LN51R-MRN (1984)
Toyota Hilux
(9508- )2L,3L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 22100 - PUMP ASSY, INJECTION OR SUPPLY | ||||
| 22100-54350 |
2L..LN5#,6#..(DLX,STD)..(GEN,SA) W(*HAC) |
1 | ||
| 22100-54360 |
2L..LN5#,60,65..(DLX,STD)..(GEN,SA) W(*HAC) |
1 | ||
| 22100-54360 |
2L..LN5#..SA W(*TAC) |
1 | ||
| 22100-54361 |
2L..LN5#,65..GEN,SA W(*HAC & *TAC) |
1 | ||
| 22100-54361 |
2L..LN5#,65..GEN,SA W(*HAC & *TAC) |
1 | ||
| 22100-54351 |
2L..LN5#..SA |
1 | ||
| 22100-5B770 |
2L..LN51,56 W(*HAC & *TAC) |
1 | ||
| 22100A - HOSE OR PIPE, FUEL(FOR INJECTION PUMP TO FUEL FILTER) | ||||
| 23271-54050 |
2L,3L..LN5#,67 |
1 | ||
| 95332-08040 |
L,2L..LN5#,6# *H,L=320,ID=7.6 |
1 | ||
| 95333-08040 |
2L..LN5#,6# *H,L=320 |
1 | ||
| 22811 - STAY, INJECTION PUMP, NO.1 | ||||
| 22811-54041 |
2L,3L..LN5#,6# |
1 | ||
| 22811-54040 |
L,2L..LN5#,6# |
1 | ||
| 23701 - PIPE SUB-ASSY, INJECTION, NO.1 | ||||
| 23701-54140 |
2L,3L..LN5#,67 |
1 | ||
| 23701-54072 |
2L..LN5#,65 |
1 | ||
| 23702 - PIPE SUB-ASSY, INJECTION, NO.2 | ||||
| 23702-54140 |
2L,3L..LN5#,67 |
1 | ||
| 23702-54071 |
2L..LN5#,65 |
1 | ||
| 23703 - PIPE SUB-ASSY, INJECTION, NO.3 | ||||
| 23703-54100 |
2L,3L..LN5#,67 |
1 | ||
| 23703-54050 |
L,2L..LN5#,6# |
1 | ||
| 23704 - PIPE SUB-ASSY, INJECTION, NO.4 | ||||
| 23704-54050 |
L,2L..LN5#,6# |
1 | ||
| 23704-54100 |
2L,3L..LN5#,67 |
1 | ||
| 23741 - CLAMP, INJECTION PIPE, NO.1 | ||||
| 23741-54030 |
2L,3L..LN5#,67 |
2 | ||
| 23741-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23741 - CLAMP, INJECTION PIPE, NO.1 | ||||
| 23741-54030 |
2L,3L..LN5#,67 |
2 | ||
| 23741-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23741A - BOLT, STUD(FOR INJECTION PIPE CLAMP) | ||||
| 90116-06095 |
2L,3L..LN5#,67 L=37,OD=6 |
2 | ||
| 90116-06275 |
L,2L..LN5#,6# |
2 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23742 - CLAMP, INJECTION PIPE, NO.2 | ||||
| 23742-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23811 - PIPE, FUEL(FOR FUEL FILTER TO INJECTION PUMP) | ||||
| 23811-54051 |
L,2L..LN5#,6# |
1 | ||
| 23811-54151 |
2L,3L..LN5#,67 |
1 | ||
| Common parts | ||||
| 23273-54020 | ||||
| 90119-06454 | ||||
| 90119-10699 | ||||
| 90179-06100 | ||||
| 90179-08022 | ||||
| 90464-00355 | ||||
| 90467-13050 | ||||
| 90929-01205 | ||||
| 91651-60818 | ||||
| 96132-30600 | ||||
(8508-9508)2L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 22100 - PUMP ASSY, INJECTION OR SUPPLY | ||||
| 22100-54350 |
2L..LN5#,6#..(DLX,STD)..(GEN,SA) W(*HAC) |
1 | ||
| 22100-54360 |
2L..LN5#,60,65..(DLX,STD)..(GEN,SA) W(*HAC) |
1 | ||
| 22100-54360 |
2L..LN5#..SA W(*TAC) |
1 | ||
| 22100-54361 |
2L..LN5#,65..GEN,SA W(*HAC & *TAC) |
1 | ||
| 22100-54361 |
2L..LN5#,65..GEN,SA W(*HAC & *TAC) |
1 | ||
| 22100-54351 |
2L..LN5#..SA |
1 | ||
| 22100-5B770 |
2L..LN51,56 W(*HAC & *TAC) |
1 | ||
| 22100A - HOSE OR PIPE, FUEL(FOR INJECTION PUMP TO FUEL FILTER) | ||||
| 23271-54050 |
2L,3L..LN5#,67 |
1 | ||
| 95332-08040 |
L,2L..LN5#,6# *H,L=320,ID=7.6 |
1 | ||
| 95333-08040 |
2L..LN5#,6# *H,L=320 |
1 | ||
| 22811 - STAY, INJECTION PUMP, NO.1 | ||||
| 22811-54041 |
2L,3L..LN5#,6# |
1 | ||
| 22811-54040 |
L,2L..LN5#,6# |
1 | ||
| 23701 - PIPE SUB-ASSY, INJECTION, NO.1 | ||||
| 23701-54140 |
2L,3L..LN5#,67 |
1 | ||
| 23701-54072 |
2L..LN5#,65 |
1 | ||
| 23702 - PIPE SUB-ASSY, INJECTION, NO.2 | ||||
| 23702-54140 |
2L,3L..LN5#,67 |
1 | ||
| 23702-54071 |
2L..LN5#,65 |
1 | ||
| 23703 - PIPE SUB-ASSY, INJECTION, NO.3 | ||||
| 23703-54100 |
2L,3L..LN5#,67 |
1 | ||
| 23703-54050 |
L,2L..LN5#,6# |
1 | ||
| 23704 - PIPE SUB-ASSY, INJECTION, NO.4 | ||||
| 23704-54050 |
L,2L..LN5#,6# |
1 | ||
| 23704-54100 |
2L,3L..LN5#,67 |
1 | ||
| 23741 - CLAMP, INJECTION PIPE, NO.1 | ||||
| 23741-54030 |
2L,3L..LN5#,67 |
2 | ||
| 23741-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23741A - BOLT, STUD(FOR INJECTION PIPE CLAMP) | ||||
| 90116-06095 |
2L,3L..LN5#,67 L=37,OD=6 |
2 | ||
| 90116-06275 |
L,2L..LN5#,6# |
2 | ||
| 23741A - BOLT, STUD(FOR INJECTION PIPE CLAMP) | ||||
| 90116-06095 |
2L,3L..LN5#,67 L=37,OD=6 |
2 | ||
| 90116-06275 |
L,2L..LN5#,6# |
2 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23742 - CLAMP, INJECTION PIPE, NO.2 | ||||
| 23742-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23811 - PIPE, FUEL(FOR FUEL FILTER TO INJECTION PUMP) | ||||
| 23811-54051 |
L,2L..LN5#,6# |
1 | ||
| 23811-54151 |
2L,3L..LN5#,67 |
1 | ||
| Common parts | ||||
| 90179-06070 | ||||
| 90179-08022 | ||||
| 90461-08447 | ||||
| 90467-13001 | ||||
| 91513-60620 | ||||
| 91651-60818 | ||||
(8308-8508)L,2L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 22100 - PUMP ASSY, INJECTION OR SUPPLY | ||||
| 22100-54350 |
2L..LN5#,6#..(DLX,STD)..(GEN,SA) W(*HAC) |
1 | ||
| 22100-54360 |
2L..LN5#,60,65..(DLX,STD)..(GEN,SA) W(*HAC) |
1 | ||
| 22100-54360 |
2L..LN5#..SA W(*TAC) |
1 | ||
| 22100-54361 |
2L..LN5#,65..GEN,SA W(*HAC & *TAC) |
1 | ||
| 22100-54361 |
2L..LN5#,65..GEN,SA W(*HAC & *TAC) |
1 | ||
| 22100-54351 |
2L..LN5#..SA |
1 | ||
| 22100-5B770 |
2L..LN51,56 W(*HAC & *TAC) |
1 | ||
| 22100A - HOSE OR PIPE, FUEL(FOR INJECTION PUMP TO FUEL FILTER) | ||||
| 23271-54050 |
2L,3L..LN5#,67 |
1 | ||
| 95332-08040 |
L,2L..LN5#,6# *H,L=320,ID=7.6 |
1 | ||
| 95333-08040 |
2L..LN5#,6# *H,L=320 |
1 | ||
| 22811 - STAY, INJECTION PUMP, NO.1 | ||||
| 22811-54041 |
2L,3L..LN5#,6# |
1 | ||
| 22811-54040 |
L,2L..LN5#,6# |
1 | ||
| 23701 - PIPE SUB-ASSY, INJECTION, NO.1 | ||||
| 23701-54140 |
2L,3L..LN5#,67 |
1 | ||
| 23701-54072 |
2L..LN5#,65 |
1 | ||
| 23702 - PIPE SUB-ASSY, INJECTION, NO.2 | ||||
| 23702-54140 |
2L,3L..LN5#,67 |
1 | ||
| 23702-54071 |
2L..LN5#,65 |
1 | ||
| 23703 - PIPE SUB-ASSY, INJECTION, NO.3 | ||||
| 23703-54100 |
2L,3L..LN5#,67 |
1 | ||
| 23703-54050 |
L,2L..LN5#,6# |
1 | ||
| 23704 - PIPE SUB-ASSY, INJECTION, NO.4 | ||||
| 23704-54050 |
L,2L..LN5#,6# |
1 | ||
| 23704-54100 |
2L,3L..LN5#,67 |
1 | ||
| 23741 - CLAMP, INJECTION PIPE, NO.1 | ||||
| 23741-54030 |
2L,3L..LN5#,67 |
2 | ||
| 23741-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23741A - BOLT, STUD(FOR INJECTION PIPE CLAMP) | ||||
| 90116-06095 |
2L,3L..LN5#,67 L=37,OD=6 |
2 | ||
| 90116-06275 |
L,2L..LN5#,6# |
2 | ||
| 23741A - BOLT, STUD(FOR INJECTION PIPE CLAMP) | ||||
| 90116-06095 |
2L,3L..LN5#,67 L=37,OD=6 |
2 | ||
| 90116-06275 |
L,2L..LN5#,6# |
2 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23741B - CLAMP, INJECTION PIPE | ||||
| 23741-54010 |
L,2L,3L..LN5#,6# |
4 | ||
| 23742 - CLAMP, INJECTION PIPE, NO.2 | ||||
| 23742-54010 |
L,2L,3L..LN5#,6# |
2 | ||
| 23811 - PIPE, FUEL(FOR FUEL FILTER TO INJECTION PUMP) | ||||
| 23811-54051 |
L,2L..LN5#,6# |
1 | ||
| 23811-54151 |
2L,3L..LN5#,67 |
1 | ||
| Common parts | ||||
| 90179-06070 | ||||
| 90179-08022 | ||||
| 90461-08447 | ||||
| 90464-00108 | ||||
| 90464-00148 | ||||
| 90467-11009 | ||||
| 90467-13001 | ||||
| 91611-40620 | ||||
| 91651-60820 | ||||
| 91661-40614 | ||||
| Linked diagrams | ||||
| 8401 | ||||
