YN60RG-MSQ (1984)
Toyota Hilux
(8308-8408)LN6#,YN6#..EUR,GEN,SA ; (8408- )LN6#,RN6#,YN6#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 46110 - HANDLE ASSY, PARKING BRAKE CONTROL | ||||
| 46110-35170 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46110A - BUSH OR RING, O (FOR PARKING BRAKE PLUNGER) | ||||
| 90386-12048 |
LN5#,6#,RN5#,61,YN5#,6# |
1 | ||
| 46114 - PIN, PARKING BRAKE PLUNGER | ||||
| 46114-20010 |
LN5#,6#,RN5#,61,YN5#,6# |
1 | ||
| 46144 - ANTI-RATTLE, PARKING BRAKE PLUNGER | ||||
| 46144-20010 |
LN5#,6#,RN5#,61,YN5#,6# |
1 | ||
| 46275 - PLATE, PARKING BRAKE RELEASE CAUTION | ||||
| 46275-26010 |
LN5#,6#,YN5#,6# |
1 | ||
| 46301 - LEVER SUB-ASSY, PARKING BRAKE INTERMEDIATE | ||||
| 46301-35140 |
LN6#,RN67,YN6# |
1 | ||
| 46301A - SPRING, TENSION(FOR INTERMEDIATE LEVER) | ||||
| 90507-20011 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46304 - EQUALIZER SUB-ASSY, PARKING BRAKE | ||||
| 46341-35030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46304 - EQUALIZER SUB-ASSY, PARKING BRAKE | ||||
| 46341-35030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46304B - BUSH(FOR PARKING BRAKE EQUALIZER) | ||||
| 90385-12029 |
LN60,65,RN6#,YN60,65 |
2 | ||
| 46304B - BUSH(FOR PARKING BRAKE EQUALIZER) | ||||
| 90385-12029 |
LN60,65,RN6#,YN60,65 |
2 | ||
| 46304C - PIN(FOR PARKING BRAKE EQUALIZER) | ||||
| 90240-08040 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46410 - CABLE ASSY, PARKING BRAKE, NO.1 | ||||
| 46410-35280 |
YN60..ARL |
1 | ||
| 46410-35270 |
RN67,YN60,63,65,67..RHD |
1 | ||
| 46420 - CABLE ASSY, PARKING BRAKE, NO.2 | ||||
| 46420-35280 |
LN60,YN60..SR5 |
1 | ||
| 46420C - PIN, W/HOLE(FOR PARKING BRAKE CABLE) | ||||
| 90240-08028 |
LN6#,RN61,YN6# L=21.5 |
2 | ||
| 46420D - GROMMET OR BUSH(FOR PARKING BRAKE CABLE CLAMP) | ||||
| 90385-13051 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46441 - NUT, WIRE ADJUSTING, NO.1 | ||||
| 46441-30030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46441 - NUT, WIRE ADJUSTING, NO.1 | ||||
| 46441-30030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46469 - LEVER, CABLE GUIDE SUPPORT | ||||
| 46469-35020 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46471 - PULLEY, WIRE | ||||
| 46471-20010 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 46471B - PIN, W/HOLE(FOR WIRE PULLEY SET) | ||||
| 90240-08070 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 46473 - BRACKET, PULLEY | ||||
| 46473-35020 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 46479 - LEVER, CABLE GUIDE SAPPORT, NO.2 | ||||
| 46479-35010 |
LN60,61,65,RN6#,YN6# |
1 | ||
| Common parts | ||||
| 90109-08102 | ||||
| 90179-08123 | ||||
| 90179-08146 | ||||
| 90206-08016 | ||||
| 90461-12331 | ||||
| 90461-12773 | ||||
| 90468-06063 | ||||
| 90468-08001 | ||||
| 90468-14004 | ||||
| 90949-01129 | ||||
| 90949-01218 | ||||
| 91611-60614 | ||||
| 91611-60816 | ||||
| 91611-60818 | ||||
| 91616-40820 | ||||
| 91651-60618 | ||||
| 94110-40600 | ||||
| 94110-40800 | ||||
| 95381-02015 | ||||
| 95381-02020 | ||||
| 96160-00900 | ||||
(8308-8408)LN60,YN60..ARL ; (8308-8408)LN65,YN65..RHD..ARL,GEN
NEW ZEALAND SPEC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 46110 - HANDLE ASSY, PARKING BRAKE CONTROL | ||||
| 46110-35170 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46110A - BUSH OR RING, O (FOR PARKING BRAKE PLUNGER) | ||||
| 90386-12048 |
LN5#,6#,RN5#,61,YN5#,6# |
1 | ||
| 46114 - PIN, PARKING BRAKE PLUNGER | ||||
| 46114-20010 |
LN5#,6#,RN5#,61,YN5#,6# |
1 | ||
| 46144 - ANTI-RATTLE, PARKING BRAKE PLUNGER | ||||
| 46144-20010 |
LN5#,6#,RN5#,61,YN5#,6# |
1 | ||
| 46207 - PIN SUB-ASSY, PLUNGER LOCK | ||||
| 46207-35010 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46217 - KNOB, PARKING BRAKE RELEASE ROD | ||||
| 46217-35010 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46217A - PIN, SLOTTED SPRING(FOR PARKING BRAKE RELEASE ROD KNOB) | ||||
| 90254-02002 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46217B - WASHER, PLATE(FOR PARKING BRAKE RELEASE ROD KNOB) | ||||
| 90201-12017 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46217C - SPRING, COMPRESSION(FOR PARKING BRAKE RELEASE ROD KNOB) | ||||
| 90501-10023 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46225 - ROD, PARKING BRAKE PAWL RELEASE | ||||
| 46225-35030 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46238 - PROTECTOR, PLUNGER LOCK PIN | ||||
| 46238-35010 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46266 - HOLDER, PLUNGER LOCK PIN | ||||
| 46266-35010 |
LN55,56,6#,YN55,57,6#..ARL |
1 | ||
| 46301 - LEVER SUB-ASSY, PARKING BRAKE INTERMEDIATE | ||||
| 46301-35140 |
LN6#,RN67,YN6# |
1 | ||
| 46301A - SPRING, TENSION(FOR INTERMEDIATE LEVER) | ||||
| 90507-20011 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46304 - EQUALIZER SUB-ASSY, PARKING BRAKE | ||||
| 46341-35030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46304 - EQUALIZER SUB-ASSY, PARKING BRAKE | ||||
| 46341-35030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46304B - BUSH(FOR PARKING BRAKE EQUALIZER) | ||||
| 90385-12029 |
LN60,65,RN6#,YN60,65 |
2 | ||
| 46304B - BUSH(FOR PARKING BRAKE EQUALIZER) | ||||
| 90385-12029 |
LN60,65,RN6#,YN60,65 |
2 | ||
| 46304C - PIN(FOR PARKING BRAKE EQUALIZER) | ||||
| 90240-08040 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46410 - CABLE ASSY, PARKING BRAKE, NO.1 | ||||
| 46410-35280 |
YN60..ARL |
1 | ||
| 46410-35270 |
RN67,YN60,63,65,67..RHD |
1 | ||
| 46420 - CABLE ASSY, PARKING BRAKE, NO.2 | ||||
| 46420-35280 |
LN60,YN60..SR5 |
1 | ||
| 46420C - PIN, W/HOLE(FOR PARKING BRAKE CABLE) | ||||
| 90240-08028 |
LN6#,RN61,YN6# L=21.5 |
2 | ||
| 46420D - GROMMET OR BUSH(FOR PARKING BRAKE CABLE CLAMP) | ||||
| 90385-13051 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46441 - NUT, WIRE ADJUSTING, NO.1 | ||||
| 46441-30030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46441 - NUT, WIRE ADJUSTING, NO.1 | ||||
| 46441-30030 |
LN60,61,65,RN6#,YN6# |
2 | ||
| 46469 - LEVER, CABLE GUIDE SUPPORT | ||||
| 46469-35020 |
LN60,61,65,RN6#,YN6# |
1 | ||
| 46471 - PULLEY, WIRE | ||||
| 46471-20010 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 46471B - PIN, W/HOLE(FOR WIRE PULLEY SET) | ||||
| 90240-08070 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 46473 - BRACKET, PULLEY | ||||
| 46473-35020 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 46479 - LEVER, CABLE GUIDE SAPPORT, NO.2 | ||||
| 46479-35010 |
LN60,61,65,RN6#,YN6# |
1 | ||
| Common parts | ||||
| 90109-08102 | ||||
| 90179-08123 | ||||
| 90179-08146 | ||||
| 90206-08016 | ||||
| 90461-12331 | ||||
| 90461-12773 | ||||
| 90468-08001 | ||||
| 90468-14004 | ||||
| 90949-01129 | ||||
| 91611-40614 | ||||
| 91611-40816 | ||||
| 91611-40818 | ||||
| 91616-40820 | ||||
| 91656-40620 | ||||
| 93249-14006 | ||||
| 94110-40600 | ||||
| 94110-40800 | ||||
| 94611-10401 | ||||
| 95381-02015 | ||||
| 95381-02020 | ||||
| 96160-00900 | ||||
