NUJ10L-BGFNWW (2008)
Toyota Iq
(0811- )MTM
EE53,EE63,EE65
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31105G - BOLT(FOR TRANSAXLE CASE & ENGINE SETTING) | ||||
| 91552-81045 |
NUJ10 *10-1.25PX45-26 |
8 | ||
| 31121 - COVER, CLUTCH HOUSING, NO.1 | ||||
| 31121-74010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33030B - BOLT(FOR TRANSAXLE CASE & TRANSMISSION CASE SETTING) | ||||
| 91551-10840 |
KGJ10,NGJ10,NUJ10..MTM *8-1.25PX40-22 |
16 | ||
| 33101A - PLUG(FOR MANUAL TRANSMISSION FILLER) | ||||
| 90341-18033 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 90341-14032 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33101A - PLUG(FOR MANUAL TRANSMISSION FILLER) | ||||
| 90341-18033 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 90341-14032 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33101B - PLUG(FOR MANUAL TRANSMISSION DRAIN) | ||||
| 90341-18016 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33101B - PLUG(FOR MANUAL TRANSMISSION DRAIN) | ||||
| 90341-18016 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33101C - GASKET(FOR MANUAL TRANSMISSION FILLER PLUG) | ||||
| 90430-18008 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 90430-14003 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33101C - GASKET(FOR MANUAL TRANSMISSION FILLER PLUG) | ||||
| 90430-18008 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 90430-14003 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33101D - GASKET(FOR MANUAL TRANSMISSION DRAIN PLUG) | ||||
| 90430-18008 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33101J - PLUG, BREATHER | ||||
| 90930-03133 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33101Q - PLUG, NO.1(FOR TRANSMISSION CASE) | ||||
| 90341-22010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33101S - GASKET(FOR TRANSMISSION CASE PLUG NO.1) | ||||
| 90430-22002 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33109C - SEPARATOR SUB-ASSY, MANUAL TRANSMISSION OIL | ||||
| 33109-74010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33109D - BOLT(FOR MANUAL TRANSMISSION OIL SEPARATOR) | ||||
| 91551-80816 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33111-74010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33111A - PLUG, MANUAL TRANSMISSION CASE | ||||
| 90341-18006 |
NGJ10..R;KGJ10,NUJ10..MTM |
1 | ||
| 33111C - PLUG(FOR TRANSMISSION CASE) | ||||
| 35150-44010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-08054 |
KGJ10,NGJ10,NUJ10..MTM L=23,OD=8 |
3 | ||
| 33111K - GASKET(FOR TRANSMISSION CASE) | ||||
| 90430-18008 |
NGJ10..R;KGJ10,NUJ10..MTM |
1 | ||
| 33124C - PIPE, OIL RECEIVER, NO.1(MTM) | ||||
| 33124-74010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33176B - SEPARATOR, TRANSMISSION OIL(MTM) | ||||
| 33176-74030 |
KGJ10,NGJ10,NUJ10..MTM NO.3 |
1 | ||
| 33176-74020 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33176-74040 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 33176B - SEPARATOR, TRANSMISSION OIL(MTM) | ||||
| 33176-74030 |
KGJ10,NGJ10,NUJ10..MTM NO.3 |
1 | ||
| 33176-74020 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33176-74040 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 33176B - SEPARATOR, TRANSMISSION OIL(MTM) | ||||
| 33176-74030 |
KGJ10,NGJ10,NUJ10..MTM NO.3 |
1 | ||
| 33176-74020 |
KGJ10,NGJ10,NUJ10..MTM NO.1 |
1 | ||
| 33176-74040 |
KGJ10,NGJ10,NUJ10..MTM NO.2 |
1 | ||
| 33176C - BOLT(FOR TRANSMISSION OIL SEPARATOR) | ||||
| 91551-80816 |
KGJ10,NGJ10,NUJ10..MTM |
7 | ||
| 33176C - BOLT(FOR TRANSMISSION OIL SEPARATOR) | ||||
| 91551-80816 |
KGJ10,NGJ10,NUJ10..MTM |
7 | ||
| 33176C - BOLT(FOR TRANSMISSION OIL SEPARATOR) | ||||
| 91551-80816 |
KGJ10,NGJ10,NUJ10..MTM |
7 | ||
| 33240B - PIN, STRAIGHT(FOR REVERSE SHIFT ARM BRACKET) | ||||
| 90250-08054 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| 33449B - MAGNET, TRANSMISSION | ||||
| 33449-20010 |
KGJ10,NGJ10,NUJ10..MTM |
1 | ||
| Common parts | ||||
| 90301-09173 | ||||
| Linked diagrams | ||||
| 4301 | ||||
| 4302 | ||||
| 8401 | ||||
