NUJ10L-BGFNWW (2008)
Toyota Iq
(0811-1010)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85301 - INLET SUB-ASSY, WASHER | ||||
| 85319-74020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85330-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85319A - HOSE, INLET | ||||
| 85319-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85330 - JAR ASSY, WINDSHIELD WASHER | ||||
| 85315-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85330A - BUSH, WINDSHIELD WASHER JAR | ||||
| 85336-60300 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85316-52190 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85333 - FILTER, WINDSHIELD WASHER JAR | ||||
| 85312-21020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85336D - PACKING, WINDSHIELD WASHER JAR | ||||
| 85336-30160 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348D - JOINT, WINDSHIELD WASHER ELBOW, NO.1 | ||||
| 85355-20200 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348E - JOINT, WINDSHIELD WASHER ELBOW, NO.2 | ||||
| 85355-20200 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348F - JOINT, WINDSHIELD WASHER ELBOW, NO.3 | ||||
| 85355-20200 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348G - JOINT, WINDSHIELD WASHER HOSE, NO.2 | ||||
| 85349-89122 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85349C - JOINT, WINDSHIELD WASHER ELBOW, NO.4 | ||||
| 85375-33040 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85355 - VALVE, WINDSHIELD WASHER HOSE | ||||
| 85321-28020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=540 |
1 | ||
| 90099-62056 |
KGJ10,NGJ10,NUJ10 L=540 |
1 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33080 |
NGJ10..N;KGJ10,NUJ10 *H,L=990 |
1 | ||
| 85372B - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.2 | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=95 |
1 | ||
| 85372H - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.3 | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=390 |
1 | ||
| 85372J - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.4 | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=60 |
1 | ||
| 90099-62059 |
KGJ10,NGJ10,NUJ10 L=60 |
1 | ||
| 85372K - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.5 | ||||
| 90099-62060 |
KGJ10,NGJ10,NUJ10 L=520 |
1 | ||
| 90099-33299 |
KGJ10,NGJ10,NUJ10 *H,L=520 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 85336-12230 |
KGJ10,NGJ10,NUJ10 L=15 |
1 | ||
| 85387 - CLAMP NO.1 (FOR WINDSEIELD WASHER) | ||||
| 85387-74020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85387A - CLAMP, WASHER, NO.2 | ||||
| 53614-12040 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85387B - CLAMP, WASHER, NO.3 | ||||
| 53614-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85389D - SPRING(WASHER HOSE) | ||||
| 85389-72030 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| Common parts | ||||
| 90119-06767 | ||||
| Linked diagrams | ||||
| 8504 | ||||
(1010- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85381-28220 |
KGJ10,NGJ10,NUJ10 MARK +1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28240 |
KGJ10,NGJ10,NUJ10 MARK -1 |
2 | ||
| 85381-28230 |
KGJ10,NGJ10,NUJ10 MARK +3 |
2 | ||
| 85301 - INLET SUB-ASSY, WASHER | ||||
| 85319-74020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85330-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85319A - HOSE, INLET | ||||
| 85319-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85330 - JAR ASSY, WINDSHIELD WASHER | ||||
| 85315-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85330A - BUSH, WINDSHIELD WASHER JAR | ||||
| 85336-60300 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85316-52190 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85333 - FILTER, WINDSHIELD WASHER JAR | ||||
| 85312-21020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85336D - PACKING, WINDSHIELD WASHER JAR | ||||
| 85336-30160 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348D - JOINT, WINDSHIELD WASHER ELBOW, NO.1 | ||||
| 85355-20200 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85348G - JOINT, WINDSHIELD WASHER HOSE, NO.2 | ||||
| 85349-89122 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85355 - VALVE, WINDSHIELD WASHER HOSE | ||||
| 85321-28020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=540 |
1 | ||
| 90099-62056 |
KGJ10,NGJ10,NUJ10 L=540 |
1 | ||
| 85372 - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1 | ||||
| 90099-33080 |
NGJ10..N;KGJ10,NUJ10 *H,L=990 |
1 | ||
| 85372B - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.2 | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=95 |
1 | ||
| 85372H - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.3 | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=390 |
1 | ||
| 85372J - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.4 | ||||
| 90099-33080 |
KGJ10,NGJ10,NUJ10 *H,L=60 |
1 | ||
| 90099-62059 |
KGJ10,NGJ10,NUJ10 L=60 |
1 | ||
| 85372K - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.5 | ||||
| 90099-62060 |
KGJ10,NGJ10,NUJ10 L=520 |
1 | ||
| 90099-33299 |
KGJ10,NGJ10,NUJ10 *H,L=520 |
1 | ||
| 85387 - CLAMP NO.1 (FOR WINDSEIELD WASHER) | ||||
| 85387-74020 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85387A - CLAMP, WASHER, NO.2 | ||||
| 53614-12040 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85387B - CLAMP, WASHER, NO.3 | ||||
| 53614-74010 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| 85389D - SPRING(WASHER HOSE) | ||||
| 85389-72030 |
KGJ10,NGJ10,NUJ10 |
1 | ||
| Common parts | ||||
| 90119-06767 | ||||
| Linked diagrams | ||||
| 8504 | ||||
