RN41R-MSN (1981)
Toyota Hilux
(7808-8312)RN31,36,41,46
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 87019C - GROMMET, HEATER HOSE | ||||
| 90480-36005 |
RN31,41;LN3#,4#,RN30,36,40,46..(DLX,STD)..(ARL,EUR,GEN,ME,SA) |
2 | ||
| 90480-36005 |
LN30,40,RN30,41..(4F,5F)..ECB |
2 | ||
| 87019C - GROMMET, HEATER HOSE | ||||
| 90480-36005 |
RN31,41;LN3#,4#,RN30,36,40,46..(DLX,STD)..(ARL,EUR,GEN,ME,SA) |
2 | ||
| 90480-36005 |
LN30,40,RN30,41..(4F,5F)..ECB |
2 | ||
| 87019C - GROMMET, HEATER HOSE | ||||
| 90480-36005 |
RN31,41;LN3#,4#,RN30,36,40,46..(DLX,STD)..(ARL,EUR,GEN,ME,SA) |
2 | ||
| 90480-36005 |
LN30,40,RN30,41..(4F,5F)..ECB |
2 | ||
| 87019C - GROMMET, HEATER HOSE | ||||
| 90480-36005 |
RN31,41;LN3#,4#,RN30,36,40,46..(DLX,STD)..(ARL,EUR,GEN,ME,SA) |
2 | ||
| 90480-36005 |
LN30,40,RN30,41..(4F,5F)..ECB |
2 | ||
| 87240 - VALVE ASSY, HEATER WATER | ||||
| 87240-89109 |
RN30,41..(4F,5F)..ECB |
1 | ||
| 87240-89109 |
RN46..ARL..IV3;RN3#,40,41..RHD;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 87240 - VALVE ASSY, HEATER WATER | ||||
| 87240-89109 |
RN30,41..(4F,5F)..ECB |
1 | ||
| 87240-89109 |
RN46..ARL..IV3;RN3#,40,41..RHD;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) |
1 | ||
| 87245A - HOSE, HEATER WATER, INLET A | ||||
| 99552-30880 |
RN46..ARL..IV3;RN31,36,41..RHD;RN46..RHD..(EUR,GEN) L=880 |
1 | ||
| 99552-31000 |
RN46..ARL..IV3;RN31,36,41..RHD;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) *H,L=880 |
1 | ||
| 87245A - HOSE, HEATER WATER, INLET A | ||||
| 99552-30880 |
RN46..ARL..IV3;RN31,36,41..RHD;RN46..RHD..(EUR,GEN) L=880 |
1 | ||
| 99552-31000 |
RN46..ARL..IV3;RN31,36,41..RHD;LN46..T1..ARL..CBU;RN46..RHD..(EUR,GEN,SA) *H,L=880 |
1 | ||
| 87245E - HOSE, HEATER WATER, INLET E | ||||
| 87245-89121 |
LN30,40,RN30,41..(4F,5F)..ECB |
1 | ||
| 87245-89121 |
RN31,41..RHD..ECB;LN3#,4#,RN30,36,40,46..RHD..STD |
1 | ||
| 87245E - HOSE, HEATER WATER, INLET E | ||||
| 87245-89121 |
LN30,40,RN30,41..(4F,5F)..ECB |
1 | ||
| 87245-89121 |
RN31,41..RHD..ECB;LN3#,4#,RN30,36,40,46..RHD..STD |
1 | ||
| 87246A - HOSE, HEATER WATER, OUTLET A | ||||
| 87245-89128 |
RN46..ARL..IV3;LN46..T1..ARL..CBU;RN31,36,41..RHD..ECB;RN46..RHD..T1..(EUR,GEN,SA) |
1 | ||
| 87246A - HOSE, HEATER WATER, OUTLET A | ||||
| 87245-89128 |
RN46..ARL..IV3;LN46..T1..ARL..CBU;RN31,36,41..RHD..ECB;RN46..RHD..T1..(EUR,GEN,SA) |
1 | ||
| 87246E - HOSE, HEATER WATER, OUTLET E | ||||
| 99552-31000 |
RN46..ARL..IV3;LN46..T1..ARL..CBU;RN31,36,41..RHD..ECB;RN46..RHD..T1..(EUR,GEN,SA) L=1000 |
1 | ||
| 87249A - PIPE, HEATER WATER OUTLET, A | ||||
| 87248-14090 |
RN46..ARL..IV3;LN46..T1..ARL..CBU;RN31,36,41..RHD..ECB;RN46..RHD..T1..(EUR,GEN,SA) |
1 | ||
| Common parts | ||||
| 90460-24039 | ||||
| 90461-10263 | ||||
| 90463-04005 | ||||
| 90463-12014 | ||||
| 90463-15002 | ||||
| 91656-40618 | ||||
| 91656-40818 | ||||
| 91661-40820 | ||||
| 96112-10250 | ||||
| 96222-20924 | ||||
