LN105L-TRMRSW3 (1988)

Toyota Hilux (Jpp)

Production Aug 1988 - Aug 1997
Engine 2L
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8808-9108)JPP

Click highlighted areas on diagram

diagram 75311 75311 75311 75312B 75351C 75351D 75391 75443 75448 75471B 75472A 9008033004 9016740012 9016740037 9016740037
Part # Description Qty Price
75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL)
75311-89123

LN105,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311-35090

KZN130,LN10#,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL)
75311-89123

LN105,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311-35090

KZN130,LN10#,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL)
75311-89123

LN105,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311-35090

KZN130,LN10#,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75351C - MARK, FENDER
75351-89125

LN10#,110,85,90,RN106,110,YN106,110,85,90..JPP

 2
75351D - MARK, FENDER, NO.2
75351-89126

LN10#,110,85,90..JPP

 2
Common parts
90080-33004
90167-40012
90167-40037

(9108- )JPP

Click highlighted areas on diagram

diagram 75311 75311 75311 75318 75351C 75351D 75391 75441E 75443 75448 75449 75471B 75472A 75472A 9046706096 9356013012
Part # Description Qty Price
75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL)
75311-89123

LN105,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311-35090

KZN130,LN10#,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL)
75311-89123

LN105,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311-35090

KZN130,LN10#,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL)
75311-89123

LN105,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75311-35090

KZN130,LN10#,110,130,RN106,110,VZN130,YN106,110..JPP

 1
75318 - RETAINER, RADIATOR GRILLE EMBLEM
75318-35010

LN105,110,RN106,110,YN106,110..JPP..(DLX,STD)

 1
75318-35020

LN105,110,RN106,110,YN106,110..JPP..(DLX,STD)

CHROME PLATED PACKAGE

 1
75318-35030

LN10#,110,RN106,110..JPP

 1
75351C - MARK, FENDER
75351-89125

LN10#,110,85,90,RN106,110,YN106,110,85,90..JPP

 2
75351D - MARK, FENDER, NO.2
75351-89126

LN10#,110,85,90..JPP

 2
Common parts
90467-06096
93560-13012
