FJ40L-UCJ (1975)
Toyota Land Cruiser
(8008-8210)3F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 91611-40816 | ||||
| Linked diagrams | ||||
| 3305 | ||||
(6903-8007)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33481P - GEAR, SPEEDOMETER DRIVE (FOR TRANSFER) | ||||
| 33481-60020 |
FJ40,43 N=6,TAKING 6X18 |
1 | ||
| 33481-60030 |
BJ4#,FJ4#,55,HJ45 N=6,TAKING 6X16,6X17 |
1 | ||
| 36111D - BEARING, TRANSFER REAR AND IDLER SHAFT | ||||
| 90363-30002 |
FJ4#,55..3F |
1 | ||
| 97103-06306 |
FJ4#,55..3F |
1 | ||
| 97103-06306 |
FJ4#,55,HJ45 |
1 | ||
| 36203 - GEAR SUB-ASSY, TRANSFER HIGH SPEED OUTPUT | ||||
| 36203-60010 |
BJ4#,FJ4#,55,HJ45 N=29 |
1 | ||
| 36203-60011 |
BJ4#,FJ4#,55,HJ45 N=31 |
1 | ||
| 36203A - BUSH, SOLID (FOR TRANSFER HIGH SPEED OUTPUT GEAR) | ||||
| 90380-40026 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 90999-73079 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36204 - GEAR SUB-ASSY, TRANSFER LOW SPEED OUTPUT | ||||
| 36204-60010 |
FJ4#,55 N=43,FOR 3-SPEED TRANSMISSION |
1 | ||
| 36204-60011 |
FJ4#,55..3F N=43 |
1 | ||
| 36204-60010 |
FJ4#,55..3F N=43 |
1 | ||
| 36204A - BUSH, SOLID (FOR TRANSFER LOW SPEED OUTPUT GEAR) | ||||
| 90380-40026 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 90999-73079 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36212 - GEAR, TRANSFER INPUT | ||||
| 36212-60020 |
FJ4#,55..3F N=29 |
1 | ||
| 36212-60020 |
FJ4#,55,HJ45 N=29 |
1 | ||
| 36212-60021 |
FJ4#,55..3F N=31 |
1 | ||
| 36215 - GEAR, POWER TAKE-OFF DRIVE | ||||
| 36215-60011 |
FJ4#,55..3F N=31 |
1 | ||
| 36215-60011 |
FJ4#,55,HJ45 N=31 |
1 | ||
| 36221 - GEAR, TRANSFER IDLER | ||||
| 36221-60020 |
FJ4#,55 N=39,25 |
1 | ||
| 36221-60021 |
FJ4#,55..3F N=41,25 |
1 | ||
| 36221-60020 |
FJ4#,55..3F N=39,25 |
1 | ||
| 36221A - SPACER(FOR TRANSFER IDLER GEAR) | ||||
| 90560-26085 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 90560-26001 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36221B - BEARING (FOR TRANSFER IDLER GEAR) | ||||
| 90364-25005 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36221B - BEARING (FOR TRANSFER IDLER GEAR) | ||||
| 90364-25005 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36225 - SHAFT, TRANSFER IDLER GEAR | ||||
| 36225-60020 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36225A - RING, O (FOR TRANSFER IDLER SHAFT) | ||||
| 90301-18026 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36225B - WASHER (FOR TRANSFER IDLER SHAFT) | ||||
| 90209-25001 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 90209-25006 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36225B - WASHER (FOR TRANSFER IDLER SHAFT) | ||||
| 90209-25001 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 90209-25006 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36231 - SHAFT, TRANSFER OUTPUT, REAR | ||||
| 36231-60010 |
FJ4#,55,HJ45 |
1 | ||
| 36231-60012 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36231A - SPACER (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90560-35082 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36231B - SHIM (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90564-64024 |
BJ4#,FJ4#,55,HJ45 T=0.20 |
1 | ||
| 90564-64017 |
BJ4#,FJ4#,55,HJ45 T=0.10 |
1 | ||
| 90564-64023 |
BJ4#,FJ4#,55,HJ45 T=0.15 |
1 | ||
| 90564-64025 |
BJ4#,FJ4#,55,HJ45 T=0.25 |
1 | ||
| 36231C - BEARING, TAPER ROLLER (FOR TRANSFER OUTPUT SHAFT) | ||||
| 97600-30307 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36231C - BEARING, TAPER ROLLER (FOR TRANSFER OUTPUT SHAFT) | ||||
| 97600-30307 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36231D - WASHER, PLATE (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90201-35070 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36231D - WASHER, PLATE (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90201-35070 |
BJ4#,FJ4#,55,HJ45 |
2 | ||
| 36231E - BEARING, NEEDLE ROLLER (FOR TRANSFER OUTPUT SHAFT FRONT | ||||
| 90364-17010 |
BJ4#,FJ40,43,45,55,HJ45 |
1 | ||
| 36234 - SHAFT, TRANSFER OUTPUT, FRONT | ||||
| 36234-60020 |
FJ40,43,45,55,HJ45 |
1 | ||
| 36234-60023 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36234-60022 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36234A - BEARING (FOR TRANSFER OUTPUT FRONT SHAFT) | ||||
| 97103-06306 |
BJ4#,FJ40,43,45,55,HJ45 |
1 | ||
| 36234B - RING, SNAP (FOR TRANSFER OUTPUT FRONT SHAFT BEARING) | ||||
| 90521-75023 |
BJ4#,FJ40,43,45,55,HJ45 T=1.6 |
1 | ||
| 36235 - SLEEVE, TRANSFER HIGH & LOW CLUTCH | ||||
| 36235-60011 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36235-60010 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36236 - SLEEVE, FRONT DRIVE CLUTCH | ||||
| 36236-60010 |
BJ4#,FJ40,43,45,55,HJ45 |
1 | ||
| 36236-60011 |
BJ4#,FJ4#,55,HJ45 |
1 | ||
| 36251 - SPACER, TRANSFER INPUT SHAFT | ||||
| 36251-60010 |
FJ4#,55..3F |
1 | ||
| 36251-60010 |
FJ4#,55,HJ45 |
1 | ||
| 36261 - SPACER, TRANSFER IDLER GEAR | ||||
| 36262-60010 |
BJ4#,FJ4#,55,HJ45 T=1.30-1.40 |
1 | ||
| 36263-60010 |
BJ4#,FJ4#,55,HJ45 T=1.40-1.50 |
1 | ||
| 36261-60010 |
BJ4#,FJ4#,55,HJ45 T=1.20-1.30 |
1 | ||
| Common parts | ||||
| 90119-08062 | ||||
| Linked diagrams | ||||
| 3305 | ||||
