RN46R-KRW (1979)
Toyota Hilux
(7901-8307)RN36,46..RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 78105 - ROD SUB-ASSY, ACCELERATOR CONNECTING, NO.3 | ||||
| 78105-95114 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78105-95110 |
RN36..RHD;RN46..ARL..IV3;RN46..RHD..(EUR,GEN) |
1 | ||
| 78105A - CLIP (FOR ACCELERATOR TORQUE ROD) | ||||
| 90468-16012 |
RN31,36,41;RN30,40..LHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..EUR,GEN,ME,SA |
1 | ||
| 78105C - CLAMP (FOR ACCELERATOR TORQUE ROD) | ||||
| 90463-03110 |
RN36;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..EUR,GEN,ME,SA |
1 | ||
| 78105D - SPRING (FOR ACCELERATOR TORQUE ROD) | ||||
| 90508-20020 |
RN36..RHD;RN46..ARL..IV3;RN46..RHD..(EUR,GEN) |
1 | ||
| 90508-23032 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78106 - BRACKET SUB-ASSY, ACCELERATOR PEDAL SUPPORT | ||||
| 78011-95110 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78011-95110 |
RN36;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..EUR,GEN,ME,SA |
1 | ||
| 78107 - BRACKET SUB-ASSY, ACCELERATOR TORQUE ROD | ||||
| 78170-95112 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78110 - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-95117 |
RN36..RHD;RN46..ARL..IV3;RN46..RHD..(EUR,GEN) |
1 | ||
| 78120-95122 |
RN36,46..RHD..EUR COLD SPEC |
1 | ||
| 78120-95128 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78120-95128 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) W/THROTTLE KNOB |
1 | ||
| 78120-95130 |
LN46,RN36,46..RHD..EUR COLD SPEC |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78010-95113 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78111-89102 |
LN3#,4#,RN3#,4# |
1 | ||
| 78010-95111 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78010-95113 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78111-89102 |
LN3#,4#,RN3#,4# |
1 | ||
| 78010-95111 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78127 - BUSH, ACCELERATOR PEDAL, NO.2 | ||||
| 78127-20010 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78180 - WIRE ASSY, ACCELERATOR | ||||
| 78180-95118 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78180-95120 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78180-95113 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78183 - BRACKET, ACCELERATOR LINK ROD | ||||
| 78014-95110 |
RN36..RHD;RN46..ARL..IV3;RN46..RHD..(EUR,GEN) W/O EGR VALVE |
1 | ||
| 25625-34021 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) W/O EGR VALVE |
1 | ||
| 78183 - BRACKET, ACCELERATOR LINK ROD | ||||
| 78014-95110 |
RN36..RHD;RN46..ARL..IV3;RN46..RHD..(EUR,GEN) W/O EGR VALVE |
1 | ||
| 25625-34021 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) W/O EGR VALVE |
1 | ||
| 78186 - SUPPORT, ACCELERATOR CONTROL CABLE, NO.1 | ||||
| 78185-95110 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78191A - CLAMP (FOR ACCELERATOR WIRE SET) | ||||
| 90461-10357 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) SUPPORT CABLE |
1 | ||
| 90463-08235 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) BRAKE CABLE,TANDEM |
1 | ||
| 90461-10287 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 78191A - CLAMP (FOR ACCELERATOR WIRE SET) | ||||
| 90461-10357 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) SUPPORT CABLE |
1 | ||
| 90463-08235 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) BRAKE CABLE,TANDEM |
1 | ||
| 90461-10287 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 78191A - CLAMP (FOR ACCELERATOR WIRE SET) | ||||
| 90461-10357 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) SUPPORT CABLE |
1 | ||
| 90463-08235 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) BRAKE CABLE,TANDEM |
1 | ||
| 90461-10287 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 78410 - CABLE ASSY, THROTTLE CONTROL | ||||
| 78410-95113 |
LN36,46;RN36,46..ARL,GEN,SA |
1 | ||
| Common parts | ||||
| 91611-40816 | ||||
| 91611-41020 | ||||
| 91616-40614 | ||||
| 91616-40616 | ||||
| 91616-40816 | ||||
| 91651-40614 | ||||
| 91651-40820 | ||||
| 91661-40620 | ||||
| 91661-40816 | ||||
(8103-8307)LN36,46..RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 78010 - LINK, ACCELERATOR | ||||
| 78100-95110 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 78100-89102 |
LN3#,4# |
1 | ||
| 78106 - BRACKET SUB-ASSY, ACCELERATOR PEDAL SUPPORT | ||||
| 78011-95110 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78011-95110 |
RN36;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..EUR,GEN,ME,SA |
1 | ||
| 78110 - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-95117 |
RN36..RHD;RN46..ARL..IV3;RN46..RHD..(EUR,GEN) |
1 | ||
| 78120-95122 |
RN36,46..RHD..EUR COLD SPEC |
1 | ||
| 78120-95128 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78120-95128 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) W/THROTTLE KNOB |
1 | ||
| 78120-95130 |
LN46,RN36,46..RHD..EUR COLD SPEC |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78010-95113 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78111-89102 |
LN3#,4#,RN3#,4# |
1 | ||
| 78010-95111 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78010-95113 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78111-89102 |
LN3#,4#,RN3#,4# |
1 | ||
| 78010-95111 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78127 - BUSH, ACCELERATOR PEDAL, NO.2 | ||||
| 78127-20010 |
LN36,46,RN36,46..EUR COLD SPEC |
1 | ||
| 78180 - WIRE ASSY, ACCELERATOR | ||||
| 78180-95118 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78180-95120 |
LN46..TW..ARL;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..RHD..(EUR,GEN) |
1 | ||
| 78180-95113 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78186 - SUPPORT, ACCELERATOR CONTROL CABLE, NO.1 | ||||
| 78185-95110 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 78191A - CLAMP (FOR ACCELERATOR WIRE SET) | ||||
| 90461-10357 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) SUPPORT CABLE |
1 | ||
| 90463-08235 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) BRAKE CABLE,TANDEM |
1 | ||
| 90461-10287 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 78191A - CLAMP (FOR ACCELERATOR WIRE SET) | ||||
| 90461-10357 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) SUPPORT CABLE |
1 | ||
| 90463-08235 |
RN36..RHD;RN46..ARL..IV3;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) BRAKE CABLE,TANDEM |
1 | ||
| 90461-10287 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN36,46..T1..(EUR,GEN) |
1 | ||
| 78410 - CABLE ASSY, THROTTLE CONTROL | ||||
| 78410-95113 |
LN36,46;RN36,46..ARL,GEN,SA |
1 | ||
| Common parts | ||||
| 90386-10138 | ||||
| 90462-12023 | ||||
| 90508-20034 | ||||
| 91611-40812 | ||||
| 91616-40614 | ||||
| 91651-40614 | ||||
| 91651-40616 | ||||
| 91655-40818 | ||||
| 91655-40820 | ||||
| 91661-40620 | ||||
| 94141-41000 | ||||
| 94511-01000 | ||||
| 94611-11001 | ||||
| 95381-02518 | ||||
