
| 47341C - WAY(FOR WHEEL CYLINDER FRONT RH TUBE) | ||||
| 90412-10071 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN |
1 | ||
| 47342 - TUBE, WHEEL CYLINDER, FRONT RH NO.2 | ||||
| 47342-60011 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN |
1 | ||
| 47342-60010 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..(3F,4F)..(ARL,GEN) |
1 | ||
| 47343A - TUBE, WHEEL CYLINDER, FRONT LH NO.1 | ||||
| 47343-60010 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..(3F,4F)..(ARL,GEN) FR DRUM BRAKE |
1 | ||
| 47343-60020 |
BJ40,42,43,46,FJ40,43 FR DISC BRAKE |
1 | ||
| 47343-60020 |
BJ40,42,43,46,FJ40,43;BJ45,FJ45,HJ47..ARL,EUR FR DISC BRAKE |
1 | ||
| 47343-60011 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN FR DRUM BRAKE |
1 | ||
| 47343A - TUBE, WHEEL CYLINDER, FRONT LH NO.1 | ||||
| 47343-60010 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..(3F,4F)..(ARL,GEN) FR DRUM BRAKE |
1 | ||
| 47343-60020 |
BJ40,42,43,46,FJ40,43 FR DISC BRAKE |
1 | ||
| 47343-60020 |
BJ40,42,43,46,FJ40,43;BJ45,FJ45,HJ47..ARL,EUR FR DISC BRAKE |
1 | ||
| 47343-60011 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN FR DRUM BRAKE |
1 | ||
| 47343B - WAY(FOR WHEEL CYLINDER FRONT LH TUBE) | ||||
| 90412-10072 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN |
1 | ||
| 47344 - TUBE, WHEEL CYLINDER, FRONT LH NO.2 | ||||
| 47342-60010 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..(3F,4F)..(ARL,GEN) |
1 | ||
| 47342-60011 |
BJ45,FJ45;BJ40,42,43,46,FJ40,43,HJ47..ARL,GEN |
1 | ||
| 47353 - BRACKET, FLEXIBLE HOSE(FOR REAR) | ||||
| 47351-60091 |
BJ40,42,43,46 |
1 | ||
| 47351-60080 |
FJ40,43 |
1 | ||
| 47353 - BRACKET, FLEXIBLE HOSE(FOR REAR) | ||||
| 47351-60091 |
BJ40,42,43,46 |
1 | ||
| 47351-60080 |
FJ40,43 |
1 | ||
| 47354 - BRACKET, FRONT FLEXIBLE HOSE | ||||
| 47354-60020 |
FJ4#,HJ47 |
1 | ||
| 47378 - PROTECTOR, BRAKE TUBE | ||||
| 47378-60010 |
FJ4#,HJ47 W/O COLLER |
1 | ||
| Common parts | ||||
| 90461-08191 | ||||
| 90461-08531 | ||||
| 90461-10574 | ||||
| 91111-41035 | ||||
| 91611-40616 | ||||
| 91611-40640 | ||||
| 91611-40816 | ||||
| 91611-60614 | ||||
| 91616-40825 | ||||
| 91651-40820 | ||||
| 91656-40816 | ||||
| 91656-40820 | ||||
| 94110-40800 | ||||
| 94110-41000 | ||||
| 94512-01000 | ||||
| 96221-30905 | ||||
| 96991-10080 | ||||
